What is the VL53L0CXV0DH/1 and What Are Its Key Verified Specs?

The VL53L0CXV0DH/1 is a Time-of-Flight (ToF) laser-ranging sensor module from STMicroelectronics, designed for accurate distance measurement up to 2 meters. It integrates a 940nm VCSEL, a SPAD array, and a microcontroller in a compact 4.4 x 2.4 x 1.0 mm optical module. Key verified specifications include a measurement range of 30 mm to 2000 mm, accuracy of ±3% (typical), supply voltage of 2.8 V, I2C interface up to 400 kHz, and a field of view of 25 degrees. The device is currently in active lifecycle status with 99,999 units in stock at XAIPART, priced at $1.5114 per unit at 1000+ quantities as of 2026-08-25.

How to Select and Design In the VL53L0CXV0DH/1?

When selecting the VL53L0CXV0DH/1 for your application, verify that your required measurement range falls within 30 mm to 2000 mm and that your system can supply 2.8 V. The sensor draws 19 mA typical during ranging and only 5 uA in standby, making it suitable for battery-powered devices. Ensure your microcontroller supports I2C up to 400 kHz. For design-in, place the module with a clear field of view, use a cover glass with high infrared transmittance, and add pull-up resistors on the I2C lines. Decouple the power supply with adequate capacitors. The device operates over -20°C to +70°C, so verify your thermal environment.

What Are the Pin Functions and How Do I Connect Them?

The VL53L0CXV0DH/1 has 6 pins: AVDD (power supply, 2.8V), GND (ground), SDA (I2C data), SCL (I2C clock), XSHUT (shutdown, active low), and GPIO1 (interrupt output). Connect AVDD to a clean 2.8V supply, GND to ground, and SDA/SCL to your microcontroller's I2C lines with pull-up resistors. Use XSHUT to place the device in shutdown mode when not in use to save power. GPIO1 can be connected to an interrupt input to signal ranging completion.

What Are the Drop-in Alternatives and How Do They Compare?

From the verified data, the only drop-in alternative is the VL53L1CXV0FY/1, which shares the same pinout and package but offers a longer range of up to 4 meters. The following table compares the two based on verified specifications:

ParameterVL53L0CXV0DH/1VL53L1CXV0FY/1
Measurement Range30 mm to 2000 mmUp to 4 m (verified from FAQ)
Accuracy±3% (typical)Higher accuracy (verified from FAQ)
Supply Voltage2.8 V[DATA_NEEDED: Supply Voltage]
InterfaceI2C (up to 400 kHz)[DATA_NEEDED: Interface]
Field of View25 degrees[DATA_NEEDED: Field of View]
Package4.4 x 2.4 x 1.0 mmSame package (verified from FAQ)
Pinout6-pin (AVDD, GND, SDA, SCL, XSHUT, GPIO1)Same pinout (verified from FAQ)

Note: The VL53L1CXV0FY/1 has a different register map and requires updated software. For cross-brand alternatives, none are listed in the verified data.

What Is the Market Position and Lifecycle Status of the VL53L0CXV0DH/1?

The VL53L0CXV0DH/1 is in active lifecycle status, indicating it is in production and available for new designs. As of 2026-08-25, XAIPART has 99,999 units in stock, with a base price of $1.5114 at 1000+ quantities. The device is manufactured by STMicroelectronics, a leading semiconductor company. [DATA_NEEDED: Market share, competitive landscape, and supply chain details are not provided in the verified data.]

What Trends Should Buyers Watch for the VL53L0CXV0DH/1?

Buyers should monitor the continued availability of the VL53L0CXV0DH/1 given its active lifecycle status. The verified specifications indicate a trend toward compact, low-power ToF sensors with I2C interfaces for consumer and industrial applications. The VL53L1CXV0FY/1 offers extended range, suggesting a roadmap toward higher performance. Watch for potential software updates and new variants. [VERIFY_NEEDED: Market trends beyond the provided data are not available.]

Frequently Asked Questions

The VL53L0CXV0DH/1 measures distances from 30mm to 2000mm. According to the STMicroelectronics VL53L0X datasheet, the typical ranging range is 30mm to 2000mm, with accuracy of ±3% under standard conditions.
The VL53L0CXV0DH/1 operates from a 2.8V supply. The datasheet specifies a supply voltage range of 2.8V ±0.3V, with a typical operating current of 19mA during active ranging.
The VL53L0CXV0DH/1 uses Time-of-Flight (ToF) technology. It emits a 940nm infrared laser pulse from a VCSEL and measures the time for the reflected light to return to a SPAD array, calculating distance with millimeter accuracy.
The VL53L0CXV0DH/1 is a specific variant of the VL53L0X module. The 'CXV0DH' suffix indicates a particular optical and packaging configuration, but the electrical and functional specifications are identical.
Yes, the VL53L0CXV0DH/1 is ideal for obstacle avoidance in robots. Its 30mm to 2000mm range and 25-degree field of view allow robots to detect obstacles at a distance, and the I2C interface simplifies integration with microcontrollers.
As of 2026-08-06, the price of VL53L0CXV0DH/1 is approximately $4.50 for single-unit quantities, decreasing to $2.88 at 1000 units. Prices vary by distributor and quantity.
VL53L0CXV0DH/1 is available from major distributors such as DigiKey, Mouser, and Arrow. You can also purchase directly from STMicroelectronics' authorized distributors.
The lead time for VL53L0CXV0DH/1 is typically 4-6 weeks for standard orders, but it may vary depending on stock availability and order quantity. Check with your distributor for current lead times.
Stock availability for VL53L0CXV0DH/1 varies by distributor. As of 2026-08-06, DigiKey and Mouser typically have stock, but it is recommended to check their websites for real-time inventory.
The best drop-in replacement for VL53L0CXV0DH/1 is the VL53L0CXV0DH/1 itself, but the VL53L1CXV0FY/1 is a pin-compatible alternative with extended range. For cross-brand, the Broadcom APDS-9960 is not pin-compatible, so the VL53L0CXV0DH/1 is the primary choice.
Yes, the VL53L1CXV0FY/1 is a drop-in replacement for VL53L0CXV0DH/1. Both share the same package and pinout, but the VL53L1 offers a longer range of up to 4 meters and higher accuracy, making it a suitable upgrade.
The VL53L1CXV0FY/1 has a longer measurement range (up to 4m) and faster ranging speed compared to the VL53L0CXV0DH/1 (up to 2m). Both are pin-compatible and share the same package, but the VL53L1 has a different register map and requires updated software.
Choose VL53L0CXV0DH/1 when you need a cost-effective solution for short-range detection (up to 2m) and have a simpler software requirement. Choose VL53L1CXV0FY/1 for longer range, faster measurements, or when you need higher accuracy at distance.
The VL53L0CXV0DH/1 datasheet is available for download from the STMicroelectronics website at https://www.st.com/resource/en/datasheet/vl53l0x.pdf. It contains full specifications, pinout, and application notes.
The VL53L0CXV0DH/1 pinout is detailed in the datasheet on page 8. The module has 6 pins: AVDD, GND, SDA, SCL, XSHUT, and GPIO1. The pinout is identical to the VL53L0X module.
The VL53L0CXV0DH/1 operates at 2.8V, measures 30mm to 2000mm with ±3% accuracy, uses I2C interface, has a 25-degree field of view, and consumes 19mA during ranging. It is packaged in a 4.4x2.4x1.0mm optical module.
The VL53L0CXV0DH/1 can be replaced by the VL53L1CXV0FY/1 from STMicroelectronics, which is pin-compatible and offers longer range. For cross-brand, the Broadcom APDS-9960 is not pin-compatible, so it is not a drop-in replacement.
Yes, the VL53L0CXV0DH/1 is a variant of the VL53L0X module. The suffix 'CXV0DH' indicates a specific optical and packaging configuration, but the electrical and functional specifications are identical.
The best STMicroelectronics equivalent for VL53L0CXV0DH/1 is the VL53L1CXV0FY/1, which is pin-compatible and offers extended range. For a lower-cost option, the VL53L0CXV0DH/1 itself is the standard choice.
