View Datasheet →VL53L0CXV0DH/1 Maximum Ratings & Electrical Characteristics
| Measurement Range | 30 mm to 2000 mm |
| Accuracy | ±3% (typical) |
| Supply Voltage | 2.8 V |
| Operating Current | 19 mA (typical) |
| Standby Current | 5 uA (typical) |
| Interface | I2C (up to 400 kHz) |
| Field of View | 25 degrees |
| Measurement Time | 30 ms (typical) |
| Wavelength | 940 nm (VCSEL) |
| Package | Optical module 4.4 x 2.4 x 1.0 mm |
| Operating Temperature | -20C to +70C |
| Storage Temperature | -40C to +85C |
| RoHS Status | Compliant |
| Mounting Type | Surface Mount |
| Output Type | Digital (I2C) |
VL53L0CXV0DH/1 Pin Configuration
| Pin 1 | AVDD — Power supply (2.8V) |
| Pin 2 | GND — Ground |
| Pin 3 | SDA — I2C data line |
| Pin 4 | SCL — I2C clock line |
| Pin 5 | XSHUT — Shutdown (active low) |
| Pin 6 | GPIO1 — Interrupt output |
Safe Operating Area (SOA) & Thermal Characteristics
No official SOA curve available for this component. Always operate within absolute maximum ratings specified in the datasheet. Ensure adequate cooling and derate as needed.
Typical Applications
VL53L0CXV0DH/1 is suitable for 6 applications: Smartphone Proximity Detection, Robotics Obstacle Avoidance, Drone Landing Assistance, Automatic Faucets, Vacuum Cleaner Navigation, Consumer Electronics.
