TPS53511RGTR vs TPS53513RVER Comparison
Detailed side-by-side comparison of TPS53511RGTR by Texas Instruments and TPS53513RVER by Texas Instruments. Compare key specifications, electrical parameters, packaging, lifecycle status, pricing, and availability to determine the best component for your design requirements.
Texas Instruments
TPS53511RGTR
TPS53511RGTR - 1.5A Sync Buck Regulator 4.5-18V | TI
TPS53511RGTR β ActiveTexas Instruments
TPS53513RVER - 8A, 18V Sync Buck Converter | Texas Instruments
TPS53513RVER β ActiveSpecification Comparison
| Parameter | TPS53511RGTR | TPS53513RVER |
|---|---|---|
| Brand | Texas Instruments | Texas Instruments |
| Category | DC-DC Converters | DC-DC Converters |
| Lifecycle Status | Active | Active |
| Stock Status | In Stock | In Stock |
| Unit Price (USD) | $0.42 | $3.55 |
| Topology | Synchronous Step-Down (Buck) Converter, D-CAP2 mode | Synchronous step-down (buck) converter |
| Input Voltage Range | 4.5 V to 18 V | 1.5 V to 18 V |
| Output Current | 1.5 A | β |
| Output Type | Positive Adjustable | β |
| Feedback Reference Voltage | 0.76 V | β |
| Number of Outputs | 1 | 1 |
| Switching MOSFETs | Integrated (synchronous) | β |
| Control Mode | Adaptive On-Time D-CAP2 | D-CAP3 adaptive on-time |
| Operating Temperature | -40C to +85C | β |
| Package | 16-VFQFN Exposed Pad (RGT), VQFN-16 | 28-VFQFN Exposed Pad (RVE), VQFN-28 |
| Mounting Type | Surface Mount | Surface Mount |
| Quiescent / Standby Current | Low standby current (per datasheet) | β |
| Applications | Points-of-load, computing power systems | β |
| Package Size | 4x4 mm QFN family | β |
| Packaging | Tape & Reel (RGTR suffix) | β |
| Typical Efficiency | [DATA_NEEDED: typical efficiency curve value] | β |
| Switching Frequency | [DATA_NEEDED: nominal switching frequency] | β |
| Output Voltage Range | β | 0.6 V to 5.5 V (adjustable) |
| Maximum Output Current | β | 8 A continuous |
| Reference Voltage | β | 600 mV +/-0.5% |
| High-Side MOSFET Rds(on) | β | 13.8 mOhm (integrated) |
| Low-Side MOSFET Rds(on) | β | 5.9 mOhm (integrated) |
| Output Capacitor Type | β | All-ceramic supported |
| Integrated Boost Switch | β | Yes |
| Operating Ambient Temperature | β | -40C to +85C |
| Packing | β | Tape & Reel (R suffix) |
| RoHS Status | β | RoHS-Exempt & Green (per TI E2E forum) |
| Unit Price (reference) | β | $5.1761 (as of 2026-09-10, Heisener) |
