AD4000BRUZ-RL7 - 16-Bit 2MSPS SAR ADC | Analog Devices
MPN: AD4000BRUZ-RL7 β Active| Qty | Unit Price | Extended |
|---|---|---|
| 1 | $40.24 | $40.24 |
| 10 | $36.5 | $365.00 |
| 100 | $32.8 | $3,280.00 |
| 500 | $29.1 | $14,550.00 |
| 1,000 | $25.4 | $25,400.00 |
Drop-in alternatives for AD4000BRUZ-RL7 β same package, pin-to-pin compatible. Different-package parts requiring PCB rework are excluded.
Quick Comparison Tool β Select alternative parts for side-by-side comparison:
AD4000BRUZ
β Drop-Inβ In Stock
$8.1 / Unit
View Datasheet βAD4004BRUZ
β Drop-Inπ Reference alternative (not in catalog)
AD4008BRUZ
β Drop-Inπ Reference alternative (not in catalog)
AD4000BRUZ-RL7 Maximum Ratings & Electrical Characteristics
| Resolution | 16 bits |
| Sampling Rate | 2 MSPS |
| Input Type | Pseudo differential |
| Number of Inputs | 1 |
| Interface | SPI, daisy-chain |
| Supply Voltage (Analog) | 1.8 V |
| Supply Voltage (Digital) | 1.8 V to 5 V |
| Power Dissipation | 3.5 mW at 2 MSPS |
| INL (Integral Nonlinearity) | [DATA_NEEDED: INL value] |
| SNR (Signal-to-Noise Ratio) | [DATA_NEEDED: SNR value] |
| Package | 16-lead TSSOP |
| Operating Temperature Range | -40Β°C to +125Β°C |
| Mounting Type | Surface Mount |
| RoHS Status | Compliant |
| Easy Drive | Yes |
AD4000BRUZ-RL7 Pin Configuration
| Pin 1 | VIN β Analog input |
| Pin 2 | REF β Reference input |
| Pin 3 | GND β Ground |
| Pin 4 | VDD β Analog supply |
| Pin 5 | VIO β Digital supply |
| Pin 6 | SCLK β Serial clock |
| Pin 7 | SDI β Serial data in |
| Pin 8 | SDO β Serial data out |
| Pin 9 | CNV β Convert input |
| Pin 10 | GND β Ground |
| Pin 11 | VDD β Analog supply |
| Pin 12 | REF β Reference input |
| Pin 13 | VIN β Analog input |
| Pin 14 | GND β Ground |
| Pin 15 | VIO β Digital supply |
| Pin 16 | GND β Ground |
Safe Operating Area (SOA) & Thermal Characteristics
No official SOA curve available for this component. Always operate within absolute maximum ratings specified in the datasheet. Ensure adequate cooling and derate as needed.
Typical Applications
AD4000BRUZ-RL7 is suitable for 6 applications: Data Acquisition Systems, Industrial Automation, Medical Instrumentation, Portable Instrumentation, Communication Systems, Test and Measurement.
Data Acquisition Systems
The AD4000BRUZ-RL7 is ideal for high-speed data acquisition systems requiring 16-bit precision at 2 MSPS. Its Easy Drive technology simplifies front-end design by allowing direct connection to sensors without an external driver amplifier, reducing component count and power consumption. The pseudo differential input rejects common-mode noise, making it suitable for industrial environments. With a low power dissipation of 3.5 mW, it is also suitable for multi-channel systems where power is a concern. The SPI interface enables easy integration with microcontrollers and DSPs, and the daisy-chain feature allows multiple ADCs to share a single serial bus, simplifying system design.
Recommended
Industrial Automation
In industrial automation, the AD4000BRUZ-RL7 provides accurate, high-speed conversion for process control, motor control, and condition monitoring. Its 16-bit resolution and 2 MSPS sampling rate enable precise measurement of fast-changing signals. The device operates over a wide temperature range (-40Β°C to +125Β°C), ensuring reliability in harsh environments. The Easy Drive feature reduces the need for external buffering, lowering system cost and complexity. The pseudo differential input helps reject ground noise, which is common in industrial settings. The SPI interface allows direct connection to industrial microcontrollers, and the daisy-chain capability simplifies wiring in multi-channel systems.
Recommended
Medical Instrumentation
The AD4000BRUZ-RL7 is well-suited for medical instrumentation such as patient monitoring, diagnostic imaging, and laboratory equipment. Its high accuracy and low power consumption are critical for battery-operated devices. The 16-bit resolution provides fine detail for physiological signals, while the 2 MSPS sampling rate captures fast transients. The Easy Drive technology allows direct connection to high-impedance sensors like ECG electrodes, simplifying the analog front-end. The small TSSOP package saves board space, and the wide temperature range ensures reliable operation in clinical environments. The SPI interface enables seamless integration with medical-grade microcontrollers.
Recommended
Portable Instrumentation
For portable instruments like handheld multimeters, data loggers, and field analyzers, the AD4000BRUZ-RL7 offers a balance of performance and power efficiency. Its 3.5 mW power dissipation at 2 MSPS extends battery life, and the 1.8V analog supply is compatible with low-voltage batteries. The Easy Drive feature reduces the need for external components, saving space and cost. The pseudo differential input allows accurate measurement of small signals in the presence of common-mode noise. The SPI interface is simple to interface with low-power microcontrollers, and the daisy-chain feature enables multi-channel expansion without additional I/O pins.
Recommended
Communication Systems
In communication systems, the AD4000BRUZ-RL7 is used for baseband signal processing, software-defined radio, and spectrum analysis. Its 2 MSPS sampling rate and 16-bit resolution provide sufficient dynamic range for many communication signals. The low power dissipation is beneficial in portable and remote communication devices. The Easy Drive technology simplifies the interface to RF front-ends, and the pseudo differential input helps reject interference. The SPI interface allows direct connection to FPGAs and DSPs, and the daisy-chain feature enables multiple ADCs to be used in phased-array systems. The wide temperature range ensures reliable operation in outdoor equipment.
Recommended
Test and Measurement
The AD4000BRUZ-RL7 is a key component in test and measurement equipment such as oscilloscopes, spectrum analyzers, and data acquisition cards. Its high speed and precision enable accurate capture of waveforms and transient events. The 16-bit resolution provides fine amplitude resolution, and the 2 MSPS sampling rate is sufficient for many audio and low-frequency applications. The Easy Drive feature reduces the burden on front-end amplifiers, and the pseudo differential input allows accurate measurement of floating signals. The SPI interface is compatible with common test equipment controllers, and the daisy-chain feature allows multiple channels to be synchronized. The device's low power dissipation is an advantage in portable test instruments.
Recommended
Recommended Products Summary
Engineering reference data for AD4000BRUZ-RL7 β comparison, design guidance, and compliance information.
Selection Guide
Comparison with Alternatives
| Parameter | This Product | AD4000BRUZ | AD4004BRUZ | AD4008BRUZ | AD4000BRMZ-RL7 |
|---|---|---|---|---|---|
| Package | 16-lead TSSOP | 16-lead TSSOP | 16-lead TSSOP | 16-lead TSSOP | 10-lead MSOP |
| Brand | Analog Devices | Analog Devices | Analog Devices | Analog Devices | Analog Devices |
| Resolution | 16 bits | 16 bits | 18 bits | 20 bits | 16 bits |
| Sampling Rate | 2 MSPS | 2 MSPS | 2 MSPS | 2 MSPS | 2 MSPS |
| Input Type | Pseudo differential | Pseudo differential | Pseudo differential | Pseudo differential | Pseudo differential |
| Power Dissipation | 3.5 mW | 3.5 mW | 3.5 mW | 3.5 mW | 3.5 mW |
| Interface | SPI, daisy-chain | SPI, daisy-chain | SPI, daisy-chain | SPI, daisy-chain | SPI, daisy-chain |
| Operating Temperature | -40Β°C to +125Β°C | -40Β°C to +125Β°C | -40Β°C to +125Β°C | -40Β°C to +125Β°C | -40Β°C to +125Β°C |
Key Differentiators
- Easy Drive technology reduces input drive requirements (vs AD7980BRMZ)
- Higher sampling rate of 2 MSPS (vs AD7980BRMZ)
- Pseudo differential input for better noise rejection (vs AD7980BRMZ)
Design Notes
The AD4000BRUZ-RL7 requires a clean 1.8V analog supply (VDD) and a separate digital supply (VIO) that can range from 1.8V to 5V. Use low-dropout regulators (LDOs) to generate these supplies and place 0.1uF and 10uF decoupling capacitors close to the VDD and VIO pins. The reference input (REF) should be driven by a low-impedance source, such as a precision reference buffer, to ensure accurate conversions.
For optimal performance, separate analog and digital ground planes and connect them at a single point near the ADC. Route the analog input (VIN) and reference (REF) traces away from digital signals to minimize noise coupling. Use a solid ground plane under the ADC and avoid routing high-speed digital traces beneath the analog input. Place the ADC close to the signal source to reduce trace inductance.
A common mistake is driving the analog input with a high-impedance source without considering the ADC's input capacitance. The Easy Drive feature reduces this issue, but it is still important to ensure the source can settle within the acquisition time. Also, avoid exceeding the absolute maximum ratings on the input pins. Use a series resistor (e.g., 10-50 ohms) to limit input current if overvoltage is possible. Ensure the reference voltage is stable and within the specified range.
Compliance Information
RoHS compliance is indicated by the 'Z' suffix in the part number. Other compliance details are not specified in the provided data.
