AD7175-8BCPZ-RL7 Overview
A sigma-delta ADC is a type of analog-to-digital converter that uses oversampling and noise shaping to achieve high resolution. It is part of the ADC family, which falls under data converters, a subset of analog-to-digital conversion in the broader category of mixed-signal ICs. Sigma-delta ADCs are known for their excellent linearity and low noise, making them ideal for precision measurement applications.
Key features of the AD7175-8 include 24-bit resolution, 8 differential or 16 single-ended inputs, and a maximum output data rate of 250 kSPS. It operates from a 2.5 V to 5.5 V analog supply and a 2.3 V to 5.5 V digital supply. The device offers a programmable digital filter, allowing trade-offs between output data rate and noise. It also includes a 24-bit sigma-delta modulator, a digital filter, and a serial interface that supports SPI. The AD7175-8 is available in a 40-lead LFCSP-WQ (6x6 mm) package, which is RoHS3 compliant and has an MSL rating of 3 (168 hours).
The AD7175-8 uses a high-performance sigma-delta architecture with a digital filter that can be configured for various output data rates and settling times. The device includes a multiplexer that allows up to 16 single-ended or 8 differential inputs. It also features an internal oscillator, eliminating the need for an external clock. The ADC provides a 24-bit output with a noise-free resolution of up to 24 bits at low data rates. The device is specified for operation over the industrial temperature range of -40°C to +105°C.
Typical applications for the AD7175-8 include process control, industrial automation, temperature and pressure measurement, and precision data acquisition systems. Its high resolution and low noise make it suitable for applications requiring accurate measurement of slow-changing signals. The device is also used in weigh scales, medical instrumentation, and energy monitoring.
When designing with the AD7175-8, it is important to provide adequate decoupling on the power supply pins and to use a clean analog ground plane. The reference inputs should be driven by a low-impedance source to maintain accuracy. The SPI interface should be isolated from noisy digital circuitry to prevent noise coupling into the analog section.
