STM32WL55CCU6 vs STM32WL55JCI6 Comparison
Detailed side-by-side comparison of STM32WL55CCU6 by STMicroelectronics and STM32WL55JCI6 by STMicroelectronics. Compare key specifications, electrical parameters, packaging, lifecycle status, pricing, and availability to determine the best component for your design requirements.
STMicroelectronics
STM32WL55CCU6
STM32WL55CCU6 - Dual-core Arm Cortex-M4/M0+ LoRa SoC | STMicroelectronics
STM32WL55CCU6 β Active
Specification Comparison
| Parameter | STM32WL55CCU6 | STM32WL55JCI6 |
|---|---|---|
| Brand | STMicroelectronics | STMicroelectronics |
| Category | RF Transceivers | RF Transceivers |
| Lifecycle Status | Active | Active |
| Stock Status | In Stock | In Stock |
| Unit Price (USD) | $5.60 | $7.25 |
| Core | Arm Cortex-M4 + Cortex-M0+ | Dual-core Arm Cortex-M4 (64 MHz) + Cortex-M0+ (48 MHz) |
| Max CPU Frequency | 48 MHz | β |
| Flash Memory | 256 KB | 256 KB |
| SRAM | 64 KB | 64 KB |
| Radio Modulation | LoRa, (G)FSK, (G)MSK, BPSK | β |
| Radio Sensitivity | -137 dBm (LoRa) | β |
| Supply Voltage | 1.8 V to 3.6 V | 1.8 V to 3.6 V |
| Package | UFQFPN-48 (7x7 mm) | UFBGA-73 (7x7 mm) |
| Operating Temperature | -40C to +85C | -40C to +85C |
| ADC | 12-bit, 1 MSPS | β |
| DAC | 12-bit | β |
| Timers | Advanced-control, general-purpose, basic | β |
| Communication Interfaces | SPI, I2C, USART, LPUART | β |
| Low Power Modes | Sleep, Stop, Standby | β |
| Standby Current | 1.62 uA (with RTC) | 1.62 uA (with RTC) |
| RoHS Status | Compliant | β |
| Radio Frequency Range | β | 150 MHz to 960 MHz |
| Modulation | β | LoRa, (G)FSK, (G)MSK, BPSK |
| Protocols | β | LoRaWAN 1.0, Sigfox, 802.15.4 |
| RX Sensitivity | β | -137 dBm |
| Max TX Output Power | β | +22 dBm |
| RX Current | β | 4.82 mA |
| TX Current | β | 87 mA at +14 dBm |
| Mounting Type | β | Surface Mount |
| Peripherals | β | 12-bit ADC, DAC, comparators, op-amps, UART/SPI/I2C, TRNG |
| RadioTXRX | β | TxRx + MCU |
