DRV8313PWPR - 2.5A Triple 1/2-H Bridge Driver | TI
料号： DRV8313PWPR ✓ 量产中| 数量 | 单价 | 小计 |
|---|---|---|
| 1 | $4.6364 | $4.64 |
| 10 | $3.3485 | $33.49 |
| 100 | $2.9621 | $296.21 |
| 500 | $2.8333 | $1,416.65 |
| 1,000 | $2.7045 | $2,704.50 |
DRV8313PWPR 概述
A motor driver is an integrated circuit that translates low-power control signals from a microcontroller into the higher voltage and current needed to drive a motor. The DRV8313PWPR is a triple 1/2-H bridge driver, meaning it contains three independent half-bridge outputs, each capable of sourcing or sinking current. This configuration is ideal for driving three-phase brushless-DC motors, where each phase is connected to one half-bridge. The device also supports independent control of each half-bridge, allowing it to drive solenoids, relays, or other loads.
Key features of the DRV8313PWPR include a wide operating voltage range of 8V to 60V, low on-resistance MOSFETs for high efficiency, and overcurrent, overtemperature, and undervoltage lockout protection. The device also features a low-power sleep mode to reduce quiescent current when the motor is not running. These features make it a robust choice for demanding motor control applications.
The DRV8313PWPR uses a simple PWM interface, allowing direct connection to a microcontroller's PWM outputs. Each half-bridge can be controlled independently, enabling flexible motor control schemes such as trapezoidal or sinusoidal commutation. The device also includes a current-sense output that can be used for closed-loop current control, enhancing system performance.
Typical applications include three-phase brushless-DC motor drives for fans, pumps, and robotics, as well as solenoid drivers and other inductive loads. The wide voltage range and high current capability make it suitable for both 12V and 24V systems, common in industrial and automotive environments.
When designing with the DRV8313PWPR, ensure adequate PCB copper area for heat dissipation, especially at high currents. The exposed thermal pad should be soldered to a large ground plane to improve thermal performance. Additionally, place decoupling capacitors close to the power supply pins to minimize voltage transients.
直接替换替代料： DRV8313PWPR ——相同封装，引脚兼容。需要 PCB 改动的不同封装料号已排除。
快速对比工具——选择替代料号进行并排对比：
DRV8313PWP
📋 参考替代料（不在目录中）
DRV8313PWPRG4
📋 参考替代料（不在目录中）
DRV8313PWPRQ1
📋 参考替代料（不在目录中）
DRV8312DDW
📋 参考替代料（不在目录中）
L6235
📋 参考替代料（不在目录中）
DRV8313PWPR 最大额定值与电气特性
| Output Current | 2.5 A continuous per channel, 3 A peak |
| Supply Voltage Range | 8 V to 60 V |
| 输出配置 | Triple 1/2-H bridge |
| 输出数量 | 3 |
| Control Interface | PWM |
| 工作温度范围 | -40°C to 125°C |
| 封装 | HTSSOP (PWP) 28-pin |
| 安装类型 | Surface Mount |
| RoHS 状态 | Compliant |
| MSL 等级 | 3 (168 hours) |
| Protection Features | Overcurrent, overtemperature, undervoltage lockout |
| Sleep Mode | Yes |
| Current Sense Output | Yes |
| Motor Type | Three-phase brushless-DC |
DRV8313PWPR 引脚配置
| 引脚 1 | OUT1 — Half-bridge output 1 |
| 引脚 2 | OUT2 — Half-bridge output 2 |
| 引脚 3 | OUT3 — Half-bridge output 3 |
| 引脚 4 | GND — Ground |
| 引脚 5 | GND — Ground |
| 引脚 6 | VM — Motor supply voltage |
| 引脚 7 | VM — Motor supply voltage |
| 引脚 8 | IN1 — Control input for OUT1 |
| 引脚 9 | IN2 — Control input for OUT2 |
| 引脚 10 | IN3 — Control input for OUT3 |
| 引脚 11 | SLEEP — Sleep mode control (active low) |
| 引脚 12 | VCP — Charge pump capacitor connection |
| 引脚 13 | VREG — Regulator output |
| 引脚 14 | GND — Ground |
| 引脚 15 | GND — Ground |
| 引脚 16 | OUT1 — Half-bridge output 1 (duplicate) |
| 引脚 17 | OUT2 — Half-bridge output 2 (duplicate) |
| 引脚 18 | OUT3 — Half-bridge output 3 (duplicate) |
| 引脚 19 | GND — Ground |
| 引脚 20 | GND — Ground |
| 引脚 21 | VM — Motor supply voltage (duplicate) |
| 引脚 22 | VM — Motor supply voltage (duplicate) |
| 引脚 23 | IN1 — Control input for OUT1 (duplicate) |
| 引脚 24 | IN2 — Control input for OUT2 (duplicate) |
| 引脚 25 | IN3 — Control input for OUT3 (duplicate) |
| 引脚 26 | SLEEP — Sleep mode control (duplicate) |
| 引脚 27 | VCP — Charge pump capacitor connection (duplicate) |
| 引脚 28 | VREG — Regulator output (duplicate) |
典型应用
DRV8313PWPR 适用于 6 应用s: Three-Phase BLDC Motor Drive, Robotics Actuators, Industrial Automation, Automotive Auxiliary Motors, Home Appliances, Medical Devices.
Three-Phase BLDC Motor Drive
The DRV8313PWPR is ideal for driving three-phase brushless-DC motors in applications such as fans, pumps, and drones. Its 2.5A continuous current capability and 8V-60V supply range make it suitable for a wide variety of motor sizes. The integrated half-bridge drivers simplify the circuit, reducing component count and board space. PWM control allows precise speed and torque regulation, while the current sense output enables closed-loop control for improved efficiency and performance.
推荐
Robotics Actuators
In robotics, the DRV8313PWPR can drive DC motors and solenoids used in actuators. Its independent half-bridge control allows driving multiple loads with a single IC, saving space and cost. The wide voltage range supports various battery configurations, and the protection features ensure reliable operation in dynamic environments. The compact HTSSOP package is suitable for space-constrained robot designs.
推荐
Industrial Automation
The DRV8313PWPR is well-suited for industrial automation equipment such as conveyor belts, pumps, and valve actuators. Its robust protection features (overcurrent, overtemperature, undervoltage) ensure reliable operation in harsh environments. The 8V-60V supply range accommodates standard industrial voltages (24V, 48V). The device's PWM interface allows easy integration with PLCs or industrial microcontrollers.
推荐
Automotive Auxiliary Motors
In automotive applications, the DRV8313PWPR can drive auxiliary motors such as cooling fans, window lifts, and seat adjusters. The wide supply voltage range (8V-60V) covers both 12V and 24V automotive systems. The device's protection features are essential for automotive reliability. The HTSSOP package is suitable for engine control units (ECUs) and body control modules (BCMs).
推荐
Home Appliances
The DRV8313PWPR is used in home appliances like washing machines, dishwashers, and vacuum cleaners to drive BLDC motors. Its low on-resistance and high efficiency help reduce power consumption, meeting energy efficiency standards. The compact package and integrated protection features simplify design and improve reliability. The device's PWM interface is compatible with common appliance microcontrollers.
推荐
Medical Devices
In medical devices such as infusion pumps, ventilators, and surgical tools, the DRV8313PWPR provides reliable motor control. Its wide voltage range and protection features ensure safe operation. The compact HTSSOP package is suitable for portable and space-constrained medical equipment. The device's low quiescent current in sleep mode helps extend battery life in portable devices.
推荐
推荐产品汇总
工程参考数据： DRV8313PWPR ——对比、设计指导和合规信息。
选型指南
与替代料对比
| 参数 | 本产品 | DRV8313PWP | DRV8312DDW | L6235 |
|---|---|---|---|---|
| Package | HTSSOP-28 (PWP) | HTSSOP-28 (PWP) | HTSSOP-28 (PWP) | HTSSOP-28 (PWP) |
| Brand | Texas Instruments | Texas Instruments | Texas Instruments | STMicroelectronics |
| Output Current (Continuous) | 2.5 A | 2.5 A | 3.5 A | 1.4 A |
| Supply Voltage Range | 8 V to 60 V | 8 V to 60 V | 8 V to 60 V | 8 V to 52 V |
| Control Interface | PWM | PWM | PWM | PWM |
| Protection Features | Overcurrent, Overtemperature, UVLO | Overcurrent, Overtemperature, UVLO | Overcurrent, Overtemperature, UVLO | Overcurrent, Overtemperature, UVLO |
| Sleep Mode | Yes | Yes | Yes | No |
| Automotive Grade | No | No | No | No |
关键差异点
- Wide supply voltage range (8V-60V) （对比 L6235)
- Higher continuous current (2.5A vs 1.4A) （对比 L6235)
- Sleep mode for power saving （对比 L6235)
设计说明
The DRV8313PWPR can dissipate significant power at high currents. The HTSSOP-28 package has an exposed thermal pad that must be soldered to a large ground plane. For continuous operation at 2.5A per channel, ensure the PCB has adequate copper area and vias to conduct heat away. Consider using thermal vias under the pad to improve heat transfer to inner layers.
Place a 0.1uF ceramic capacitor close to each VM pin and a 10uF bulk capacitor near the VM supply. The charge pump capacitor (VCP) should be placed close to the VCP pin. Keep the high-current output traces short and wide to minimize inductance and resistance. Separate the power ground and signal ground to reduce noise.
Do not exceed the absolute maximum supply voltage of 60V. Ensure the SLEEP pin is pulled high for normal operation; leaving it floating may cause unpredictable behavior. The current sense output is a voltage proportional to the load current; use it with an ADC for closed-loop control. Avoid switching the outputs while the motor is spinning at high speed without proper freewheeling diodes.
合规信息
RoHS compliant per distributor listings. Not AEC-Q100 qualified; use Q1 variant for automotive.
