EPM240GT100I5N vs EPM240GM100I5N Comparison
Detailed side-by-side comparison of EPM240GT100I5N by Altera and EPM240GM100I5N by Intel. Compare key specifications, electrical parameters, packaging, lifecycle status, pricing, and availability to determine the best component for your design requirements.
Altera
EPM240GT100I5N
EPM240GT100I5N - 240-LE MAX II CPLD, 4.7ns, 100-TQFP | Intel
EPM240GT100I5N β Active
Specification Comparison
| Parameter | EPM240GT100I5N | EPM240GM100I5N |
|---|---|---|
| Brand | Altera | Intel |
| Category | FPGA & CPLD | FPGA & CPLD |
| Lifecycle Status | Active | Active |
| Stock Status | In Stock | In Stock |
| Unit Price (USD) | $6.31 | $39.77 |
| Product Type | CPLD (Complex Programmable Logic Device) | β |
| Family | MAX II | MAX II |
| Logic Elements (LEs) | 240 | β |
| Equivalent Macrocells | 192 | 192 |
| User I/Os | 80 | β |
| Propagation Delay (tPD) | 4.7 ns | β |
| Internal Performance (fMAX) | 304 MHz | β |
| Embedded Non-Volatile Memory | 8 Kbits user Flash | β |
| Process Technology | 0.18 Β΅m 6-layer-metal Flash CMOS | 0.18 Β΅m 6-layer-metal flash CMOS |
| Supply Voltage - Core (VCCINT) | 1.71 V to 1.89 V (3.3 V tolerant for MAX II G variant) | 1.8 V |
| I/O Bank Voltage (VCCIO) | 1.5 V / 1.8 V / 2.5 V / 3.3 V MultiVolt I/O | β |
| Programming Interface | JTAG (IEEE 1149.1) ISP | JTAG (IEEE 1149.1) ISP |
| Package | 100-pin TQFP (14x14 mm, 0.5 mm pitch) | 100-ball Micro FineLine BGA (MBGA), 6 mm Γ 6 mm, 0.5 mm pitch |
| Operating Temperature | -40 Β°C to +100 Β°C (Industrial) | -40 Β°C to +105 Β°C (industrial) |
| Lead-Free / RoHS | Yes (suffix N) | β |
| Mounting Type | Surface Mount | Surface Mount |
| Logic Elements (LE) | β | 240 |
| User I/O Pins | β | 80 |
| User Flash Memory (UFM) | β | 8 Kbits |
| Pin-to-Pin Delay (tPD1) | β | 4.7 ns |
| Maximum Operating Frequency | β | 300 MHz (internal) |
| Configuration Memory | β | On-chip non-volatile flash (instant-on) |
| MultiVolt I/O (VCCIO) | β | 1.5 V / 1.8 V / 2.5 V / 3.3 V / 5 V |
| RoHS / Lead-Free | β | Lead-free per package marking |
