STM32F722ZET6 Übersicht
An ARM Cortex-M7 microcontroller is a high-performance 32-bit processor core designed for embedded systems that demand intensive computation, such as digital signal processing, motor control, and graphical user interfaces. The Cortex-M7 core features a 6-stage pipeline, branch prediction, and optional double-precision floating-point unit (FPU), enabling efficient execution of complex algorithms. In the system hierarchy, the STM32F722ZET6 sits at the application processor level, interfacing with memory, peripherals, and external devices to control and process data in real-time.
Key features of the STM32F722ZET6 include a 216 MHz CPU with a single-precision FPU, 512 KB flash, 256 KB SRAM, and a comprehensive set of peripherals. It supports a wide supply voltage range of 1.7V to 3.6V, operates over a temperature range of -40°C to +85°C, and includes advanced security features such as a true random number generator (TRNG) and a cryptographic acceleration cell. The device also features a Chrom-ART Accelerator for enhanced graphical performance, making it ideal for human-machine interface (HMI) applications.
Technically, the STM32F722ZET6 is built on a 90nm process technology, offering a balance between performance and power consumption. It includes a memory protection unit (MPU) for enhanced reliability, a direct memory access (DMA) controller with up to 16 channels, and a flexible memory controller (FMC) supporting external memory interfaces. The device also integrates a 12-bit ADC with up to 24 channels, two 12-bit DACs, and multiple 16-bit and 32-bit timers, providing precise analog and timing control.
Typical applications include industrial control systems, motor drives, advanced human-machine interfaces, IoT gateways, audio processing, and high-end consumer electronics. The combination of high clock speed, ample memory, and rich peripherals makes it a versatile choice for designers requiring a powerful MCU in a compact package.
When designing with the STM32F722ZET6, ensure proper decoupling of the power supply pins with 100nF capacitors placed close to each VDD pin, and a 4.7uF bulk capacitor on the main supply. The device supports multiple low-power modes, including Sleep, Stop, and Standby, which can be leveraged to optimize energy consumption in battery-powered applications.
Drop-in-Alternativen für STM32F722ZET6 – gleiches Gehäuse, Pin-kompatibel. Bauteile mit anderem Gehäuse, die eine PCB-Überarbeitung erfordern, sind ausgeschlossen.
Varianten dieser Serie
Modelle derselben Serie, die drop-in-kompatibel sind mit STM32F722ZET6 (gleiche Bauform und Footprint) – abweichend in Operating Temperature, Package, SRAM, ADC, Communication Interfaces.
Schnellvergleichstool – Wählen Sie Alternativbauteile für den Direktvergleich:
STM32F767ZIT6
✓ Auf Lager
$17.6 / Stück
Datenblatt ansehen →STM32F722RET6
✓ Auf Lager
$8.1 / Stück
Datenblatt ansehen →STM32F722ZET6TR
📋 Referenzalternative (nicht im Katalog)
STM32F722ZET6Q
📋 Referenzalternative (nicht im Katalog)
STM32F746ZET6
📋 Referenzalternative (nicht im Katalog)
LPC54628J512BD208
📋 Referenzalternative (nicht im Katalog)
STM32F722ZET6 Grenzwerte & elektrische Eigenschaften
| Core | ARM Cortex-M7 |
| Maximum Clock Speed | 216 MHz |
| Flash Memory | 512 KB |
| SRAM | 256 KB |
| Gehäuse | LQFP144 (20x20 mm) |
| Versorgungsspannung | 1.7V to 3.6V |
| Betriebstemperatur | -40°C to +85°C |
| Number of I/O Pins | 114 |
| ADC Resolution | 12-bit |
| Number of ADC Channels | 24 |
| DAC Resolution | 12-bit |
| Number of DAC Channels | 2 |
| USART Interfaces | 4 |
| SPI Interfaces | 5 |
| I2C Interfaces | 4 |
| USB OTG | HS and FS |
| Ethernet MAC | Yes |
| Camera Interface | Yes |
| Timers | 12 (16-bit and 32-bit) |
| DMA Channels | 16 |
| FPU | Single-precision |
| RoHS-Status | Compliant |
