AD7795BRUZ - 16-Bit Sigma-Delta ADC, 6-Channel | Analog Devices

Name: AD7795BRUZ
Brand: Analog Devices
Price: 4.98 USD
Availability: InStock

MPN: AD7795BRUZ ✓ Active

In Stock Ships in 1-3 business days

2.7 V to 5.25 V Vdss 1 µA max Id 24-Lead TSSOP Package

From $4.98 USD / Unit

MOQ: 1 |

Price updated: 2026-08-22

Volume Pricing

Qty	Unit Price	Extended
1	$8.52	$8.52
10	$7.83	$78.30
100	$6.54	$654.00
500	$5.62	$2,810.00
1,000	$4.98	$4,980.00

ℹ️ All prices are in USD

View Datasheet (PDF) View Alternatives
