Motor Drivers
Products (104)
6EDL7141XUMA1 - 60V 3-Phase BLDC Gate Driver IC | Infineon
The Infineon 6EDL7141XUMA1 is a three-phase, half-bridge-based smart gate driver IC designed for battery-supplied BLDC and PMSM motor control. It integrates three half-bridge drivers capable of sourcing/sinking 1.5 A peak gate current, operates from a 5.5 V to 60 V recommended supply, supports programmable driving voltage, and is housed in a PG-VQFN-48-78 power package with exposed pad. The device includes three current-sense amplifiers for bi-directional low-side current sensing with programmable gain and supports R_DSON sensing through internal phase-node connections. A three-phase gate driver IC (sometimes called a "smart gate driver" or "motor driver front end") sits between an MCU and the three half-bridges of N-channel MOSFETs that commutate a BLDC motor stator. By placing all six gate-drive channels, charge-pump bootstrap supplies, dead-time control, current-sense conditioning and protection logic into one IC, the designer replaces ~30 discrete parts and gains digital SPI configurability. The 6EDL7141 belongs to Infineon's MOTIX family and targets battery-powered motion control where PCB area, efficiency and firmware configurability are paramount. Key differentiating features include 1.5 A peak source/sink gate-drive current with programmable drive voltage, integrated 3.3 V / 5 V-compatible current-sense amplifiers with low noise and fast settling time, bi-directional low-side current sensing with programmable gain, R_DSON-based phase-current sensing via internal connections, SPI-configurable parameters, integrated charge pump and bootstrap diodes, and built-in protection (overcurrent, undervoltage, gate-fault detection). The PG-VQFN-48-78 package combines a low-Rth power pad with compact outline. The architecture uses three independent high-side/low-side channels with integrated bootstrap diodes and a charge pump to drive the high-side N-MOSFETs at 100% duty cycle. Internal logic provides configurable dead-time, adaptive shoot-through protection, and a SPI interface exposing >50 parameters (gain, blanking time, current-trigger thresholds, gate-drive strength, fault masks). Typical applications include cordless power tools (drills, impact drivers, saws), battery gardening tools (hedge trimmers, leaf blowers), automated guided vehicles and robotics, e-bike and e-scooter traction inverters, drone ESCs, and home appliances with BLDC motors (vacuum cleaners, washing-machine drum drives, range-hood fans). When designing with this part, allocate the bottom exposed pad to at least 1 sq-inch of copper with thermal vias to dissipate charge-pump and gate-driver losses, and place the bootstrap capacitors (typically 100 nF ceramic) as close as possible to the BST pins. Configure the SPI registers at startup before enabling the outputs - the device will not drive if the digital core is uninitialized. This page synthesizes distributor pricing (DigiKey/Mouser), SPI-register-aware drop-in alternatives within Infineon's MOTIX 6EDL714x family, and practical design notes not consolidated in the manufacturer datasheet.
BTM9011EPXUMA1 - 10A Full-Bridge Motor Driver, 7-18V | Infineon
The Infineon BTM9011EPXUMA1 is a 10 A full-bridge motor driver IC with integrated power MOSFETs and SPI interface, housed in a 14-pin PG-TSDSO-14 package with exposed pad for enhanced thermal performance. The device integrates a monolithic BCD (Bipolar-CMOS-DMOS) full-bridge designed for automotive motor drive applications such as door locks, latches, and small DC brushed-motor loads. A full-bridge motor driver IC (also known as an H-bridge) is a topology that uses four switching elements arranged in an H configuration to drive a DC or bipolar stepper motor in both directions from a single supply rail. The full-bridge sits within the broader hierarchy: motor driver IC -> motion controller -> power management IC -> semiconductor. By integrating the four MOSFETs plus gate drive, charge pump, current sense, and protection into one monolithic die, the BTM9011EPXUMA1 eliminates dozens of discrete components that an equivalent discrete solution would require. Key features include a typical path resistance of 175 mΩ at 25 °C, pulse current capability of 5.2 A for tpulse ≤ 1 s at 85 °C (4.2 A for tpulse ≤ 10 s at 85 °C), a normal supply voltage range of 7 V to 18 V with an extended range of 4.5 V to 40 V, and a minimum current limitation. PWM operation is supported up to 20 kHz. The SPI interface enables diagnostic readout and parameter configuration, while the integrated protection set includes overtemperature, overcurrent, and undervoltage lockout. The device is implemented in BCD technology and qualified to AEC-Q100 for automotive use. Compared with discrete MOSFET bridges, the integrated full-bridge cuts PCB area by roughly 60%, reduces parasitic loop inductance, and simplifies EMI compliance thanks to tighter gate-driver timing and shorter power paths. Typical applications include automotive door-lock actuators, trunk latches, fuel-flap actuators, seat adjusters, mirror-fold motors, and HVAC flap control. The combination of 10 A current limit, 20 kHz PWM, and SPI diagnostics makes the part well suited to body-electronics modules that must report fault status to a central ECU. When designing with this part, place a low-ESR 100 nF + 10 µF ceramic bypass on VS as close to the IC as possible, and tie the exposed pad to a continuous ground copper pour of at least 100 mm² to stay within the thermal envelope at full 10 A load. The SPI bus should be pulled up to VIO and isolated from the motor phase traces with a ground guard ring to avoid conducted-noise coupling during PWM transitions.
BTM9020EPXUMA1 - Full-Bridge 20A Motor Driver IC | Infineon MOTIX
The Infineon BTM9020EPXUMA1 is a fully integrated full-bridge driver IC designed for brushed DC (BDC) motors, housed in a PG-TSDSO-14 package. It combines four power MOSFETs in an H-bridge topology with integrated charge pump and PWM control, delivering typical path resistance of 84 mΩ at 25 °C and supporting a supply voltage range of 7 V to 18 V (extended 4.5 V to 40 V). Pulse current capability reaches 8.8 A for pulses ≤ 1 s at 85 °C and 6.9 A for pulses ≤ 10 s at 85 °C, making it well suited to locks, latches, and small body-motor loads. A brushed DC motor driver is an integrated power stage that switches the polarity of voltage across a DC motor winding to control direction, speed, and torque. It belongs to the broader family of motor-driver ICs, which sit hierarchically below power management ICs and alongside gate drivers, half-bridge drivers, and three-phase motor drivers. The full-bridge (H-bridge) topology in particular enables bidirectional control of a single winding using only two logic-level inputs, eliminating the need for external discrete MOSFETs and gate-drive circuitry. Key features include a 20 A current limit, 20 kHz PWM frequency for quiet operation, built-in protection (overcurrent, overtemperature, undervoltage), and a logic-level interface compatible with 3.3 V and 5 V microcontrollers. The exposed pad of the PG-TSDSO-14 package provides a low thermal resistance path, enabling sustained high-current operation on a standard FR-4 PCB. Architecturally, the BTM9020EPXUMA1 uses four N-channel power MOSFETs in an H-bridge driven by an internal charge pump that generates the high-side gate supply. The integrated charge pump eliminates external capacitors for the high-side drive, simplifying PCB layout and reducing BOM cost. This makes the device a true single-chip motor driver solution for space-constrained automotive body-electronics modules. Typical applications include automotive door-lock and door-latch actuators, sunroof and window-lift motors, mirror-adjust actuators, and other small BDC motors in body-electronics systems. The AEC-Q100 qualification and wide supply-voltage range make it especially suitable for 12 V automotive board nets and 24 V truck systems. When designing with this part, ensure adequate copper area under the exposed thermal pad for heat dissipation, and place the supply bypass capacitor as close as possible to the VBB pin. The logic inputs are TTL-compatible but should be kept clean to avoid spurious direction changes during PWM transitions. This page synthesizes Infineon distributor pricing, drop-in MOTIX-family alternatives, and practical PCB design notes not found in the manufacturer datasheet alone, helping sourcing engineers select a verified replacement and helping design engineers shorten first-pass bring-up.
BTM9021EPXUMA1 - 8.8A Full-Bridge BDC Motor Driver | Infineon
The Infineon BTM9021EPXUMA1 is a fully integrated full-bridge motor driver IC for brushed DC (BDC) motors, delivering up to 8.8 A pulse current (tpulse <= 1 s at 85 °C) and 6.9 A continuous pulse current (tpulse <= 10 s at 85 °C) in a 14-pin PG-TSDSO package with exposed pad. It features a typical path resistance of 84 mΩ at 25 °C, an SPI diagnostic interface, and AEC-Q100 qualification for automotive applications. What is a brushed DC motor driver? A brushed DC motor driver is an integrated power stage that switches the current through a BDC motor's windings using internal MOSFETs in an H-bridge topology. It belongs to the motor-driver category within power management and power-semiconductor ICs, sitting hierarchically under power management IC -> motor driver -> brushed DC motor driver -> integrated full-bridge. By integrating four power MOSFETs, gate drivers, protection, and (in this case) an SPI configuration/diagnostic interface, the part eliminates the need for discrete H-bridges, optocouplers, and external current-sense amplifiers. Key features include a normal supply voltage range of 7 V to 18 V and an extended supply range of 4.5 V to 40 V for cold-crank and load-dump survival in 12 V automotive systems. Integrated protection covers overtemperature, overcurrent, undervoltage, and short-circuit conditions. The SPI interface provides status feedback, PWM control configuration, and current-limit adjustment. Typical path resistance of 84 mΩ at 25 °C keeps conduction losses low, enabling higher continuous current from a thermally limited 14-pin exposed-pad TSSOP. Technically, the BTM9021 uses an N-channel MOSFET H-bridge driven by a charge-pump-generated gate supply. The device supports PWM frequencies up to the limit defined in the datasheet and offers configurable slew-rate control to trade EMI against switching losses. The internal current limit is programmable via SPI, and the diagnostic register reports fault flags such as open-load, short-to-ground, and overtemperature pre-warning. Typical applications include automotive throttle-body actuators, HVAC blower motors, fuel-pump drivers, and small body-comfort loads such as seat-position adjusters and mirror-fold mechanisms. Industrial uses include 24 V valve actuators and small robotic drives. The AEC-Q100 grade makes it especially well suited for under-the-hood and body-electronics modules where the supply rail experiences cranking transients. When designing with the BTM9021, observe the thermal limits of the PG-TSDSO-14 package. At 8.8 A pulse and a VIN of 13.5 V, the H-bridge conduction loss is roughly (2 x 84 mΩ) x I² per MOSFET pair; sufficient copper on the exposed pad is essential. The 4.5 V to 40 V extended range allows direct connection to a 12 V automotive bus with no pre-regulation. This page synthesizes distributor pricing, AEC-Q100 drop-in alternatives, and PG-TSDSO-14 thermal design notes that go beyond the manufacturer datasheet's headline specs, giving a one-stop engineering reference for motor-drive selection.
BTN8982TAAUMA1 - 55A Half-Bridge Motor Driver, 40V | Infineon
The Infineon BTN8982TAAUMA1 is an integrated high-current half-bridge motor driver from the NovalithIC family, rated for 40 V operation and 55 A peak current, housed in a 7-pin PG-TO263-7-1 (D2PAK with tab) surface-mount package. It combines a P-channel high-side MOSFET, an N-channel low-side MOSFET, and a fully integrated driver IC in a single exposed-tab package, providing a complete half-bridge that requires only an external logic signal for PWM control of brushed DC and BLDC motors. A half-bridge driver is a power-stage building block that uses one high-side and one low-side switch to drive a motor terminal from a single DC rail. Two BTN8982TA devices are commonly paired to form a full H-bridge for bidirectional brushed DC motors, or used in three-phase configurations for BLDC motors. Half-bridge drivers belong to the broader category of motor/Motion/Ignition PMICs (Power Management ICs), which sit under the umbrella of integrated power semiconductors and motor-driver ICs. Key features of the BTN8982TA include: 5.5 V to 40 V supply voltage range, 50 A nominal continuous load current, integrated charge pump for the high-side gate drive, current-limit protection set around 55 A, status flag output, slew-rate-adjustable switching, and over-temperature shutdown. The NovalithIC construction eliminates the need for an external bootstrap capacitor or gate-drive supply, simplifying PCB layout compared to discrete MOSFET half-bridges. The architecture integrates a charge pump, level shifter, gate drivers, dead-time generation, current sense, and protection logic on the same silicon as the power MOSFETs. This co-integration reduces parasitic inductance between driver and FET, lowering switching losses and improving EMI performance versus discrete solutions, at the cost of a fixed set of protection features that cannot be user-programmed. Typical applications include brushed DC motors in automotive body electronics (e.g., window lift, seat adjust, sunroof), e-bike and e-scooter traction drives, industrial pumps and fans, robotic actuators, and small BLDC motor control where two or three BTN8982TA devices form a complete inverter. The 40 V rating suits 12 V and 24 V automotive bus systems with generous transient margin. When designing with the BTN8982TA, ensure the exposed thermal pad is soldered to a sufficiently large copper pour - the device is capable of dissipating tens of watts under stall conditions. Add adequate bulk capacitance on the supply rail and follow Infineon reference layout recommendations to keep switching transients within EMI limits. This page synthesizes distributor pricing, drop-in NovalithIC alternatives, and practical design notes that go beyond the bare manufacturer datasheet.
BTN9960LVAUMA1 - 9.7mOhm 35A Half-Bridge Motor Driver | Infineon
The Infineon BTN9960LVAUMA1 is an integrated high-current half-bridge motor driver from the MOTIX (NovalithIC) family, featuring a P-channel high-side MOSFET and an N-channel low-side MOSFET co-packaged with a driver IC in a PG-HSOF-7-1 surface-mount package. It delivers a typical path resistance of 9.7 mOhm, supports up to 35 A overcurrent detection, and operates from a supply voltage range of 8 V to 18 V (with maximum ratings extending to 40 V), making it ideal for 12 V DC motor drive applications. What is a half-bridge motor driver? A half-bridge is the fundamental switching element in DC motor control, consisting of one high-side and one low-side switch that alternately connect a motor terminal to the supply rail or to ground. By PWM-modulating the switching, the average voltage applied to the motor (and therefore its speed and torque) is controlled. The BTN9960LVAUMA1 is part of a wider product taxonomy: half-bridge driver -> integrated motor driver -> motor control IC -> power management IC -> semiconductor. Two such half-bridges can be combined externally to drive a brushed DC motor in H-bridge configuration, or three are used for brushless DC (BLDC) motor commutation. Key features include AEC-Q100/Q006 qualification at Grade 1 for automotive use, integrated under-voltage, over-current, short-circuit, and over-temperature protection, dead-time control, and an enable/shutdown input. The P-channel high-side switch eliminates the need for a charge pump, reducing EMI and simplifying PCB layout. Logic-level inputs interface directly with microcontrollers, and the device includes interleaved conduction (shoot-through) protection to safeguard against cross-conduction events. The BTN9960LVAUMA1 leverages Infineon's proprietary NovalithIC three-chip integration: the high-side PMOS, low-side NMOS, and a smart driver IC are co-packaged to minimize parasitic inductance and maximize power density. With operating junction temperatures from -40C to +150C, it suits under-hood automotive and industrial environments. The exposed pad package provides a low thermal resistance path for high-current switching applications. Typical applications include 12 V brushed DC motor drivers for automotive body electronics (window lift, sunroof, seat adjustment, fans, pumps), electric power steering (EPS) auxiliary systems, industrial actuators, e-bike controllers, and small BLDC motor driver stages. It is also used in relay replacement, solenoid driving, and high-current LED arrays where PWM dimming is required. When designing with this device, ensure that the PG-HSOF-7-1 thermal pad is soldered to a sufficiently large copper pour to keep junction temperature within safe limits under sustained load. The enable pin should be controlled cleanly to avoid spurious switching, and the dead-time logic must be respected in external H-bridge configurations. Pair with a microcontroller such as Infineon TLE987x or AURIX for automotive motor control. This page synthesizes distributor pricing from DigiKey, Mouser, LCSC, and Octopart, plus drop-in MOTIX alternatives, comparison tables, and practical design notes not found in the manufacturer datasheet.
BTN9970LVAUMA1 - Integrated Half-Bridge 9.7mΩ 60A NovalithIC+ | Infineon
The Infineon BTN9970LVAUMA1 is an integrated high-current half-bridge from the NovalithIC+ family, combining one p-channel high-side MOSFET and one n-channel low-side MOSFET with a monolithic driver IC in a single PG-HSOF-7-1 surface-mount package. It targets PWM-controlled brushed DC motor drive applications up to 60 A peak current, with a typical R_DS(on) of 9.7 mΩ per switch leg. What is a NovalithIC? A NovalithIC is Infineon's category of integrated power half-bridges that co-package the high-side switch, low-side switch, gate driver, and protection logic into one thermally efficient package. The use of a p-channel high-side MOSFET eliminates the need for an external charge pump, which simplifies PCB layout and minimizes electromagnetic emissions compared to traditional n-channel high-side designs. Within the broader taxonomy, NovalithIC+ parts sit between discrete MOSFET half-bridges and full H-bridge motor driver ICs. Key features include a 9.7 mΩ typical on-state resistance per MOSFET, integrated current sensing with 60 A detection capability, built-in protection (overtemperature, overcurrent, undervoltage, short-circuit), and direct logic-level PWM inputs. The package exposes the source pads for direct PCB cooling, eliminating external heatsinks in many 12 V motor applications. From an architectural standpoint, the BTN9970LV integrates the charge-pump-free p-channel high-side to reduce quiescent power and EMI. The on-chip current sense resistor (or shunt emulation) feeds an IS pin proportional to load current, enabling closed-loop torque control without external shunts. Logic inputs are TTL-compatible and accept 3.3 V or 5 V microcontroller signals. Typical applications include brushed DC motor control in 12 V automotive subsystems (HVAC blowers, fuel pumps, window lifters), small industrial pumps and valves, robot actuators, and battery-powered tools. The wide operating voltage range (typically 5 V to 28 V, with transient tolerance up to 40 V) also supports 24 V industrial rails. Designers should observe the PG-HSOF-7-1 land-pattern geometry with sufficient copper area on both drain pads for continuous high-current operation. The exposed lead-frame pads must be soldered to the PCB for both electrical grounding and thermal dissipation. According to the Infineon datasheet, derating begins above 25 A continuous per leg without additional cooling. This page synthesizes distributor pricing from 7 distributors, same-brand drop-in alternatives in the same NovalithIC+ family, and practical PCB/thermal design notes not found in the manufacturer datasheet alone.
BTN9990LVAUMA1 - 60V Half-Bridge Motor Driver | Infineon
The Infineon BTN9990LVAUMA1 is a 60 V integrated high-current half-bridge driver housed in a PG-HSOF-7-1 exposed-pad SMD package. It combines one low-RDS(on) N-channel power MOSFET per switch position with gate-drive, charge-pump, and protection logic to drive brushed DC motors, solenoids, and other inductive loads up to tens of amps continuous. The part is part of Infineon's MOTIX™ family of integrated half-bridge products designed for space-constrained automotive and industrial power switching. A half-bridge is a power-electronics topology that switches a load between a high-side supply rail and ground using two MOSFETs in a push-pull arrangement; the half-bridge is the building block of H-bridge DC motor drivers, three-phase BLDC inverters, and synchronous buck converters. By integrating the power stage into a single exposed-pad package, the BTN9990LVAUMA1 reduces PCB area, simplifies thermal design, and minimizes parasitic loop inductance that otherwise causes voltage overshoot during switching. Key features of the BTN9990LVAUMA1 include integrated charge-pump for 100% duty-cycle high-side operation, under-voltage lockout (UVLO) on both the logic and gate-drive supplies, over-current protection, and an exposed thermal pad that delivers a low thermal resistance to the PCB copper pour. Logic-level inputs interface directly to 3.3 V or 5 V microcontrollers, eliminating the need for external level shifters in most 12 V automotive applications. Typical applications include brushed DC motor control in automotive body modules (window lift, seat adjustment, tailgate), industrial relay and solenoid replacement, LED driver power stages, and small BLDC half-bridge stages where each phase is built from two of these parts. The exposed-pad package allows the heat of the switching losses to be conducted directly into the PCB copper, removing the need for an external heatsink in most well-designed boards. When designing with this device, follow Infineon's PG-HSOF-7-1 PCB layout recommendations: place input and motor ceramic bypass capacitors as close to the package as possible, and provide at least 6 cm² of 2 oz copper on the opposite side of the board tied to the exposed pad. The motor supply (VS) and logic supply (VCC) should be decoupled separately to prevent logic reset during motor current transients.
DRV10983QPWPRQ1 - 3.5A Sensorless BLDC Driver AEC-Q100 | TI
The Texas Instruments DRV10983QPWPRQ1 is an automotive-grade, three-phase sensorless BLDC motor driver designed for 12-V battery systems. It integrates power MOSFETs delivering up to 3.5-A peak current and supports sensorless sinusoidal control via I2C or PWM interfaces. Housed in a 24-pin HTSSOP (PWP) package, it operates from -40C to +125C junction temperature, targeting under-hood automotive applications. A BLDC motor driver is a power management IC that controls commutation of brushless DC motors without mechanical brushes. The DRV10983-Q1 belongs to the sensorless motor driver family, using back-EMF sensing to determine rotor position and eliminating Hall sensors, which reduces system cost and improves reliability. As a motor driver, it sits in the broader power management IC hierarchy, specifically motor control ICs. Key features include the integrated 3.5-A peak power stage, a supply range of 8 V to 28 V (24-V battery load-dump tolerant), and dual I2C and PWM control interfaces. Sinusoidal drive waveforms minimize acoustic noise and vibration versus trapezoidal (block) commutation. Protection features include overcurrent, overtemperature shutdown, undervoltage lockout, and lock detection. AEC-Q100 automotive qualification ensures robust performance. Technically, the DRV10983-Q1 estimates rotor position from motor back-EMF, enabling smooth startup across a wide speed range. The integrated power stage uses low RDS(on) MOSFETs to reduce dissipation, and motor parameters are configurable via I2C for tuning to specific motor characteristics. The HTSSOP exposed pad provides good thermal performance for PCB heat spreading. Typical applications include automotive cooling fans, oil pumps, water pumps, and HVAC blowers. The I2C interface enables real-time monitoring and configuration valuable in advanced automotive systems. Design tip: ensure adequate PCB copper area on the exposed pad for heat dissipation, and correctly configure I2C motor parameters to match the specific motor being driven.
DRV3201-Q1 - Automotive 12V 3-Phase Gate Driver | Texas Instruments
The Texas Instruments DRV3201-Q1 is an AEC-Q100 qualified automotive 12-V battery 3-phase gate driver with integrated current shunt amplifiers and enhanced protection, designed for automotive brushless DC (BLDC) motor control including safety-relevant applications. It is packaged in a 64-pin HTQFP (10x10 mm, PAP) surface-mount package with SPI control interface. A 3-phase gate driver is a power management IC that provides the level-shifted gate-drive signals required to switch the six power MOSFETs of a three-phase inverter bridge. Positioned between the microcontroller (which generates PWM signals) and the power stage, it translates logic-level inputs into high-current gate pulses, and often integrates current sensing, protection, and diagnostics to support functional-safety systems such as ASIL-rated automotive actuation. The DRV3201-Q1 provides six dedicated gate drivers for normal-level N-channel MOSFET transistors. The driver capability is designed to handle gate charges up to 250 nC, and the driver source/sink currents are programmable for easy output slope adjustment, enabling EMI optimization. Three high-side and three low-side gate drivers can be switched individually with low propagation delay, supporting PWM-based trapezoidal and field-oriented control schemes. The device incorporates integrated current shunt amplifiers for phase or bus current measurement, plus enhanced protection features including gate-fault detection, overcurrent, and supply supervisory functions, supporting automotive functional safety architectures. Control and diagnostics are accessed through an SPI interface, giving the MCU visibility into fault conditions and operating status. Typical applications include automotive 12-V BLDC motor drives such as electric power steering, engine cooling fans, water pumps, fuel pumps, and other safety-relevant actuation systems. Design tip: take advantage of the programmable gate source/sink currents to tune MOSFET switching slopes - slower turn-on reduces EMI while faster turn-off minimizes switching losses; verify propagation-delay matching across all six channels to minimize dead-time distortion in FOC implementations.
DRV3201AQPAPRQ1 - 12V Automotive 3-Phase Gate Driver | TI
The Texas Instruments DRV3201AQPAPRQ1 is an automotive-grade 12-V battery 3-phase gate driver with integrated current shunt amplifiers and enhanced protection features, provided in a surface-mount PAP package on Tape & Reel. It is AEC-Q100 qualified (Q1 automotive variant) and intended for three-phase motor drive safety applications such as electric power steering, fuel pumps, and HVAC blowers in 12-V automotive systems. A three-phase gate driver is a power-management IC that translates low-voltage logic-level PWM signals from a microcontroller into gate drive signals for the six MOSFETs of a three-phase inverter bridge. Within the system hierarchy, it sits between the MCU (control layer) and the power MOSFETs (power layer), and it typically integrates supervisory, diagnostic, and current-sensing functions to meet functional-safety targets in vehicles. Key features of the DRV3201-Q1 family include half-bridge (3) output configuration for driving a complete three-phase inverter, control via PWM inputs and an SPI interface for configuration and diagnostics, integrated current shunt amplifiers that reduce external component count in phase-current sensing, and enhanced protection functions such as gate-fault detection and supply supervision designed for automotive safety applications. Technically, the device manages gate charge for external N-channel power MOSFETs, provides direction and commutation management, and reports fault conditions over SPI. The integration of current-sense amplifiers on the same die allows compact, coordinated gate-drive and current-feedback loops, improving board-level reliability compared with discrete solutions assembled from separate gate drivers and amplifiers. Typical applications include 12-V automotive brushed-DC and BLDC/PMSM motor drives, three-phase pumps and fans, and electric power steering systems where functional safety diagnostics are required. The Q1 designation makes it suitable for production vehicle platforms. Design consideration: verify the SPI register configuration at every power cycle and validate gate-drive current capability against your external MOSFET total gate charge to set realistic switching speeds and EMI performance. This page synthesizes distributor pricing, drop-in alternative data, and practical design notes not found in the manufacturer datasheet.
DRV3201QPAPRQ1 - Automotive 3-Phase Gate Driver SPI 64-HTQFP | TI
The Texas Instruments DRV3201QPAPRQ1 is an automotive-grade 12-V battery 3-phase gate driver with integrated current shunt amplifiers and enhanced protection, controlled via SPI and housed in a 64-pin HTQFP (PAP) 10x10 mm package rated from -40C to +125C. It operates from a supply range of 4.75 V to 30 V, making it suitable for direct connection to 12-V automotive battery rails with transient headroom. A 3-phase gate driver is a power management IC that drives the six external power MOSFETs of a three-phase bridge (inverter) used to control brushless DC (BLDC), permanent magnet synchronous (PMSM), and AC induction motors. In the power-train hierarchy it sits between the microcontroller (which generates PWM commands) and the power stage (MOSFETs), translating logic-level signals into gate charge currents while providing isolation of protection functions such as overcurrent, overtemperature, and undervoltage monitoring. Key features of the DRV3201-Q1 include SPI-based configuration and diagnostics for functional-safety-relevant applications, integrated current shunt amplifiers for phase-current sensing, and enhanced protection circuitry covering gate driver faults, supply supervision, and thermal events. According to TI, the bridge driver is dedicated to automotive 3-phase BLDC motor control including safety relevant applications, supported by AEC-Q100 Grade 1 temperature qualification. The device integrates the gate-drive power architecture with charge-pump assisted high-side supply, allowing DC 100 percent duty-cycle operation of the high-side switches - a requirement in automotive motor positioning and pump applications where the phase must be held continuously. The SPI interface enables fault readback, configuration of protection thresholds, and system-level functional-safety diagnostics. Typical applications include electric power steering (EPS), automotive fuel pumps, water pumps and oil pumps, engine cooling fans, HVAC blowers, and start-stop systems - all 12-V battery-driven 3-phase motor drives with ASIL-relevant safety requirements. A key design consideration is thermal management of the HTQFP (PAP) exposed-pad package: the exposed die pad must be soldered to a well-grounded PCB copper area to dissipate gate-drive losses and achieve the specified junction temperature range. This page synthesizes verified distributor pricing, drop-in alternative cross-references, and practical automotive design guidance not consolidated in the manufacturer datasheet.
DRV3255-Q1 - 48V 3-Phase Automotive Gate Driver | TI
The Texas Instruments DRV3255-Q1 is a highly-integrated three-phase gate driver unit (GDU) for 48-V automotive motor drive applications, delivering 3.5-A peak source and 4.5-A peak sink gate drive currents with 90-V MOSFET transient overvoltage support, housed in a 64-pin HTQFP (10x10 mm, EAP) surface-mount package. A gate driver unit is a power-management IC that translates low-voltage logic signals from a microcontroller into the high-current gate signals required to switch external power MOSFETs in a three-phase inverter. Within the power-electronics hierarchy, the GDU sits between the MCU and the MOSFET bridge, providing gate charge amplification, protection logic, and system diagnostics for brushless DC (BLDC) and PMSM motor drives. Key features include high gate drive capability (3.5-A source / 4.5-A sink peak) enabling fast switching of large parallel MOSFET arrays, a highly efficient bootstrap architecture for the high-side supply, and 90-V transient overvoltage support that protects against load-dump-style events on 48-V rails. Digital I/O pins withstand up to 75-V absolute maximum ratings, protecting the device against 12-V supply overvoltage events. The DRV3255-Q1 integrates a highly configurable Active Short Circuit (ASC) function that short-circuits selected external MOSFETs in response to system faults, eliminating external transistors and control logic. According to TI, it was the industry's first 48-V three-phase BLDC driver to integrate active shorting on both high and low sides. Wide monitoring and diagnostic capability supports robust, functional-safety-oriented motor drive system design, making it well suited to ASIL-oriented architectures in electrified powertrain systems. Typical applications include 48-V belt starter generators (BSG), motor generators for mild-hybrid electric vehicles (MHEV), e-turbo and e-compressor drives, and 48-V high-power traction accessories. TI reference design SLVAF39A covers driving parallel MOSFETs with this device for 350-A class output stages. Design consideration: verify bootstrap capacitor sizing against the total gate charge of the selected MOSFETs, and confirm that the ASC pin configuration matches the required short-circuit strategy before finalizing the PCB layout. This page synthesizes verified distributor data, drop-in alternative guidance, and practical design notes not consolidated in the manufacturer datasheet, with pricing and stock signals as of 2026-08-30.
DRV8231 - 35V 3.7A H-Bridge Motor Driver | Texas Instruments
The Texas Instruments DRV8231 is a 35-V, 3.7-A brushed DC motor driver with integrated current regulation, supplied in a compact 8-pin WSON (DSG, 2x2 mm) package. It operates from a 4.5-V to 33-V supply rail and integrates four N-channel MOSFETs forming an H-bridge with a typical RDS(on) of 600 mOhm (including one high-side and one low-side FET). A brushed DC motor driver is a type of motor controller IC that switches power to a DC motor using an H-bridge of transistors, enabling forward, reverse, brake, and coast control. Within the power management IC hierarchy, motor drivers sit between logic-level microcontroller outputs and the power stage, and integrated H-bridge drivers like the DRV8231 combine gate drive, power FETs, charge pump, and protection in a single device. Key features include integrated current regulation with programmable current limit via the ILIM pin, a charge pump that supports 100% duty cycle operation and full N-channel H-bridge efficiency, and low-voltage logic inputs compatible with 3.3-V and 5-V controllers. Two logic inputs (PWM interface on the DRV8231D variant, PH/EN interface on the DRV8231A variant) control the bridge states, minimizing MCU pin usage and firmware complexity. Technically, the DRV8231 family offers pin-to-pin scalable RDS(on) and supply voltage options, allowing designers to support various loads and rails with minimal PCB changes. Integrated protection includes undervoltage lockout, overcurrent protection, and thermal shutdown, reducing external component count and board area compared to discrete MOSFET bridge solutions. Typical applications include brushed DC motor control in printers, small appliances, actuators, robotics, factory automation systems, and consumer electronics, where the compact 2x2 mm WSON-8 package fits space-constrained designs and integrated current regulation protects the motor and PCB traces without an external sense resistor network. When designing with the DRV8231, set the current limit using the ILIM pin resistor per the datasheet equation and provide a solid power ground plane under the exposed pad, since bridge conduction losses scale with the 600 mOhm typical RDS(on) at higher load currents.
DRV8242SQRHLRQ1 - 40V 6A Automotive H-Bridge Driver | Texas Instruments
The Texas Instruments DRV8242SQRHLRQ1 is an automotive-qualified 40V, 6A H-bridge motor driver with integrated high-side current sensing and feedback, housed in a 20-pin VQFN (RHL) package measuring 3.5 x 4.5 x 0.9 mm and rated for operation from -40C to +125C. An H-bridge motor driver is a power management IC that controls the direction, speed, and braking of a DC motor by switching four internal power transistors in complementary pairs. H-bridge drivers sit within the motor driver family of the broader power management IC hierarchy, bridging the gap between low-voltage logic controllers and the inductive loads of brushed DC motors, stepper motors, and actuators used across automotive and industrial systems. Key features include the integrated 40V-rated N-channel H-bridge, an integrated charge pump regulator for high-side gate drive, and on-chip current sensing with regulation that eliminates the need for external sense resistors. Control is provided through PWM or SPI interfaces, and a low-power sleep mode minimizes quiescent current for always-on automotive modules. The DRV8242-Q1 family shares an identical pin function across variants with scalable RON (on-resistance) to match different load currents, allowing designers to scale power capability without PCB redesign. Integrated protection circuitry covers overcurrent, thermal, and supply fault conditions, and the current-proportional output feeds motor current data back to the microcontroller for closed-loop control and diagnostics. Typical applications include automotive brushed DC motor modules such as pumps, fans, actuators, HVAC dampers, seat adjusters, and door latches, as well as industrial motion control where a compact 4.5V to 35V supply range and 6A continuous current are required. When designing with this device, exploit the integrated current-sense regulation to remove external shunt resistors, but ensure the VQFN exposed pad is soldered to an adequate PCB thermal plane to dissipate conduction losses at full 6A load. Verify that the supply path tolerates inductive kick-back beyond the 40V rating during aggressive PWM braking. This page synthesizes verified distributor pricing, drop-in same-family alternatives, and practical design notes not found in the manufacturer datasheet, giving engineers a complete sourcing and design reference for the DRV8242SQRHLRQ1.
DRV8243SQRHLRQ1 - 40V, 12A Automotive H-Bridge Driver | TI
The Texas Instruments DRV8243SQRHLRQ1 is an automotive-grade 40-V, 12-A H-bridge motor driver with integrated current sensing, integrated N-channel power FETs, and SPI-based configurable control, housed in a thermally enhanced VQFN-HR (RHL) power package and qualified to AEC-Q100 for automotive deployment. An H-bridge driver is a power management IC that controls the direction, speed, and braking of DC motors and other inductive loads by switching four bridge arms in controlled combinations. Within the power electronics hierarchy, the DRV8243-Q1 belongs to the integrated motor driver family: a monolithic device combining gate drive, power stage, current sensing, diagnostics, and protection in a single package, eliminating the need for discrete MOSFETs and gate drivers. Key features include a 40 V absolute maximum supply rating supporting 12-V automotive battery systems with load-dump headroom, up to 12 A of current capability from an integrated N-channel H-bridge on a BiCMOS high-power process, and high-side current sensing with regulation plus a current-proportional analog feedback output. The SPI (SQ) control interface allows configuration of off-state diagnostics, current regulation thresholds, slew-rate control, and detailed fault reporting, enabling predictive maintenance and functional-safety architectures. The DRV824x-Q1 family is fabricated on a monolithic BiCMOS high-power process that delivers excellent power handling and thermal performance. The family shares an identical pin function across members with scalable RON, so designers can trade current capability against cost without a PCB respin. A low-power sleep mode minimizes quiescent battery drain, and an integrated charge pump guarantees full enhancement of the high-side N-channel FETs across the supply range. Typical applications include automotive body and comfort functions such as power liftgates, power seats, window lifters, sunroof and pump actuators, as well as industrial 12-V brushed-DC motor drives requiring rich diagnostics. The integrated current-sense amplifier with proportional output removes the external sense resistor in many designs, saving board area and improving efficiency. Design consideration: because the bridge power FETs are integrated, thermal design centers on PCB copper area under the power pad; estimate conduction losses as I^2 x RON per arm and verify junction temperature against the AEC-Q100 Grade 1 ambient range. This page synthesizes distributor pricing, drop-in family alternatives, comparison tables, and practical design notes not found in the manufacturer datasheet.
DRV8313PWPR - 2.5A Triple 1/2-H Bridge Driver | TI
The Texas Instruments DRV8313PWPR is a triple 1/2-H bridge driver designed for three-phase brushless-DC motors and other loads. It integrates N-channel power MOSFETs in a 1/2-H bridge configuration, providing up to 2.5A continuous output current per channel and 3A peak. The device operates from a supply voltage range of 8V to 60V, making it suitable for a wide range of industrial and consumer applications. Housed in a 28-pin HTSSOP (PWP) package, the DRV8313PWPR offers a compact solution for motor control. A motor driver is an integrated circuit that translates low-power control signals from a microcontroller into the higher voltage and current needed to drive a motor. The DRV8313PWPR is a triple 1/2-H bridge driver, meaning it contains three independent half-bridge outputs, each capable of sourcing or sinking current. This configuration is ideal for driving three-phase brushless-DC motors, where each phase is connected to one half-bridge. The device also supports independent control of each half-bridge, allowing it to drive solenoids, relays, or other loads. Key features of the DRV8313PWPR include a wide operating voltage range of 8V to 60V, low on-resistance MOSFETs for high efficiency, and overcurrent, overtemperature, and undervoltage lockout protection. The device also features a low-power sleep mode to reduce quiescent current when the motor is not running. These features make it a robust choice for demanding motor control applications. The DRV8313PWPR uses a simple PWM interface, allowing direct connection to a microcontroller's PWM outputs. Each half-bridge can be controlled independently, enabling flexible motor control schemes such as trapezoidal or sinusoidal commutation. The device also includes a current-sense output that can be used for closed-loop current control, enhancing system performance. Typical applications include three-phase brushless-DC motor drives for fans, pumps, and robotics, as well as solenoid drivers and other inductive loads. The wide voltage range and high current capability make it suitable for both 12V and 24V systems, common in industrial and automotive environments. When designing with the DRV8313PWPR, ensure adequate PCB copper area for heat dissipation, especially at high currents. The exposed thermal pad should be soldered to a large ground plane to improve thermal performance. Additionally, place decoupling capacitors close to the power supply pins to minimize voltage transients.
DRV8353SRTAR - 102V 3-Phase Smart Gate Driver | Texas Instruments
The Texas Instruments DRV8353SRTAR is a highly integrated three-phase smart gate driver designed for brushless DC (BLDC) motor applications. It operates from a supply voltage of 9V to 100V (102V absolute maximum) and is available in a 40-pin WQFN (RTA) package measuring 6x6 mm. This device integrates three half-bridge gate drivers, optional current shunt amplifiers, and an optional buck regulator, making it a compact solution for motor control systems. A smart gate driver is a specialized integrated circuit that controls the external power MOSFETs in a motor drive inverter. It translates low-voltage logic signals from a microcontroller into high-current gate drive signals, ensuring efficient and reliable switching of the power stage. The DRV8353 belongs to the DRV835x family, which is part of TI's motor driver portfolio, ultimately falling under power management ICs. This hierarchy places the device within the broader category of motor control and power conversion semiconductors. Key features of the DRV8353SRTAR include adjustable slew rate control for EMI performance, VGS handshake and dead-time management, and a SPI interface for configuration and diagnostics. The device supports a wide operating temperature range of -40°C to 125°C, making it suitable for industrial and automotive environments. The integrated current shunt amplifiers enable precise current sensing without external op-amps, reducing BOM cost and board space. Technically, the DRV8353 uses a smart gate drive architecture that monitors the gate-to-source voltage (VGS) to ensure proper turn-on and turn-off of the external MOSFETs. This reduces the risk of shoot-through and improves system reliability. The adjustable slew rate allows designers to optimize switching speed versus EMI, which is critical in noise-sensitive applications. The device also includes protection features such as undervoltage lockout (UVLO), overcurrent protection, and thermal shutdown. Typical applications include industrial motor drives, robotics, power tools, and automotive systems such as electric power steering and cooling fans. The wide input voltage range and integrated features make it ideal for both 12V and 48V systems. The SPI interface allows real-time monitoring and configuration, enabling advanced motor control algorithms. When designing with this device, ensure proper PCB layout with adequate copper pour for thermal dissipation, and place decoupling capacitors close to the power pins. The gate drive current and slew rate should be selected based on the external MOSFETs' gate charge to optimize switching performance.
DRV8353SRTAR-Q1 - 100V 3-Phase Smart Gate Driver SPI | TI
The Texas Instruments DRV8353SRTAR-Q1 is an AEC-Q100 qualified, 9-V to 100-V three-phase smart gate driver for BLDC and PMSM motors, housed in a 40-pin WQFN (RTA) 6x6 mm package and configurable via SPI. It integrates three half-bridge gate drivers with smart gate-drive architecture, adjustable slew-rate control, and optional triple low-side current shunt amplifiers for precise motor phase current sensing. A three-phase gate driver is a power-management IC that controls the external MOSFETs forming the three half-bridges of an inverter stage, providing the gate charge, protection, and control interface between an MCU and the power stage. Within the power hierarchy, it sits above discrete MOSFET drivers and below full motor-controller SoCs, bridging control electronics and the power stage. Key features include smart gate drive with VGS handshake and automatic handshake modes, IDRIVE current and slew-rate adjustability for EMI control, integrated 100% duty-cycle support and IVCP tri-level input, plus integrated protections: VDS overcurrent monitor, UVLO, OCP, OTS, and GDF fault reporting with SPI fault registers. The SPI interface enables full register-level configuration of gate-drive current, slew rate, and CSA gain. The smart gate-drive architecture allows engineers to tune MOSFET switching speed independently for turn-on and turn-off events, balancing EMI, efficiency, and di/dt-related protection. The on-chip current shunt amplifiers (programmable gain) enable low-side current sensing for FOC and trapezoidal control without external op-amps. Typical applications include automotive 48V BLDC pumps, fans, and traction auxiliaries, e-bike and power-sport motor inverters, industrial servo drives, drones, and power tools. The -40C to +125C operating range and AEC-Q100 qualification make it suited for harsh automotive environments. Design tip: size the IDRIVE setting to the external MOSFET gate charge to control switching slew; overly aggressive gate drive increases radiated EMI and VDS overshoot risk on the 100V rail.
DRV8376HQNLGRQ1 - Automotive 70V 4A BLDC Driver | TI
The Texas Instruments DRV8376HQNLGRQ1 is an automotive-grade, three-phase brushless-DC (BLDC) motor driver with integrated current sensing, designed for 4.5V to 65V motor supplies. It integrates three 1/2-H bridges with 70V absolute maximum capability and a very low RDS(on) of 400 mOhm (high-side plus low-side) to enable high-power drive capability, delivering up to 4A peak output current in a 28-pin VQFN (6x5mm) exposed-pad package operating from -40C to +125C. A motor driver is an integrated circuit that translates low-power control signals from a microcontroller into the high-current, high-voltage signals needed to drive a motor. The DRV8376-Q1 belongs to the gate driver and integrated power stage family, positioned between the MCU and the three-phase motor in the power electronics hierarchy. It provides the power amplification, current feedback, and protection layers required in modern automotive and industrial motion systems. Key features include integrated current sensing that eliminates external sense resistors, reducing BOM cost and board area. The device supports PWM control with a highly configurable interface through hardware pins or registers, allowing flexible current limiting, slew-rate control, and fault response tuning. Protection features include overcurrent, overtemperature, and undervoltage lockout with fault reporting, safeguarding the device, motor, and system. The DRV8376-Q1 uses an NMOS power-stage architecture in a three-phase bridge configuration. The low 400 mOhm RDS(on) minimizes conduction losses, improving thermal performance and efficiency. The integrated sense-FET current sensing provides accurate current feedback without the power loss of external shunts, enabling precise torque control and stall detection in FOC and trapezoidal control schemes. Typical applications include automotive BLDC motors such as electric power steering (EPS), engine cooling fans, oil pumps, and fuel pumps. AEC-Q100 qualification and the 4.5V to 65V input range suit both 12V and 24V automotive systems, as well as industrial drives and robotics requiring integrated sensing. When designing with this device, ensure proper PCB layout with adequate copper area on the VQFN exposed pad for thermal dissipation, and place decoupling capacitors close to the power pins. Calibrate the current-sense gain setting for accurate torque control.
DRV8432DKDR - 52V 14A Dual Full-Bridge Motor Driver | TI
The Texas Instruments DRV8432DKDR is a high-performance, integrated dual full-bridge PWM motor driver designed for driving DC motors, stepper motors, and other inductive loads. It operates from a load supply voltage of 0 V to 52.5 V and can deliver up to 14 A continuous output current per bridge (7 A per channel in dual full-bridge mode). The device is housed in a 36-pin HSSOP (PowerPAD) package, providing excellent thermal performance for high-power applications. A motor driver is an integrated circuit that translates low-power control signals from a microcontroller or DSP into high-current, high-voltage signals capable of driving motors. The DRV8432 belongs to the motor driver category, which is a subset of power management ICs. It integrates four half-bridges (configurable as two full H-bridges) with low RDS(on) MOSFETs (110 mΩ at TJ = 25°C), achieving up to 97% power-stage efficiency. This integration reduces external component count and simplifies PCB layout compared to discrete H-bridge designs. Key features include advanced protection circuitry: overcurrent protection (OCP), overtemperature protection (OTP), undervoltage lockout (UVLO), and overvoltage protection (OVP). The device supports PWM control with a wide frequency range, and its current regulation capability enables precise torque control in stepper applications. The DRV8432 also features a sleep mode for low-power standby, reducing quiescent current consumption. Technically, the DRV8432 uses a bootstrap-based gate drive architecture for the high-side N-channel MOSFETs, requiring external bootstrap capacitors. The device provides separate logic and power grounds, and its digital inputs are compatible with 3.3 V and 5 V logic levels. The PWM frequency can be set up to 500 kHz, making it suitable for high-speed switching applications. The thermal pad on the HSSOP package must be soldered to a copper plane for adequate heat dissipation. Typical applications include brushed DC motor drivers in robotics, industrial automation, and automotive systems; bipolar stepper motor drivers in 3D printers and CNC machines; and solenoid drivers in vending machines and industrial controls. The wide voltage range and high current capability make it versatile for various motor control systems. When designing with the DRV8432, ensure proper PCB layout with low-inductance paths for high-current loops and adequate thermal vias under the thermal pad. The bootstrap capacitors should be placed close to the respective pins, and the logic supply should be decoupled with a 0.1 µF ceramic capacitor.
DRV8714SQRHARQ1 - 40V 4-Ch Smart Gate Driver | TI | Automotive
The Texas Instruments DRV8714SQRHARQ1 is an automotive-grade, 40-V, four-channel half-bridge smart gate driver with integrated wide common-mode inline current sense amplifiers, housed in a 56-pin VQFN (RVJ) package. A half-bridge gate driver is a power-management IC that controls the gate charge of external MOSFETs in an H-bridge or half-bridge power stage. It sits between a low-voltage controller (MCU) and the power FETs, translating logic-level PWM signals into gate-drive currents while providing protection, dead-time management, and current feedback. Multi-channel gate drivers such as the DRV871x-Q1 family consolidate driver power supplies, shunt amplifiers, and protection monitors into one IC, replacing dozens of discrete components in a brushed-DC, stepper, or solenoid drive stage. Key features include a 40-V operating rating suitable for 12-V and 24-V automotive battery systems with load-dump headroom, four independently controllable half-bridges, and smart gate-drive architecture that automatically manages dead time to minimize switching losses and shoot-through. Integrated wide common-mode inline current sense amplifiers eliminate external shunt amplifiers and support accurate motor current feedback for FOC and stall detection. The DRV871x-Q1 family integrates driver power supplies, current shunt amplifiers, and protection monitors, reducing total system complexity, size, and cost. Per the TI datasheet, the DRV8718-Q1 (8-channel) and DRV8714-Q1 (4-channel) are drop-in pin-to-pin compatible in the 56-pin VQFN (RVJ) package, with half-bridge 1-4 locations shifted on the DRV8714-Q1 to aid PCB routing. Typical applications include automotive brushed DC motor control for pumps, fans, dampers and actuators, solenoid drivers, seat adjusters, and multi-motor body-electronics modules requiring AEC-Q100-qualified silicon. Design consideration: verify gate-drive current settings and dead-time register configuration in SPI before first power-up, and place gate-loop layouts short and symmetrical to limit ringing. This page synthesizes distributor pricing, drop-in alternative data, and practical design notes not found in the manufacturer datasheet.
DRV8718SQRHARQ1 - 40V 8-Ch Half-Bridge Gate Driver | Texas Instruments
The Texas Instruments DRV8718SQRHARQ1 is an automotive-qualified, 8-channel half-bridge smart gate driver with wide common-mode inline current sense amplifiers, operating from a 4.9 V to 37 V supply range (40 V absolute maximum) in a 56-pin VQFN (8x8 mm) package. A half-bridge gate driver is a power management IC that controls the gate terminals of external power MOSFETs, allowing a low-voltage logic controller to switch high-current motor loads safely and efficiently. Within the power-delivery hierarchy, it sits between the microcontroller and the power stage: gate driver -> power stage -> motor/load driver -> power management IC. The DRV871x-Q1 family integrates multiple half-bridge drivers, driver power supplies, current shunt amplifiers, and protection monitors to reduce total system complexity, size, and cost. Key features include AEC-Q100 qualification at temperature grade 1 (-40C to +125C ambient), pin-to-pin 4-channel (DRV8714-Q1) and 8-channel (DRV8718-Q1) variants, 4 PWM inputs with flexible output mapping, and a tripler charge pump that sustains 100% duty-cycle PWM operation. Integrated wide common-mode inline current sense amplifiers eliminate the need for external amplifiers in brushless DC motor control. Architecturally, the DRV8718SQRHARQ1 integrates eight half-bridge gate drivers with internal gate-drive supplies and per-channel protection (overcurrent, OVP/UVP, thermal shutdown), making it suited to 12 V and 24 V automotive battery rails with load-dump headroom. Smart gate-drive features tune MOSFET switching to control EMI while limiting switching loss. Typical applications include automotive DC motor control (pumps, fans, actuators), body electronics modules, HVAC dampers, and general-purpose multi-motor loads driven by external power MOSFETs. Design consideration: choose external MOSFETs whose gate charge matches the drive capability of each channel, and route high-current paths away from the current-sense amplifier inputs to preserve accuracy. This page synthesizes verified distributor data, same-family drop-in alternatives, and practical design notes not found in the manufacturer datasheet.
DRV8818PWPR - 2.5A Bipolar Stepper Motor Driver | TI
The Texas Instruments DRV8818PWPR is a bipolar stepper motor driver with integrated current regulation and microstepping indexer, capable of driving up to 2.5 A per winding. It operates from a supply voltage range of 8 V to 35 V and is housed in a 28-pin HTSSOP (PWP) package with an exposed thermal pad (PowerPAD). The device integrates two H-bridge drivers and a microstepping indexer that supports up to 1/8-step operation, making it suitable for printers, scanners, textile machines, and other automated equipment. A stepper motor driver is a power management IC that translates step and direction signals into the precise current sequences needed to rotate a stepper motor. It typically includes H-bridge output stages, current sensing, and protection features. The DRV8818 belongs to the motor driver category, which is part of the broader power management IC family. It uses a STEP/DIR interface, simplifying the connection to a microcontroller or motion controller. Key features of the DRV8818PWPR include a low 0.37 Ω (HS + LS) MOSFET on-resistance at 25°C, which minimizes power dissipation and improves efficiency. The device supports programmable mixed decay, blanking time, and off time, allowing designers to optimize current regulation for different motor types and operating conditions. It also provides a separate logic supply voltage (VCC) for the digital interface, enabling operation with 3.3 V or 5 V logic while the motor supply can be up to 35 V. The DRV8818 uses a current-regulation architecture with a built-in indexer that generates the microstepping waveforms. The device includes protection features such as overcurrent, overtemperature, and undervoltage lockout. The low on-resistance and high current capability make it suitable for applications requiring smooth motion and low heat generation. Typical applications include 3D printers, office automation equipment, vending machines, and industrial automation. The device's wide supply range and robust output stage allow it to drive a variety of bipolar stepper motors. The HTSSOP-28 package with PowerPAD provides excellent thermal performance, enabling continuous operation at high currents with proper PCB layout. When designing with the DRV8818, ensure adequate decoupling on the motor supply and logic supply pins. The exposed thermal pad must be soldered to a copper plane for heat dissipation. The STEP/DIR inputs should be filtered to avoid noise-induced false steps.
