AD623ARZ-R7 - Rail-to-Rail In-Amp, 3-12V | Analog Devices
部品番号: AD623ARZ-R7 ✓ 生産中| 数量 | 単価 | 小計 |
|---|---|---|
| 1 | $4.2 | $4.20 |
| 10 | $3.78 | $37.80 |
| 100 | $3.3 | $330.00 |
| 500 | $2.9 | $1,450.00 |
| 1,000 | $2.65 | $2,650.00 |
AD623ARZ-R7 概要
An instrumentation amplifier (in-amp) is a type of differential amplifier that amplifies the difference between two input signals while rejecting common-mode voltages. Characterized by high input impedance, high common-mode rejection ratio (CMRR), and low offset voltage, in-amps form a specialized subclass within the operational amplifier family and are essential building blocks in analog signal conditioning chains for precision sensing.
Key features of the AD623ARZ-R7 include gain programming with a single external resistor via the formula G = 1 + 100 kOhm/RG (unity gain with no external resistor), rail-to-rail output swing, and input common-mode range extending 150 mV below ground on a single supply. It operates from single supplies of 3 V to 12 V or dual supplies of +/-2.5 V to +/-6 V, suiting both portable and industrial systems.
Technically, the AD623 uses a classic three-op-amp topology with a laser-trimmed internal precision resistor network. The input stage provides high impedance and excellent CMRR, while the output stage delivers rail-to-rail swing. The REF terminal allows low-impedance level shifting of the output, critical for centering signals in single-supply data acquisition systems. A and B grades differ in offset voltage and drift specifications.
Typical applications include load cell and pressure sensor signal conditioning, medical ECG front ends, thermocouple amplification, and industrial process control, where the high CMRR rejects common-mode noise in electrically noisy environments.
When designing, place the gain resistor close to the device, bypass each supply pin with 0.1 uF, and drive the REF pin from a low-impedance source to preserve CMRR.
This page synthesizes distributor pricing, drop-in alternatives, and practical design notes not found in the manufacturer datasheet.
ドロップイン代替品: AD623ARZ-R7 — 同一パッケージでピン互換。PCBの作り直しが必要な異なるパッケージの部品は除外されています。
このシリーズのバリエーション
同一シリーズでドロップイン互換のモデル: AD623ARZ-R7 （同一形状・フットプリント） — 相違点: Gain Range, Package, CMRR, Amplifier Type, Operating Temperature Range.
クイック比較ツール — 並列比較する代替部品を選択:
AD623ARZ
✅ ドロップイン📋 参考代替品（カタログ未掲載）
AD623BRZ-R7
✅ ドロップイン📋 参考代替品（カタログ未掲載）
AD8226BRZ
✅ ドロップイン✓ 在庫あり
$3.1 / 個
データシートを見る →AD8221ARZ
✅ ドロップイン✓ 在庫あり
$3.29 / 個
データシートを見る →AD620ARZ
✅ ドロップイン✓ 在庫あり
$7.2 / 個
データシートを見る →INA128PA
✅ ドロップイン📋 参考代替品（カタログ未掲載）
INA122PA
✅ ドロップイン📋 参考代替品（カタログ未掲載）
AD623ARZ-R7 最大定格＆電気的特性
| Amplifier Type | Instrumentation Amplifier |
| Number of Circuits | 1 |
| Supply Voltage Range (Single) | 2.7 V to 12 V |
| Supply Voltage Range (Dual) | +/-2.5 V to +/-6 V |
| 出力タイプ | Rail-to-Rail |
| 3 dB Bandwidth | 800 kHz |
| Slew Rate | 0.3 V/us |
| CMRR | 90 dB (min) at G = 1 |
| Gain Setting | Single external resistor, G = 1 + 100 kOhm/RG |
| Gain Range | 1 to 1000+ |
| Input Common-Mode Range | Extends 150 mV below ground (single supply) |
| 動作温度 | -40C to +85C |
| パッケージ | 8-SOIC (0.154 in, 3.90 mm width) |
| 実装タイプ | Surface Mount |
| Packaging | Tape & Reel (R7) |
| RoHS ステータス | Compliant |
| Grade | A grade (B grade offers lower offset/drift) |
AD623ARZ-R7 ピン構成
| ピン 1 | RG- — Gain resistor terminal (connect RG between pins 1 and 8) |
| ピン 2 | -IN — Inverting input |
| ピン 3 | +IN — Non-inverting input |
| ピン 4 | -VS — Negative supply / ground (single supply) |
| ピン 5 | REF — Reference terminal - drive from low impedance to level-shift output |
| ピン 6 | OUTPUT — Rail-to-rail amplifier output |
| ピン 7 | +VS — Positive supply (2.7 V to 12 V single) |
| ピン 8 | RG+ — Gain resistor terminal (connect RG between pins 1 and 8) |
主な用途
AD623ARZ-R7 の用途: 6 件s: Load Cell and Bridge Sensor Conditioning, ECG and Medical Instrumentation Front End, Thermocouple Amplifiers, Industrial Process Control (4-20 mA Loops), Portable and Battery-Powered Data Acquisition, Pressure and Strain Gauge Sensor Interfaces.
Load Cell and Bridge Sensor Conditioning
The AD623ARZ-R7 fits load cell signal conditioning because its single-resistor gain equation (G = 1 + 100 kOhm/RG) directly scales millivolt-level bridge outputs, and its 90 dB minimum CMRR at G = 1 rejects common-mode noise picked up on long cable runs. In a typical circuit, the bridge differential output drives pins 2 and 3, gain is set to 100 or more with RG near 1 kOhm, and REF is tied to a buffered mid-supply or ground reference. The rail-to-rail output maximizes ADC dynamic range on a 5 V single supply, while the 150 mV below-ground input range tolerates bridge offset. Estimated bandwidth at G = 100 is about 8-10 kHz, ample for static weighing.
おすすめ
ECG and Medical Instrumentation Front End
For battery-powered ECG front ends, the AD623ARZ-R7 combines single-supply operation (2.7 V minimum), high input impedance, and strong common-mode rejection - exactly the profile needed to extract weak electrode signals from mains interference. Per the ADI datasheet typical application, the electrodes drive the differential inputs through protection resistors, the gain resistor sets G around 10-100, and the REF pin is driven by a right-leg-drive or mid-supply buffer to keep the output centered. The input common-mode range extending 150 mV below ground accommodates electrode offset on a single 3 V cell. B grade parts (AD623BRZ-R7) with 0.3 uV/C drift improve DC stability for diagnostic-grade designs.
おすすめ
Thermocouple Amplifiers
The AD623ARZ-R7 amplifies microvolt-per-degree thermocouple signals with the DC precision this task demands: low offset, low offset drift, and high CMRR against ground noise. The thermocouple is applied differentially with a bias network referencing inputs within the common-mode range (which extends 150 mV below ground on single supply), gain is set to several hundred via RG, and cold-junction compensation is performed with an RTD or sensor at the connector. The rail-to-rail output lets the signal occupy the full span into a 3.3 V or 5 V ADC. With bandwidth in the low kHz range at high gain, the AD623 is well matched to slow thermal processes.
おすすめ
Industrial Process Control (4-20 mA Loops)
In industrial process control, the AD623ARZ-R7 acts as the precision front end for pressure, flow, and level transmitters, where sensors sit far from the ADC and ground potential differences inject large common-mode voltages. Its 90 dB minimum CMRR (improving at higher gain) and high input impedance preserve signal integrity across these grounds. The REF pin allows direct level shifting of the output to match controller input ranges, and the 12 V maximum single supply tolerates harsh industrial rails. Rail-to-rail output swing ensures the full measured range maps onto the ADC span even at low supply. Gain is reprogrammed with one resistor, simplifying product variants.
おすすめ
Portable and Battery-Powered Data Acquisition
Battery-powered data loggers benefit from the AD623ARZ-R7's 2.7 V minimum supply and rail-to-rail output, which keep full signal swing as the battery discharges from fresh (3.3-4.2 V) toward cutoff. Single-supply operation eliminates a negative rail, reducing cost, size, and quiescent drain versus dual-supply in-amp designs. The input range extending 150 mV below ground simplifies single-supply sensor biasing. Bandwidth of 800 kHz at low gain covers vibration and acoustic channels, while the SOIC-8 footprint suits compact boards. For sub-mA budget analysis, verify total consumption including the gain network current, which flows through RG and scales with gain.
おすすめ
Pressure and Strain Gauge Sensor Interfaces
Piezoresistive pressure sensors and strain gauges produce small differential outputs superimposed on a large common-mode voltage; the AD623ARZ-R7's high CMRR (90 dB minimum at G = 1, typically much higher at gain) rejects this common-mode component while amplifying the differential signal. Because the gain equation needs only one external resistor, one PCB supports multiple pressure ranges by changing RG - valuable across product families. The REF pin ties to a buffered offset so zero-pressure output sits at the desired ADC code. Estimated gain of 50-200 with RG from roughly 500 ohms to 2 kOhm suits typical 10-100 mV full-scale sensors on a 5 V supply.
おすすめ
おすすめ製品の概要
エンジニアリング参考データ: AD623ARZ-R7 — 比較、設計ガイダンス、コンプライアンス情報。
選定ガイド
代替品との比較
| パラメータ | この製品 | AD623ARZ | AD623BRZ-R7 | AD8226BRZ | INA128PA |
|---|---|---|---|---|---|
| Package | 8-SOIC (3.90 mm) | 8-SOIC - same | 8-SOIC - same | 8-SOIC - same | 8-SOIC - same |
| Brand | Analog Devices | Analog Devices | Analog Devices | Texas Instruments | |
| Operating Temperature | -40C to +85C | -40C to +85C | -40C to +125C | -40C to +125C | -40C to +85C |
主な差別化要因
- Single-resistor gain programming with unity gain default （vs INA128PA)
- Lowest-cost precision tier within ADI in-amp family （vs AD8221ARZ)
- Wide low-voltage single-supply range with input below ground （vs AD620ARZ)
設計ノート
Place the gain resistor RG as close as possible to pins 1 and 8 to minimize parasitic series resistance and capacitance, which otherwise degrade gain accuracy and stability at high gains. Use 1% or better, low-TC resistors. Bypass both supply pins with 0.1 uF ceramic capacitors placed within a few millimeters, plus a bulk 10 uF capacitor nearby. Keep the high-impedance input traces short and guarded from switching nodes to preserve CMRR in noisy industrial environments.
Never drive the REF pin (pin 5) from a resistor divider. Any series impedance in REF adds directly to the internal gain-setting network, causing gain error and CMRR degradation. Always buffer REF with a low-output-impedance op amp or tie it directly to ground/a precision reference. Also remember that closed-loop bandwidth scales inversely with gain: at G = 100 the -3 dB point is roughly 8-10 kHz (estimated from the 800 kHz gain-bandwidth behavior), so do not expect 800 kHz at high gain.
The AD623ARZ-R7 accepts single supplies from 2.7 V to 12 V or dual supplies of +/-2.5 V to +/-6 V. On single supply, keep input common-mode within the datasheet range (extending 150 mV below ground but limited near the top rail); verify that the input CMVR versus output swing plot in the ADI datasheet matches your gain and reference configuration. Note the current flowing through RG adds to supply consumption at high gain - size your power budget accordingly in battery designs.
コンプライアンス情報
RoHS compliant and lead-free per the Z-suffix designation in ADI product data; REACH and halogen-free declarations should be verified against current Analog Devices compliance documentation.
