TMS320F28027PTT Visão geral
A microcontroller (MCU) is a single-chip computer integrating a processor core, memory, and peripherals for embedded control. The C2000 Piccolo family sits within TI's digital signal controller hierarchy: C28x DSP core -> Piccolo MCU -> C2000 real-time control MCU -> digital signal processor (DSP) -> semiconductor integrated circuit. These devices are purpose-built for real-time closed-loop control such as digital power conversion and motor drive.
Key features include the high-performance static CMOS C28x core with 32x32-bit multiply-accumulate (MAC) capability, an internal voltage regulator enabling single-rail 3.3V operation, highly integrated control peripherals including ePWM modules, a 12-bit ADC, and eCAP/eQEP units, plus on-chip flash with code security. Per TI, the F2802x family is code-compatible with previous C28x-based code while providing a high level of analog integration in low pin-count devices.
Architecturally, the device combines Harvard-bus C28x CPU performance with fast interrupt latency, making it suitable for control loops executing at tens to hundreds of kHz. The integrated voltage regulator reduces external power-supply complexity, and the 48-pin LQFP keeps PCB footprint compact while retaining sufficient GPIO and peripheral pinout for typical control designs.
Typical applications include digital motor control (BLDC, PMSM, ACIM), solar inverters and power factor correction, digital LED lighting power supplies, and industrial automation control nodes. The 60 MHz core and dedicated PWM peripherals make it a cost-effective entry point into the C2000 ecosystem.
Design consideration: the F2802x is a 3.3V device; ensure all GPIO are level-compatible with external logic, and use TI C2000ware with the LaunchPad LAUNCHXL-F28027 for rapid prototyping before committing to PCB layout.
This page synthesizes distributor pricing, drop-in alternatives, and practical design notes not found in the manufacturer datasheet.
Alternativas drop-in para TMS320F28027PTT — mesmo encapsulamento, compatível pino a pino. Peças de encapsulamento diferente que exigem retrabalho na PCB são excluídas.
Variantes desta série
Modelos da mesma série compatíveis como drop-in com TMS320F28027PTT (mesmo formato e footprint) — diferindo em Supply Voltage, Package, Flash Memory, Operating Temperature, SRAM.
Ferramenta de comparação rápida — selecione peças alternativas para comparação lado a lado:
TMS320F28027FPTT
✅ Drop-In✓ Em estoque
$1 / unidade
Ver ficha técnica →TMS320F28027PTS
✅ Drop-In📋 Alternativa de referência (fora do catálogo)
TMS320F28026PTT
✅ Drop-In📋 Alternativa de referência (fora do catálogo)
TMS320F28022PTT
✅ Drop-In📋 Alternativa de referência (fora do catálogo)
TMS320F28027PTT Classificações máximas e características elétricas
| Core Processor | C28x Piccolo (C2000) |
| Core Size | 32-Bit |
| Frequência máxima de clock | 60 MHz |
| Flash Memory | 64KB (32K x 16) |
| SRAM | 12KB |
| Tensão de alimentação | 3.3 V (single-rail via internal regulator) |
| Encapsulamento | 48-LQFP (7x7 mm) |
| Tipo de montagem | Surface Mount |
| Temperatura de operação | -40C to +85C |
| Peripherals | ePWM, eCAP, eQEP, internal voltage regulator |
| ADC Resolution | 12-bit |
| Multiply-Accumulate | 32x32-bit MAC |
| Nível MSL | 2 (260C, 1 year) |
| Status RoHS | Compliant |
| Code Compatibility | C28x code-compatible with previous C28x-based devices |
Guia de Configuração de Pinos do TMS320F28027PTT 48-lqfp (7x7 mm)
Configuração de pinos para TMS320F28027PTT (pacote 48-lqfp (7x7 mm)). Este CI digital inclui GPIO, interfaces de comunicação (UART, SPI, I2C) e pinos de alimentação. Consulte o datasheet do fabricante para funções alternativas dos pinos e opções de configuração. Essencial para projeto de sistemas embarcados e layout de PCB.
Nenhum dado detalhado de pinagem disponível para TMS320F28027PTT.
Consulte a ficha técnica para a configuração completa dos pinos.
Aplicações típicas
TMS320F28027PTT é adequado para 6 aplicaçãos: Digital Motor Control, Solar Inverters and Power Factor Correction, Digital LED Lighting Power Supplies, Industrial Automation Control Nodes, Battery Chargers and DC-DC Conversion, Embedded Learning and C2000 Prototyping.
Digital Motor Control
The TMS320F28027PTT fits BLDC, PMSM, and ACIM motor drives because its 60 MHz C28x core with 32x32-bit MAC executes field-oriented control (FOC) loops at tens of kHz while multiple ePWM modules generate complementary six-step or SVM waveforms with hardware dead-band. The 12-bit ADC samples phase currents and bus voltage for closed-loop current control, and eQEP decodes incremental encoder feedback. In a typical topology the MCU drives a three-phase gate-driver stage from 3.3V logic, with the single-rail internal regulator simplifying the power tree. For sensorless designs, the InstaSPIN-enabled TMS320F28027FPTT adds motor auto-detection ROM on the identical footprint.
Recomendado
Solar Inverters and Power Factor Correction
The TMS320F28027PTT suits solar micro-inverter and PFC front-end control where deterministic interrupt latency and fast control loops matter more than general-purpose throughput. Its ePWM modules implement phase-shifted or interleaved PWM stages, the 12-bit ADC samples input/output voltage and inductor current for MPPT and current-shaping loops, and eCAP captures grid frequency events. Running at 60 MHz, the C28x core closes MPPT and current loops in software without a separate controller. The single 3.3V rail from the internal regulator eases isolated-supply design. For grid-tie designs requiring larger memory or CLA accelerators, the TMS320F28034QPNTQ1 offers an upgrade path within the same C2000 architecture.
Recomendado
Digital LED Lighting Power Supplies
In digital LED drivers, the TMS320F28027PTT provides constant-current and dimming control with the precision of a DSP-class core: ePWM outputs drive buck or boost LED stages with programmable resolution and shadow registers for flicker-free dimming, while the 12-bit ADC closes the current loop directly from the current-sense shunt. The 64KB flash stores multi-string sequencing and communication stacks, and the 3.3V single-rail operation with internal regulator reduces BOM count in compact lamp geometries. Control loops at tens of kHz achieve better dynamic response than analog-only drivers, supporting 0-10V, PWM, and DALI-style dimming interfaces on SCI/GPIO pins.
Recomendado
Industrial Automation Control Nodes
As a control node in factory automation, the TMS320F28027PTT combines real-time closed-loop capability with serial connectivity: SCI (UART), SPI, and I2C peripherals link to sensors, HMIs, and field-bus transceivers, while eQEP interfaces rotary encoders for position feedback and eCAP measures pulse-train inputs. The 60 MHz C28x core processes PID loops with deterministic timing at rates unattainable by general-purpose MCUs in this price class. The 64KB flash accommodates protocol stacks and calibration tables, and the -40C to +85C operating range suits cabinet and floor-level environments. C2000Ware driver libraries shorten software bring-up on custom carrier boards.
Recomendado
Battery Chargers and DC-DC Conversion
The TMS320F28027PTT governs digitally controlled battery chargers and DC-DC converters where adaptive charging profiles and telemetry are required. ePWM with cycle-by-cycle current limiting protects the power stage, the 12-bit ADC monitors cell voltage, current, and temperature for CC/CV/profiled charging algorithms, and software-defined control laws can be field-updated via the on-chip flash - a key advantage over fixed analog controllers. The Harvard-bus C28x core maintains stable switching frequencies into the hundreds of kHz, and the internal voltage regulator lets the controller share the 3.3V auxiliary rail. SCI/SPI ports provide charger-to-host telemetry for fleet management systems.
Recomendado
Embedded Learning and C2000 Prototyping
The TMS320F28027PTT is the MCU mounted on TI's LAUNCHXL-F28027 LaunchPad, making it the canonical entry point for learning C2000 real-time control. Engineers and students can prototype motor-control, power-conversion, and digital-control algorithms using C2000Ware, Code Composer Studio, and the free controlSUITE libraries, then migrate designs directly to the identical 48-LQFP device on production PCBs - the same silicon on the LaunchPad removes porting risk. The 64KB flash is ample for teaching examples, and JTAG debugging via the onboard XDS100 emulator provides full breakpoint and memory visibility during algorithm development.
Recomendado
Resumo dos produtos recomendados
Dados de referência de engenharia para TMS320F28027PTT — comparação, orientação de projeto e informações de conformidade.
Guia de seleção
Comparação com alternativas
| Parâmetro | Este produto | TMS320F28027FPTT | TMS320F28027PTS | TMS320F28026PTT | TMS320F28022PTT |
|---|---|---|---|---|---|
| Package | 48-LQFP (7x7 mm) | 48-LQFP (7x7 mm) - same | 48-LQFP (7x7 mm) - same | 48-LQFP (7x7 mm) - same | 48-LQFP (7x7 mm) - same |
| Brand | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Core / Clock | C28x 32-bit, 60 MHz | C28x 32-bit, 60 MHz | C28x 32-bit, 60 MHz | C28x 32-bit, 60 MHz | C28x 32-bit, 60 MHz |
| Flash Memory | 64KB (32K x 16) | 64KB (32K x 16) | 64KB (32K x 16) | 32KB | 64KB |
| SRAM | 12KB | 12KB | 12KB | 6KB | 12KB |
| Special ROM Contents | Standard boot ROM | InstaSPIN motor firmware ROM | Standard boot ROM (no InstaSPIN) | Standard boot ROM | Standard boot ROM |
| Pin Compatibility | Reference (48-LQFP) | Pin-to-pin identical | Pin-to-pin identical | Pin-to-pin identical | Pin-to-pin identical |
| Supply Voltage | 3.3 V (internal regulator) | 3.3 V (internal regulator) | 3.3 V (internal regulator) | 3.3 V (internal regulator) | 3.3 V (internal regulator) |
Principais diferenciais
- Lowest-cost entry into the C2000 real-time control ecosystem (vs TMS320F28035PNT)
- Largest memory in its pin-compatible subfamily (vs TMS320F28026PTT)
- Single-rail operation via integrated voltage regulator (vs TMS320F28335PTPQ)
Notas de projeto
The F2802x integrates a core voltage regulator enabled via the VREGENZ pin, allowing single-rail 3.3V operation. When the internal regulator is enabled, it supplies the 1.x V core from VDDIO - do not also drive VDD externally, or contention results. If you bypass the regulator (VREGENZ pulled to disable), supply the core rail externally and observe the power-up sequencing specified in the datasheet. Place 0.1uF decoupling capacitors at every VDDIO/VDD pin pair and one bulk 10uF per supply domain.
Use the 48-LQFP (7x7 mm) land pattern per IPC guidelines with the standard 0.5 mm pitch footprint. Keep the 12-bit ADC analog input traces short and away from ePWM switching nets; add an RC anti-alias filter on current-sense channels. Ground the ADC reference properly and dedicate an analog ground region connected to the digital ground at a single point. Reserve JTAG header access (TRST, TDI, TMS, TDO, TCK) in production boards for in-system flash programming with an XDS100 emulator.
The TMS320F28027PTT has 64KB flash versus 32KB on the TMS320F28026PTT - verify code size before substituting the smaller variant as a cost reduction. The F-suffix F28027FPTT differs only in InstaSPIN ROM contents; do not assume the standard part runs InstaSPIN motor examples. All GPIO are 3.3V only and are not 5V tolerant, so level-shift any 5V logic interfaces. Also confirm MSL 2 handling: floor-life after opening the moisture-barrier bag is 1 year before reflow.
At 60 MHz the C28x core's external clock net is modest, but ePWM edges driving gate drivers carry fast edges that can couple into the 12-bit ADC. Route PWM traces with series termination near the MCU if traces exceed a few centimeters, and separate the analog ADC input channel routing on an inner layer with ground guard traces. Use XCLKIN with a clean oscillator source rather than an RC network when ADC accuracy matters.
Informações de conformidade
RoHS compliant and MSL 2 (260C, 1 year) per PartGenie compliance data. REACH, halogen-free, and conflict-minerals status not stated in available data - confirm on TI's product page.
