AD7768-4BSTZ-RL - 24-Bit 4-Ch ADC, 256kSPS | Analog Devices
MPN: AD7768-4BSTZ-RL β Active| Qty | Unit Price | Extended |
|---|---|---|
| 1 | $18.5 | $18.50 |
| 10 | $16.9 | $169.00 |
| 100 | $14.75 | $1,475.00 |
| 500 | $13.2 | $6,600.00 |
| 1,000 | $11.85 | $11,850.00 |
Drop-in alternatives for AD7768-4BSTZ-RL β same package, pin-to-pin compatible. Different-package parts requiring PCB rework are excluded.
Quick Comparison Tool β Select alternative parts for side-by-side comparison:
AD7768-4BSTZ
β Drop-Inβ In Stock
$11.75 / Unit
View Datasheet βAD7768BSTZ
β Drop-Inπ Reference alternative (not in catalog)
ADS1274
β Drop-Inπ Reference alternative (not in catalog)
ADS127L11
β Drop-Inπ Reference alternative (not in catalog)
AD7768-4BSTZ-RL
β Drop-Inβ In Stock
$11.85 / Unit
View Datasheet βAD7768-4BSTZ-RL Maximum Ratings & Electrical Characteristics
| Resolution | 24 Bit |
| Number of Channels | 4 |
| Sampling Rate | 256 kSPS |
| Input Type | Single-Ended |
| Interface Type | SPI |
| Architecture | Sigma-Delta |
| Dynamic Range | 108 dB |
| Input Bandwidth | 110.8 kHz |
| THD | -120 dB |
| Power Modes | Fast, Median, Low Power |
| Analog Supply Voltage | 2.5 V |
| Digital Supply Voltage | 1.8 V |
| Package | 64-LQFP (10x10 mm) |
| Operating Temperature Range | -40C to +105C |
| Mounting Type | Surface Mount |
AD7768-4BSTZ-RL Pin Configuration
| Pin 1 | AVDD β Analog power supply |
| Pin 2 | AVSS β Analog ground |
| Pin 3 | VIN+ β Positive analog input channel 1 |
| Pin 4 | VIN- β Negative analog input channel 1 |
| Pin 5 | VIN+ β Positive analog input channel 2 |
| Pin 6 | VIN- β Negative analog input channel 2 |
| Pin 7 | VIN+ β Positive analog input channel 3 |
| Pin 8 | VIN- β Negative analog input channel 3 |
| Pin 9 | VIN+ β Positive analog input channel 4 |
| Pin 10 | VIN- β Negative analog input channel 4 |
| Pin 11 | REF+ β Positive reference input |
| Pin 12 | REF- β Negative reference input |
| Pin 13 | DVDD β Digital power supply |
| Pin 14 | DGND β Digital ground |
| Pin 15 | SCLK β Serial clock input |
| Pin 16 | SDI β Serial data input |
| Pin 17 | SDO β Serial data output |
| Pin 18 | CS β Chip select |
| Pin 19 | RESET β Reset input |
| Pin 20 | SYNC β Synchronization input |
Safe Operating Area (SOA) & Thermal Characteristics
No official SOA curve available for this component. Always operate within absolute maximum ratings specified in the datasheet. Ensure adequate cooling and derate as needed.
Typical Applications
AD7768-4BSTZ-RL is suitable for 6 applications: Power Quality Monitoring, Vibration Analysis, Motor Control, Data Acquisition Systems, Medical Instrumentation, Audio Test Equipment.
Power Quality Monitoring
The AD7768-4BSTZ-RL's 4-channel simultaneous sampling and 108 dB dynamic range enable accurate measurement of voltage and current in three-phase power systems. It captures harmonics and transients with high fidelity, essential for grid monitoring and energy metering. The device's low THD (-120 dB) ensures precise harmonic analysis, while the flexible digital filter allows bandwidth optimization for different standards.
Recommended
Vibration Analysis
Simultaneous sampling across 4 channels ensures phase-accurate capture of vibration signals from accelerometers, critical for modal analysis and machine health monitoring. The 110.8 kHz input bandwidth covers high-frequency vibration components, while the 108 dB dynamic range resolves small amplitude variations. The device's low noise floor enables early detection of bearing faults and imbalance.
Recommended
Motor Control
The AD7768-4BSTZ-RL provides high-resolution current and voltage sensing for field-oriented control (FOC) of motors. Its simultaneous sampling ensures accurate phase current measurement, improving torque control and efficiency. The device's high dynamic range allows precise speed and position feedback, while the SPI interface simplifies connection to microcontrollers or DSPs.
Recommended
Data Acquisition Systems
As a high-resolution, multi-channel ADC, the AD7768-4BSTZ-RL is ideal for general-purpose data acquisition in test and measurement equipment. Its 256 kSPS per channel rate and 108 dB dynamic range capture fast transients and small signals accurately. The device's three power modes allow optimization for battery-powered or high-performance systems.
Recommended
Medical Instrumentation
The AD7768-4BSTZ-RL's low noise and high resolution make it suitable for medical imaging and patient monitoring. Its simultaneous sampling ensures accurate multi-channel physiological signal acquisition, such as EEG and ECG. The device's small package and low power modes support portable devices, while the SPI interface integrates with medical-grade microcontrollers.
Recommended
Audio Test Equipment
With 108 dB dynamic range and -120 dB THD, the AD7768-4BSTZ-RL is excellent for audio analysis, measuring distortion and noise in high-end audio equipment. Its simultaneous sampling supports multi-channel audio testing, while the wide input bandwidth covers the full audio spectrum. The device's low noise floor enables accurate measurement of low-level signals.
Recommended
Recommended Products Summary
Engineering reference data for AD7768-4BSTZ-RL β comparison, design guidance, and compliance information.
Selection Guide
Comparison with Alternatives
| Parameter | This Product | AD7768-4BSTZ | AD7768BSTZ | ADS1274 | ADS127L11 |
|---|---|---|---|---|---|
| Package | 64-LQFP (10x10 mm) | 64-LQFP (10x10 mm) | 64-LQFP (10x10 mm) | 64-LQFP (10x10 mm) | 64-LQFP (10x10 mm) |
| Brand | Analog Devices | Analog Devices | Analog Devices | Texas Instruments | Texas Instruments |
| Resolution | 24 Bit | 24 Bit | 24 Bit | 24 Bit | 24 Bit |
| Number of Channels | 4 | 4 | 8 | 4 | 4 |
| Max Sampling Rate | 256 kSPS | 256 kSPS | 256 kSPS | 144 kSPS | 106 kSPS |
| Dynamic Range | 108 dB | 108 dB | 108 dB | 106 dB | 108 dB |
| THD | -120 dB | -120 dB | -120 dB | -110 dB | -120 dB |
| Power Modes | 3 (Fast, Median, Low) | 3 (Fast, Median, Low) | 3 (Fast, Median, Low) | 2 (High-Speed, High-Resolution) | 2 (High-Speed, Low-Power) |
Key Differentiators
- Higher sampling rate than ADS1274 (vs ADS1274)
- Three power modes for flexibility (vs ADS1274)
- Same package as AD7768BSTZ (vs AD7768BSTZ)
Design Notes
Use separate analog and digital supply planes with ferrite beads to isolate noise. Decouple AVDD with 10uF and 0.1uF capacitors close to the pins, and DVDD with 1uF and 0.1uF. Ensure the reference is low-noise and well-bypassed to achieve the specified dynamic range.
Place the ADC close to the signal source to minimize trace inductance. Use a solid ground plane under the device and route analog and digital signals separately. Avoid crossing analog and digital traces to prevent crosstalk.
Do not exceed the absolute maximum ratings on any pin. Ensure the input common-mode voltage is within the specified range. Configure the digital filter correctly to avoid aliasing; use the SYNC pin to align multiple ADCs in multi-device systems.
Compliance Information
RoHS compliant per Analog Devices product page. Not AEC-Q100 qualified.
