STM32F779ZIT6 - 2MB Flash, 216MHz Cortex-M7 MCU | STMicroelectronics
MPN: STM32F779ZIT6 β Active| Qty | Unit Price | Extended |
|---|---|---|
| 1 | $18.5 | $18.50 |
| 10 | $16.8 | $168.00 |
| 100 | $14.2 | $1,420.00 |
| 500 | $12.9 | $6,450.00 |
| 1,000 | $11.75 | $11,750.00 |
Drop-in alternatives for STM32F779ZIT6 β same package, pin-to-pin compatible. Different-package parts requiring PCB rework are excluded.
Quick Comparison Tool β Select alternative parts for side-by-side comparison:
STM32F769ZIT6
β Drop-Inπ Reference alternative (not in catalog)
STM32F767ZIT6
β Drop-Inβ 99,999 In Stock
$19.25 / Unit
View Datasheet βSTM32F756ZIT6
β Drop-Inπ Reference alternative (not in catalog)
STM32F746ZIT6
β Drop-Inπ Reference alternative (not in catalog)
STM32F745ZIT6
β Drop-Inπ Reference alternative (not in catalog)
STM32F779ZIT6 Maximum Ratings & Electrical Characteristics
| Core | ARM Cortex-M7 |
| Core Clock Speed | 216 MHz |
| Flash Memory | 2 MB |
| SRAM | 512 KB |
| Package | LQFP144 (20x20 mm) |
| Supply Voltage | 1.7V to 3.6V |
| Operating Temperature | -40Β°C to +85Β°C |
| Number of I/O Pins | 114 |
| ADC Resolution | 12-bit |
| Number of ADCs | 3 |
| DAC Resolution | 12-bit |
| Number of DACs | 2 |
| Timers | 12 (16-bit and 32-bit) |
| Communication Interfaces | 4x USART, 4x SPI, 4x I2C, 2x CAN, USB OTG FS/HS, Ethernet MAC |
| Cryptographic Acceleration | AES, DES, 3DES, TRNG |
| Graphics Acceleration | Chrom-ART Accelerator (DMA2D) |
| CoreMark Score | 1082 at 216 MHz |
| RoHS Status | Compliant |
STM32F779ZIT6 Pin Configuration
| Pin 1 | PE2 β General purpose I/O or alternate function |
| Pin 2 | PE3 β General purpose I/O or alternate function |
| Pin 3 | PE4 β General purpose I/O or alternate function |
| Pin 4 | PE5 β General purpose I/O or alternate function |
| Pin 5 | PE6 β General purpose I/O or alternate function |
| Pin 6 | VBAT β Backup battery supply |
| Pin 7 | PC13 β General purpose I/O or RTC output |
| Pin 8 | PC14 β General purpose I/O or OSC32_IN |
| Pin 9 | PC15 β General purpose I/O or OSC32_OUT |
| Pin 10 | PF0 β General purpose I/O or alternate function |
| Pin 11 | PF1 β General purpose I/O or alternate function |
| Pin 12 | PF2 β General purpose I/O or alternate function |
| Pin 13 | PF3 β General purpose I/O or alternate function |
| Pin 14 | PF4 β General purpose I/O or alternate function |
| Pin 15 | PF5 β General purpose I/O or alternate function |
| Pin 16 | VSS β Ground |
| Pin 17 | VDD β Power supply |
| Pin 18 | PF6 β General purpose I/O or alternate function |
| Pin 19 | PF7 β General purpose I/O or alternate function |
| Pin 20 | PF8 β General purpose I/O or alternate function |
| Pin 21 | PF9 β General purpose I/O or alternate function |
| Pin 22 | PF10 β General purpose I/O or alternate function |
| Pin 23 | PF11 β General purpose I/O or alternate function |
| Pin 24 | PF12 β General purpose I/O or alternate function |
| Pin 25 | PF13 β General purpose I/O or alternate function |
| Pin 26 | PF14 β General purpose I/O or alternate function |
| Pin 27 | PF15 β General purpose I/O or alternate function |
| Pin 28 | VSS β Ground |
| Pin 29 | VDD β Power supply |
| Pin 30 | PG0 β General purpose I/O or alternate function |
| Pin 31 | PG1 β General purpose I/O or alternate function |
| Pin 32 | PG2 β General purpose I/O or alternate function |
| Pin 33 | PG3 β General purpose I/O or alternate function |
| Pin 34 | PG4 β General purpose I/O or alternate function |
| Pin 35 | PG5 β General purpose I/O or alternate function |
| Pin 36 | PG6 β General purpose I/O or alternate function |
| Pin 37 | PG7 β General purpose I/O or alternate function |
| Pin 38 | PG8 β General purpose I/O or alternate function |
| Pin 39 | PG9 β General purpose I/O or alternate function |
| Pin 40 | PG10 β General purpose I/O or alternate function |
| Pin 41 | PG11 β General purpose I/O or alternate function |
| Pin 42 | PG12 β General purpose I/O or alternate function |
| Pin 43 | PG13 β General purpose I/O or alternate function |
| Pin 44 | PG14 β General purpose I/O or alternate function |
| Pin 45 | PG15 β General purpose I/O or alternate function |
| Pin 46 | VSS β Ground |
| Pin 47 | VDD β Power supply |
| Pin 48 | PH0 β General purpose I/O or OSC_IN |
| Pin 49 | PH1 β General purpose I/O or OSC_OUT |
| Pin 50 | PH2 β General purpose I/O or alternate function |
| Pin 51 | PH3 β General purpose I/O or alternate function |
| Pin 52 | PH4 β General purpose I/O or alternate function |
| Pin 53 | PH5 β General purpose I/O or alternate function |
| Pin 54 | PH6 β General purpose I/O or alternate function |
| Pin 55 | PH7 β General purpose I/O or alternate function |
| Pin 56 | PH8 β General purpose I/O or alternate function |
| Pin 57 | PH9 β General purpose I/O or alternate function |
| Pin 58 | PH10 β General purpose I/O or alternate function |
| Pin 59 | PH11 β General purpose I/O or alternate function |
| Pin 60 | PH12 β General purpose I/O or alternate function |
| Pin 61 | PH13 β General purpose I/O or alternate function |
| Pin 62 | PH14 β General purpose I/O or alternate function |
| Pin 63 | PH15 β General purpose I/O or alternate function |
| Pin 64 | VSS β Ground |
| Pin 65 | VDD β Power supply |
| Pin 66 | PI0 β General purpose I/O or alternate function |
| Pin 67 | PI1 β General purpose I/O or alternate function |
| Pin 68 | PI2 β General purpose I/O or alternate function |
| Pin 69 | PI3 β General purpose I/O or alternate function |
| Pin 70 | PI4 β General purpose I/O or alternate function |
| Pin 71 | PI5 β General purpose I/O or alternate function |
| Pin 72 | PI6 β General purpose I/O or alternate function |
| Pin 73 | PI7 β General purpose I/O or alternate function |
| Pin 74 | PI8 β General purpose I/O or alternate function |
| Pin 75 | PI9 β General purpose I/O or alternate function |
| Pin 76 | PI10 β General purpose I/O or alternate function |
| Pin 77 | PI11 β General purpose I/O or alternate function |
| Pin 78 | PI12 β General purpose I/O or alternate function |
| Pin 79 | PI13 β General purpose I/O or alternate function |
| Pin 80 | PI14 β General purpose I/O or alternate function |
| Pin 81 | PI15 β General purpose I/O or alternate function |
| Pin 82 | VSS β Ground |
| Pin 83 | VDD β Power supply |
| Pin 84 | PA0 β General purpose I/O or alternate function |
| Pin 85 | PA1 β General purpose I/O or alternate function |
| Pin 86 | PA2 β General purpose I/O or alternate function |
| Pin 87 | PA3 β General purpose I/O or alternate function |
| Pin 88 | PA4 β General purpose I/O or alternate function |
| Pin 89 | PA5 β General purpose I/O or alternate function |
| Pin 90 | PA6 β General purpose I/O or alternate function |
| Pin 91 | PA7 β General purpose I/O or alternate function |
| Pin 92 | PA8 β General purpose I/O or alternate function |
| Pin 93 | PA9 β General purpose I/O or alternate function |
| Pin 94 | PA10 β General purpose I/O or alternate function |
| Pin 95 | PA11 β General purpose I/O or alternate function |
| Pin 96 | PA12 β General purpose I/O or alternate function |
| Pin 97 | PA13 β General purpose I/O or alternate function (SWDIO) |
| Pin 98 | PA14 β General purpose I/O or alternate function (SWCLK) |
| Pin 99 | PA15 β General purpose I/O or alternate function |
| Pin 100 | VSS β Ground |
| Pin 101 | VDD β Power supply |
| Pin 102 | PC0 β General purpose I/O or alternate function |
| Pin 103 | PC1 β General purpose I/O or alternate function |
| Pin 104 | PC2 β General purpose I/O or alternate function |
| Pin 105 | PC3 β General purpose I/O or alternate function |
| Pin 106 | PC4 β General purpose I/O or alternate function |
| Pin 107 | PC5 β General purpose I/O or alternate function |
| Pin 108 | PB0 β General purpose I/O or alternate function |
| Pin 109 | PB1 β General purpose I/O or alternate function |
| Pin 110 | PB2 β General purpose I/O or alternate function |
| Pin 111 | PB3 β General purpose I/O or alternate function |
| Pin 112 | PB4 β General purpose I/O or alternate function |
| Pin 113 | PB5 β General purpose I/O or alternate function |
| Pin 114 | PB6 β General purpose I/O or alternate function |
| Pin 115 | PB7 β General purpose I/O or alternate function |
| Pin 116 | PB8 β General purpose I/O or alternate function |
| Pin 117 | PB9 β General purpose I/O or alternate function |
| Pin 118 | PB10 β General purpose I/O or alternate function |
| Pin 119 | PB11 β General purpose I/O or alternate function |
| Pin 120 | VSS β Ground |
| Pin 121 | VDD β Power supply |
| Pin 122 | PB12 β General purpose I/O or alternate function |
| Pin 123 | PB13 β General purpose I/O or alternate function |
| Pin 124 | PB14 β General purpose I/O or alternate function |
| Pin 125 | PB15 β General purpose I/O or alternate function |
| Pin 126 | PD8 β General purpose I/O or alternate function |
| Pin 127 | PD9 β General purpose I/O or alternate function |
| Pin 128 | PD10 β General purpose I/O or alternate function |
| Pin 129 | PD11 β General purpose I/O or alternate function |
| Pin 130 | PD12 β General purpose I/O or alternate function |
| Pin 131 | PD13 β General purpose I/O or alternate function |
| Pin 132 | PD14 β General purpose I/O or alternate function |
| Pin 133 | PD15 β General purpose I/O or alternate function |
| Pin 134 | PC6 β General purpose I/O or alternate function |
| Pin 135 | PC7 β General purpose I/O or alternate function |
| Pin 136 | PC8 β General purpose I/O or alternate function |
| Pin 137 | PC9 β General purpose I/O or alternate function |
| Pin 138 | PA0 β General purpose I/O or alternate function |
| Pin 139 | PA1 β General purpose I/O or alternate function |
| Pin 140 | PA2 β General purpose I/O or alternate function |
| Pin 141 | PA3 β General purpose I/O or alternate function |
| Pin 142 | VSS β Ground |
| Pin 143 | VDD β Power supply |
| Pin 144 | PA4 β General purpose I/O or alternate function |
Safe Operating Area (SOA) & Thermal Characteristics
No official SOA curve available for this digital IC. Always operate within absolute maximum ratings specified in the datasheet. Ensure adequate cooling and derate as needed.
Typical Applications
STM32F779ZIT6 is suitable for 6 applications: Industrial Automation, IoT Gateway, Medical Devices, Consumer Electronics, Smart Energy, Audio Processing.
Industrial Automation
The STM32F779ZIT6 is ideal for industrial automation due to its high-performance Cortex-M7 core, extensive communication interfaces (Ethernet, CAN, USART, SPI, I2C), and real-time control capabilities. It can handle complex PLC logic, motor control, and HMI interfaces. The hardware cryptographic processor ensures secure communication in industrial IoT networks. With 2 MB Flash and 512 KB SRAM, it can store large control algorithms and data logs. The wide temperature range (-40Β°C to +85Β°C) and robust peripherals make it suitable for factory floor environments. Its 12-bit ADCs and timers enable precise sensor acquisition and PWM generation for motor drives. The Chrom-ART Accelerator offloads graphics rendering for operator panels, reducing CPU load. Overall, the STM32F779ZIT6 provides a single-chip solution for advanced industrial controllers, reducing BOM cost and board space.
Recommended
IoT Gateway
The STM32F779ZIT6 is well-suited for IoT gateways that aggregate data from multiple sensors and communicate with cloud services. Its Ethernet MAC and USB OTG interfaces enable wired and wireless connectivity options. The hardware cryptographic processor accelerates TLS/DTLS handshakes, ensuring secure data transmission. The 2 MB Flash can store protocol stacks (MQTT, CoAP) and firmware updates. The 512 KB SRAM supports buffering of sensor data and multitasking. The low-power modes (Sleep, Stop, Standby) help optimize energy consumption in battery-powered gateways. The Chrom-ART Accelerator can drive a local display for status monitoring. With its rich peripheral set, the STM32F779ZIT6 can interface with various sensors via SPI, I2C, and UART, making it a central hub in smart home and industrial IoT deployments.
Recommended
Medical Devices
The STM32F779ZIT6 is suitable for medical devices such as patient monitors, infusion pumps, and diagnostic equipment. Its high processing power enables real-time signal processing for ECG, EEG, and blood pressure monitoring. The multiple ADCs can sample analog sensor outputs simultaneously. The hardware cryptographic processor ensures secure storage and transmission of patient data, complying with data privacy regulations. The large memory can store patient records and firmware. The device's reliability and wide temperature range make it suitable for clinical environments. The Chrom-ART Accelerator can drive graphical user interfaces for touchscreens, enhancing user experience. The STM32F779ZIT6's low power consumption is beneficial for portable medical devices. Its extensive communication interfaces allow integration with hospital networks and medical peripherals.
Recommended
Consumer Electronics
The STM32F779ZIT6 powers high-end consumer electronics like smart home hubs, audio systems, and wearable devices. Its Cortex-M7 core delivers the performance needed for audio processing, voice recognition, and user interfaces. The Chrom-ART Accelerator enables smooth graphics on TFT displays. The hardware cryptographic processor secures over-the-air updates and user data. The 2 MB Flash can store large audio samples and UI assets. The device supports various connectivity options (USB, Ethernet, CAN) for smart home integration. Its low-power modes extend battery life in portable devices. The rich peripheral set allows interfacing with touchscreens, sensors, and audio codecs. The STM32F779ZIT6's high integration reduces component count, making it cost-effective for mass-produced consumer products.
Recommended
Smart Energy
The STM32F779ZIT6 is used in smart energy systems such as smart meters, solar inverters, and energy management units. Its high-speed ADCs and timers enable accurate measurement of voltage and current waveforms. The Ethernet and CAN interfaces support communication with grid infrastructure and home energy management systems. The hardware cryptographic processor secures communication protocols for billing and data integrity. The large memory can store energy consumption data and firmware updates. The device's wide operating temperature range is suitable for outdoor installations. The STM32F779ZIT6's real-time capabilities enable precise control of power conversion stages in inverters. Its low power consumption is beneficial for battery-powered monitoring devices. The rich peripheral set allows interfacing with metering ICs and communication modules.
Recommended
Audio Processing
The STM32F779ZIT6 is ideal for audio processing applications such as digital audio workstations, effects processors, and smart speakers. Its Cortex-M7 core with FPU can handle real-time audio algorithms like filtering, equalization, and noise reduction. The multiple I2S interfaces allow connection to high-quality audio codecs. The 2 MB Flash can store audio samples and processing code. The 512 KB SRAM supports large audio buffers. The Chrom-ART Accelerator can drive a user interface for audio control. The hardware cryptographic processor can secure audio streaming. The device's low latency and deterministic performance ensure glitch-free audio. The STM32F779ZIT6's rich peripheral set includes SAI (serial audio interface) for multi-channel audio. Its low power consumption is suitable for portable audio devices.
Recommended
Recommended Products Summary
Engineering reference data for STM32F779ZIT6 β comparison, design guidance, and compliance information.
Selection Guide
Comparison with Alternatives
| Parameter | This Product | STM32F769ZIT6 | STM32F767ZIT6 | STM32F756ZIT6 | STM32F746ZIT6 | STM32F745ZIT6 |
|---|---|---|---|---|---|---|
| Package | LQFP144 | LQFP144 | LQFP144 | LQFP144 | LQFP144 | LQFP144 |
| Brand | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Core Clock Speed | 216 MHz | 216 MHz | 216 MHz | 216 MHz | 216 MHz | 216 MHz |
| Flash Memory | 2 MB | 2 MB | 2 MB | 1 MB | 1 MB | 1 MB |
| SRAM | 512 KB | 512 KB | 512 KB | 320 KB | 320 KB | 320 KB |
| Hardware Crypto | Yes (AES, DES, 3DES, TRNG) | No | No | No | No | No |
| Chrom-ART Accelerator | Yes | Yes | Yes | Yes | Yes | Yes |
| Ethernet MAC | Yes | Yes | Yes | Yes | Yes | Yes |
Key Differentiators
- Hardware cryptographic processor with AES, DES, 3DES, and TRNG (vs STM32F769ZIT6)
- 2 MB Flash and 512 KB SRAM (vs STM32F756ZIT6)
- Chrom-ART Accelerator (DMA2D) (vs STM32F745ZIT6)
Design Notes
The STM32F779ZIT6 operates from 1.7V to 3.6V. Use a clean power supply with proper decoupling: place a 100nF ceramic capacitor close to each VDD/VSS pair, and a 4.7uF bulk capacitor on the main supply. The VDDA pin should be connected to a filtered analog supply (e.g., via a ferrite bead) to minimize ADC noise. For battery-powered applications, utilize the low-power modes (Sleep, Stop, Standby) to extend battery life.
For the LQFP144 package, ensure adequate copper pour on the ground plane to reduce thermal resistance. The theta_JA is approximately 40Β°C/W, so for high-current applications, add thermal vias under the exposed pad (if present) and increase copper area. Keep high-speed signal traces (Ethernet, USB) impedance-controlled and away from noisy power traces. Follow ST's layout guidelines in the datasheet and application notes.
Do not exceed the absolute maximum ratings: VDD max 3.6V, and any pin voltage must not exceed VDD+0.3V. Ensure the boot pins (BOOT0, BOOT1) are configured correctly for the desired boot mode. When using the hardware cryptographic processor, initialize it properly and handle key storage securely. Also, be aware that the STM32F779ZIT6 is not AEC-Q100 qualified; for automotive applications, consider the STM32F779AI (AEC-Q100) variant if available.
Compliance Information
RoHS compliant per STMicroelectronics product page. Not AEC-Q100 qualified; for automotive, use STM32F779AI (if available) or other automotive-grade parts.
