GRM32EC72A106KE05L Overview

The Murata GRM32EC72A106KE05L is a 10uF, 100V, X7S ceramic capacitor in a 1210 (3225M) package. It offers high capacitance in a compact size with stable temperature characteristics, ideal for power supply decoupling, smoothing circuits, and DC-DC converters in automotive and industrial applications.

Drop-in alternatives for GRM32EC72A106KE05L — same package, pin-to-pin compatible. Different-package parts requiring PCB rework are excluded.

C3216X7S2A106K

TDK, 1210, 10uF, 100V, X7S

📋 Reference alternative (not in catalog)

CL32B106KBJNNNE

Samsung, 1210, 10uF, 100V, X7R

📋 Reference alternative (not in catalog)

1210C106KARAC

AVX, 1210, 10uF, 100V, X7R

📋 Reference alternative (not in catalog)

GRM32ER72A106KE01L

Murata, 1210, 10uF, 100V, X7R

📋 Reference alternative (not in catalog)

KGM32ER72A106KU

KYOCERA AVX, 1210, 10uF, 100V, X7R

📋 Reference alternative (not in catalog)

GRM32EC72A106KE05L Maximum Ratings & Electrical Characteristics

Capacitance 10 uF
Voltage Rating 100 V
Dielectric Material X7S
Tolerance ±10%
Package / Case 1210 (3225M)
Mounting Type Surface Mount
Operating Temperature -55°C to +125°C
Temperature Coefficient X7S (±22% over -55°C to +125°C)
Termination Style SMD/SMT
Length 3.2 mm
Width 2.5 mm
Height 2.5 mm
RoHS Status Compliant
MSL Level 1

GRM32EC72A106KE05L 1210 (3225m) Pin Configuration Guide

Pin configuration for GRM32EC72A106KE05L (1210 (3225m) package). Pin numbering, functions, and connection diagrams are defined in the manufacturer datasheet. Refer to it for the exact footprint and soldering guidelines.

1210 (3225m) package pinout diagram for GRM32EC72A106KE05L

No detailed pinout data available for GRM32EC72A106KE05L.

Refer to the datasheet for full pin configuration.

Typical Applications

GRM32EC72A106KE05L is suitable for 8 applications: Power Supply Decoupling, DC-DC Converter Output Smoothing, Automotive Electronics, Industrial Power Supplies, Telecommunications Equipment, LED Lighting Drivers, Medical Devices, IoT Gateways.

⚡

Power Supply Decoupling

Used to filter noise on power rails in various electronic devices.

⚡

DC-DC Converter Output Smoothing

Smooths the output voltage ripple from DC-DC converters.

🚗

Automotive Electronics

Used in engine control units, infotainment, and ADAS power supplies.

🏭

Industrial Power Supplies

Filtering and decoupling in industrial power modules.

🌐

Telecommunications Equipment

Decoupling in base stations and networking gear.

💡

LED Lighting Drivers

Output capacitor for constant current LED drivers.

💊

Medical Devices

Decoupling in portable medical equipment power supplies.

🧩

IoT Gateways

Power rail decoupling in IoT gateway devices.

What is the capacitance and voltage rating of GRM32EC72A106KE05L?
It is a 10 µF, 100 V ceramic capacitor.
What is the package size of GRM32EC72A106KE05L?
It is in a 1210 (3225M) package, measuring 3.2 mm x 2.5 mm x 2.5 mm.
What is the temperature characteristic of this capacitor?
It uses X7S dielectric, with capacitance change of ±22% over -55°C to +125°C.
Is GRM32EC72A106KE05L RoHS compliant?
Yes, it is RoHS compliant.
What is the tolerance of this capacitor?
The tolerance is ±10%.
Can this capacitor be used for DC-DC converter output filtering?
Yes, its 10 µF capacitance and 100 V rating make it suitable for output filtering in DC-DC converters.
What is the operating temperature range?
It operates from -55°C to +125°C.
What is the MSL level of GRM32EC72A106KE05L?
MSL Level 1, meaning no moisture sensitivity restrictions.
What are typical applications for this capacitor?
Power supply decoupling, smoothing circuits, DC-DC converters, and automotive electronics.
Does this capacitor have polarity?
No, MLCCs are non-polarized.
What is the difference between X7S and X7R?
X7S has a wider capacitance change (±22%) compared to X7R (±15%), but both are stable over temperature.
Can I use this capacitor in high-frequency applications?
MLCCs have low ESL and ESR, making them suitable for high-frequency decoupling, but specific ESR data is needed for precise analysis.
What is the recommended soldering profile?
Standard reflow soldering profile for MLCCs, with peak temperature around 260°C.
Is this capacitor suitable for automotive applications?
Yes, Murata offers automotive-grade versions; check the datasheet for AEC-Q200 qualification.
What is the lifespan of this capacitor?
MLCCs have very long lifespan under rated conditions; specific lifetime data is available from Murata.
