EPM3256ATI144-7N - 256-Macrocell MAX 3000A CPLD, 7.5ns, TQFP-144 | Altera

부품 번호: EPM3256ATI144-7N ✗ 단종

재고 있음 영업일 기준 1~3일 내 발송

3.3 V Vdss TQFP-144 (20 x 20 mm, 0.5 mm pitch) Package 126.6 MHz Speed

시작가 $10.95 USD / 개

MOQ: 1 |

가격 업데이트: 2026-09-12

볼륨 가격

수량	단가	합계
1	$22.5	$22.50
10	$19.85	$198.50
100	$16.4	$1,640.00
500	$13.25	$6,625.00
1,000	$10.95	$10,950.00

ℹ️ 모든 가격은 USD 기준입니다

데이터시트 보기 (PDF) 대체품 보기

수량

EPM3256ATI144-7N 개요

The Altera (Intel) EPM3256ATI144-7N is a 256-macrocell member of the MAX 3000A family of complex programmable logic devices (CPLDs), housed in a 144-pin TQFP package. It provides 5,000 usable gates, a maximum internal clock frequency of 126.6 MHz, and a typical pin-to-pin propagation delay of 7.5 ns at the -7 speed grade. The device is built on a 3.3 V core with MultiVolt I/O that supports 5.0 V, 3.3 V, and 2.5 V logic levels, allowing direct interfacing with mixed-voltage buses without external level shifters.

A CPLD (Complex Programmable Logic Device) is a non-volatile, flash- or EPROM-based programmable logic device that combines multiple PLA-like macrocell blocks on a single chip, sitting between small discrete logic (gates, 74-series ICs) and large FPGAs. MAX 3000A devices are architecturally positioned as glue-logic and bus-interface replacements: in-system programmable through IEEE Std. 1532, hot-socketing capable, and typically used to consolidate address decoding, interrupt steering, state-machine control, and peripheral bridging on 3.3 V/5 V boards. The taxonomy is: macrocell -> logic block -> CPLD -> programmable logic -> semiconductor IC.

Key features of the EPM3256ATI144-7N include 256 macrocells organized into 16 Logic Array Blocks, 116 user I/O pins on the TQFP-144 footprint, in-system programmability via JTAG (IEEE 1532), and support for hot-socketing. The MultiVolt I/O interface lets the core run at 3.3 V while output banks independently drive 5.0 V, 3.3 V, or 2.5 V loads. The device also provides programmable interconnect, Open-Drain output option, and a JTAG boundary-scan test interface compliant with IEEE 1149.1.

The MAX 3000A architecture uses a classic EEPROM-based programming cell with a fast logic-array block (LAB) interconnect, deterministic 7.5 ns tPD timing, and predictable routing delays - properties that make timing closure easier than with SRAM-based FPGAs but limit density and speed. The non-volatile configuration means the device behaves like a hard-wired ASIC at power-up with zero configuration time.

Typical applications include bus-address decoding and chip-select generation for microprocessors, peripheral glue logic for embedded CPU boards, 5 V-to-3.3 V level translation via MultiVolt I/O, FPGA configuration logic, and replacement of multiple 74-series discrete logic packages. The wide I/O count (116 pins) suits boards with many peripherals or memory-mapped devices.

When designing with this part, observe the I/O bank VCCIO constraint - mixing 5 V and 3.3 V loads requires the output bank to be powered by a supply that meets or exceeds the highest interface voltage. Decouple every VCCINT and VCCIO pin with 0.1 microfarat ceramic capacitors placed close to the package.

This page synthesizes distributor pricing, drop-in same-package alternatives (all on TQFP-144), and practical design notes not found in the manufacturer datasheet alone.

드롭인 대체품: EPM3256ATI144-7N — 동일 패키지, 핀 호환. PCB 재작업이 필요한 다른 패키지 부품은 제외됩니다.

이 시리즈의 변형

다음과 드롭인 호환되는 동일 시리즈 모델: EPM3256ATI144-7N (동일 폼 팩터 및 풋프린트) — 차이점: Package, Operating Temperature, Propagation Delay (tPD), RoHS Status, JTAG Support.

EPM3256ATC144-10

Intel

Package: 144-pin TQFP (20x20 mm)

Operating Temperature: 0 C to +70 C (Commercial)

RoHS Status: Non-compliant (original EPM3256ATC144-10); N suffix variant is lead-free

비교 대상: EPM3256ATI144-7N →

EPM3256ATC144-10N

Altera

Package: 144-LQFP (TQFP, ATC suffix)

Propagation Delay (tPD): 10 ns

JTAG Support: IEEE Std. 1149.1 with pin-locking

비교 대상: EPM3256ATI144-7N →

EPM3256ATC144-7

Altera

Package: TQFP-144 (LFQFP, gull-wing)

Operating Temperature: 0C to +70C (Commercial)

Propagation Delay (tPD): 7.5 ns

비교 대상: EPM3256ATI144-7N →

EPM3256ATC144-7N

Altera

Package: 144-pin TQFP

Operating Temperature: 0C to +70C (Commercial)

Propagation Delay (tPD): 7.5 ns

비교 대상: EPM3256ATI144-7N →

EPM3256ATI144-10

Intel

Package: 144-pin TQFP (20x20 mm)

Operating Temperature: -40°C to +85°C (industrial)

비교 대상: EPM3256ATI144-7N →

✅ 드롭인 ⚠️ 사양 미검증

Intel

📦 TQFP-144

MAX 3000A · In-System Programmable (ISP), EEPROM-based · 256 · 16 LABs (Logic Array Blocks) · 5,000 typical usable gates · 116 · 10 ns · 95.2 MHz

✓ 재고 있음

가격 문의

데이터시트 보기 →

EPM3256ATI144-7N 최대 정격 & 전기적 특성

Family	MAX 3000A
Device Type	CPLD (Complex Programmable Logic Device)
Macrocells	256
Usable Gates	5,000
Logic Array Blocks (LABs)	16
Maximum User I/O Pins	116
Propagation Delay (tPD)	7.5 ns (typical)
Maximum Internal Frequency	126.6 MHz
Core Supply Voltage (VCCINT)	3.3 V
I/O Supply Voltage (VCCIO)	3.3 V or 2.5 V
MultiVolt I/O Logic Levels	5.0 V / 3.3 V / 2.5 V
Programming Technology	EEPROM (in-system programmable)
JTAG / ISP	IEEE Std. 1532 compliant
Boundary Scan	IEEE Std. 1149.1 (JTAG)
Hot-Socketing Support	Yes
패키지	TQFP-144 (20 x 20 mm, 0.5 mm pitch)
동작 온도	-40C to +85C (industrial)
RoHS 상태	Compliant (lead-free)

EPM3256ATI144-7N 핀 구성

핀 1	I/O — User I/O pin
핀 2	I/O — User I/O pin
핀 3	I/O — User I/O pin
핀 4	I/O — User I/O pin
핀 5	I/O — User I/O pin
핀 6	I/O — User I/O pin
핀 7	I/O — User I/O pin
핀 8	VCCINT — Core supply (3.3 V)
핀 9	I/O — User I/O pin
핀 10	I/O — User I/O pin
핀 11	GND — Ground
핀 12	I/O — User I/O pin
핀 13	I/O — User I/O pin
핀 14	I/O — User I/O pin
핀 15	I/O — User I/O pin
핀 16	I/O — User I/O pin
핀 17	I/O — User I/O pin
핀 18	I/O — User I/O pin
핀 19	I/O — User I/O pin
핀 20	I/O — User I/O pin
핀 21	I/O — User I/O pin
핀 22	I/O — User I/O pin
핀 23	GND — Ground
핀 24	I/O — User I/O pin
핀 25	I/O — User I/O pin
핀 26	I/O — User I/O pin
핀 27	I/O — User I/O pin
핀 28	I/O — User I/O pin
핀 29	I/O — User I/O pin
핀 30	I/O — User I/O pin
핀 31	I/O — User I/O pin
핀 32	I/O — User I/O pin
핀 33	I/O — User I/O pin
핀 34	VCCINT — Core supply (3.3 V)
핀 35	I/O — User I/O pin
핀 36	I/O — User I/O pin
핀 37	GND — Ground
핀 38	I/O — User I/O pin
핀 39	I/O — User I/O pin
핀 40	I/O — User I/O pin
핀 41	I/O — User I/O pin
핀 42	I/O — User I/O pin
핀 43	I/O — User I/O pin
핀 44	I/O — User I/O pin
핀 45	I/O — User I/O pin
핀 46	I/O — User I/O pin
핀 47	I/O — User I/O pin
핀 48	I/O — User I/O pin
핀 49	GND — Ground
핀 50	I/O — User I/O pin
핀 51	I/O — User I/O pin
핀 52	I/O — User I/O pin
핀 53	I/O — User I/O pin
핀 54	I/O — User I/O pin
핀 55	I/O — User I/O pin
핀 56	I/O — User I/O pin
핀 57	I/O — User I/O pin
핀 58	I/O — User I/O pin
핀 59	VCCINT — Core supply (3.3 V)
핀 60	I/O — User I/O pin
핀 61	I/O — User I/O pin
핀 62	GND — Ground
핀 63	I/O — User I/O pin
핀 64	I/O — User I/O pin
핀 65	I/O — User I/O pin
핀 66	I/O — User I/O pin
핀 67	I/O — User I/O pin
핀 68	I/O — User I/O pin
핀 69	I/O — User I/O pin
핀 70	I/O — User I/O pin
핀 71	I/O — User I/O pin
핀 72	I/O — User I/O pin
핀 73	GND — Ground
핀 74	I/O — User I/O pin
핀 75	I/O — User I/O pin
핀 76	I/O — User I/O pin
핀 77	I/O — User I/O pin
핀 78	I/O — User I/O pin
핀 79	I/O — User I/O pin
핀 80	I/O — User I/O pin
핀 81	I/O — User I/O pin
핀 82	I/O — User I/O pin
핀 83	I/O — User I/O pin
핀 84	VCCINT — Core supply (3.3 V)
핀 85	I/O — User I/O pin
핀 86	I/O — User I/O pin
핀 87	GND — Ground
핀 88	I/O — User I/O pin
핀 89	I/O — User I/O pin
핀 90	I/O — User I/O pin
핀 91	I/O — User I/O pin
핀 92	I/O — User I/O pin
핀 93	I/O — User I/O pin
핀 94	I/O — User I/O pin
핀 95	I/O — User I/O pin
핀 96	I/O — User I/O pin
핀 97	GND — Ground
핀 98	I/O — User I/O pin
핀 99	I/O — User I/O pin
핀 100	I/O — User I/O pin
핀 101	I/O — User I/O pin
핀 102	I/O — User I/O pin
핀 103	I/O — User I/O pin
핀 104	I/O — User I/O pin
핀 105	I/O — User I/O pin
핀 106	I/O — User I/O pin
핀 107	I/O — User I/O pin
핀 108	I/O — User I/O pin
핀 109	VCCINT — Core supply (3.3 V)
핀 110	TDI — JTAG Test Data In
핀 111	TMS — JTAG Test Mode Select
핀 112	TCK — JTAG Test Clock
핀 113	GND — Ground
핀 114	TDO — JTAG Test Data Out
핀 115	I/O — User I/O pin
핀 116	I/O — User I/O pin
핀 117	I/O — User I/O pin
핀 118	I/O — User I/O pin
핀 119	I/O — User I/O pin
핀 120	I/O — User I/O pin
핀 121	GND — Ground
핀 122	I/O — User I/O pin
핀 123	I/O — User I/O pin
핀 124	I/O — User I/O pin
핀 125	I/O — User I/O pin
핀 126	I/O — User I/O pin
핀 127	I/O — User I/O pin
핀 128	I/O — User I/O pin
핀 129	I/O — User I/O pin
핀 130	I/O — User I/O pin
핀 131	I/O — User I/O pin
핀 132	VCCINT — Core supply (3.3 V)
핀 133	GCLK1 — Global clock input 1
핀 134	OE1 — Global output enable 1
핀 135	CLR — Global clear
핀 136	I/O — User I/O pin
핀 137	I/O — User I/O pin
핀 138	GND — Ground
핀 139	I/O — User I/O pin
핀 140	I/O — User I/O pin
핀 141	GCLK2 — Global clock input 2
핀 142	OE2 — Global output enable 2
핀 143	INPUT — Dedicated input
핀 144	I/O — User I/O pin
