BUF634T vs BUF634P Comparison
Detailed side-by-side comparison of BUF634T by Texas Instruments and BUF634P by Texas Instruments. Compare key specifications, electrical parameters, packaging, lifecycle status, pricing, and availability to determine the best component for your design requirements.
Texas Instruments
BUF634T - 250mA High-Speed Buffer, 2000V/us | Texas Instruments
BUF634T β Active
Specification Comparison
| Parameter | BUF634T | BUF634P |
|---|---|---|
| Brand | Texas Instruments | Texas Instruments |
| Category | Amplifier ICs | Amplifier ICs |
| Lifecycle Status | Active | Active |
| Stock Status | In Stock | In Stock |
| Unit Price (USD) | $9.40 | $5.40 |
| Function | Unity-gain high-speed buffer amplifier | High-speed unity-gain buffer |
| Number of Circuits | 1 | β |
| Output Current | 250 mA | 250 mA |
| Slew Rate | 2000 V/us | 2000 V/us |
| Bandwidth | 180 MHz (pin-selected); 30 MHz low-power mode | β |
| Quiescent Current | 1.5 mA (30 MHz BW mode) | 1.5 mA (30 MHz BW mode) |
| Supply Voltage Range | Up to +/-18 V | +/-2.25 V to +/-18 V |
| Input Type | Bipolar | β |
| Protection Features | Internal current limit, thermal shutdown | Internal current limit, thermal shutdown |
| Topology | Open-loop buffer (usable inside op amp feedback loop) | β |
| Operating Temperature | [DATA_NEEDED: operating temperature range] | [DATA_NEEDED: operating temperature range] |
| Package | TO-220-5 | 8-PDIP (P) |
| Mounting Type | Through Hole | Through Hole |
| RoHS Status | Compliant | [DATA_NEEDED: RoHS status] |
| Upgraded Version | BUF634A (higher slew rate 3750 V/us, 210 MHz BW) | β |
| Number of Channels | β | 1 |
| Bandwidth (pin-selected) | β | 180 MHz (BW to V+) / 30 MHz (BW open) |
| Gain | β | 1 V/V (unity, open-loop buffer) |
| Input Offset Voltage | β | [DATA_NEEDED: input offset voltage] |
| Output Resistance | β | [DATA_NEEDED: output resistance] |
| Upgrade Path | β | BUF634A (higher slew 3750 V/us, 210 MHz BW, 8.5 mA IQ) |
