DRV8313PWPR - 2.5A Triple 1/2-H Bridge Driver | TI
MPN: DRV8313PWPR β Active| Qty | Unit Price | Extended |
|---|---|---|
| 1 | $3.45 | $3.45 |
| 10 | $3.1 | $31.00 |
| 100 | $2.58 | $258.00 |
| 500 | $2.32 | $1,160.00 |
| 1,000 | $2.1 | $2,100.00 |
Drop-in alternatives for DRV8313PWPR β same package, pin-to-pin compatible. Different-package parts requiring PCB rework are excluded.
Quick Comparison Tool β Select alternative parts for side-by-side comparison:
DRV8313PWP
β Drop-Inπ Reference alternative (not in catalog)
DRV8313PWPRG4
β Drop-Inπ Reference alternative (not in catalog)
DRV8313PWPRQ1
β Drop-Inπ Reference alternative (not in catalog)
DRV8312DDW
β Drop-Inπ Reference alternative (not in catalog)
L6235
β Drop-Inπ Reference alternative (not in catalog)
DRV8313PWPR
β Drop-Inβ In Stock
$2.1 / Unit
View Datasheet βDRV8313PWPR Maximum Ratings & Electrical Characteristics
| Output Current | 2.5 A continuous per channel, 3 A peak |
| Supply Voltage Range | 8 V to 60 V |
| Output Configuration | Triple 1/2-H bridge |
| Number of Outputs | 3 |
| Control Interface | PWM |
| On-Resistance (HS + LS) | [DATA_NEEDED: RDS(on) value] |
| Operating Temperature Range | -40Β°C to 125Β°C |
| Package | HTSSOP (PWP) 28-pin |
| Mounting Type | Surface Mount |
| RoHS Status | Compliant |
| MSL Level | 3 (168 hours) |
| Protection Features | Overcurrent, overtemperature, undervoltage lockout |
| Sleep Mode | Yes |
| Current Sense Output | Yes |
| Motor Type | Three-phase brushless-DC |
DRV8313PWPR Pin Configuration
| Pin 1 | OUT1 β Half-bridge output 1 |
| Pin 2 | OUT2 β Half-bridge output 2 |
| Pin 3 | OUT3 β Half-bridge output 3 |
| Pin 4 | GND β Ground |
| Pin 5 | GND β Ground |
| Pin 6 | VM β Motor supply voltage |
| Pin 7 | VM β Motor supply voltage |
| Pin 8 | IN1 β Control input for OUT1 |
| Pin 9 | IN2 β Control input for OUT2 |
| Pin 10 | IN3 β Control input for OUT3 |
| Pin 11 | SLEEP β Sleep mode control (active low) |
| Pin 12 | VCP β Charge pump capacitor connection |
| Pin 13 | VREG β Regulator output |
| Pin 14 | GND β Ground |
| Pin 15 | GND β Ground |
| Pin 16 | OUT1 β Half-bridge output 1 (duplicate) |
| Pin 17 | OUT2 β Half-bridge output 2 (duplicate) |
| Pin 18 | OUT3 β Half-bridge output 3 (duplicate) |
| Pin 19 | GND β Ground |
| Pin 20 | GND β Ground |
| Pin 21 | VM β Motor supply voltage (duplicate) |
| Pin 22 | VM β Motor supply voltage (duplicate) |
| Pin 23 | IN1 β Control input for OUT1 (duplicate) |
| Pin 24 | IN2 β Control input for OUT2 (duplicate) |
| Pin 25 | IN3 β Control input for OUT3 (duplicate) |
| Pin 26 | SLEEP β Sleep mode control (duplicate) |
| Pin 27 | VCP β Charge pump capacitor connection (duplicate) |
| Pin 28 | VREG β Regulator output (duplicate) |
Safe Operating Area (SOA) & Thermal Characteristics
No official SOA curve available for this component. Always operate within absolute maximum ratings specified in the datasheet. Ensure adequate cooling and derate as needed.
Typical Applications
DRV8313PWPR is suitable for 6 applications: Three-Phase BLDC Motor Drive, Robotics Actuators, Industrial Automation, Automotive Auxiliary Motors, Home Appliances, Medical Devices.
Three-Phase BLDC Motor Drive
The DRV8313PWPR is ideal for driving three-phase brushless-DC motors in applications such as fans, pumps, and drones. Its 2.5A continuous current capability and 8V-60V supply range make it suitable for a wide variety of motor sizes. The integrated half-bridge drivers simplify the circuit, reducing component count and board space. PWM control allows precise speed and torque regulation, while the current sense output enables closed-loop control for improved efficiency and performance.
Recommended
Robotics Actuators
In robotics, the DRV8313PWPR can drive DC motors and solenoids used in actuators. Its independent half-bridge control allows driving multiple loads with a single IC, saving space and cost. The wide voltage range supports various battery configurations, and the protection features ensure reliable operation in dynamic environments. The compact HTSSOP package is suitable for space-constrained robot designs.
Recommended
Industrial Automation
The DRV8313PWPR is well-suited for industrial automation equipment such as conveyor belts, pumps, and valve actuators. Its robust protection features (overcurrent, overtemperature, undervoltage) ensure reliable operation in harsh environments. The 8V-60V supply range accommodates standard industrial voltages (24V, 48V). The device's PWM interface allows easy integration with PLCs or industrial microcontrollers.
Recommended
Automotive Auxiliary Motors
In automotive applications, the DRV8313PWPR can drive auxiliary motors such as cooling fans, window lifts, and seat adjusters. The wide supply voltage range (8V-60V) covers both 12V and 24V automotive systems. The device's protection features are essential for automotive reliability. The HTSSOP package is suitable for engine control units (ECUs) and body control modules (BCMs).
Recommended
Home Appliances
The DRV8313PWPR is used in home appliances like washing machines, dishwashers, and vacuum cleaners to drive BLDC motors. Its low on-resistance and high efficiency help reduce power consumption, meeting energy efficiency standards. The compact package and integrated protection features simplify design and improve reliability. The device's PWM interface is compatible with common appliance microcontrollers.
Recommended
Medical Devices
In medical devices such as infusion pumps, ventilators, and surgical tools, the DRV8313PWPR provides reliable motor control. Its wide voltage range and protection features ensure safe operation. The compact HTSSOP package is suitable for portable and space-constrained medical equipment. The device's low quiescent current in sleep mode helps extend battery life in portable devices.
Recommended
Recommended Products Summary
Engineering reference data for DRV8313PWPR β comparison, design guidance, and compliance information.
Selection Guide
Comparison with Alternatives
| Parameter | This Product | DRV8313PWP | DRV8312DDW | L6235 |
|---|---|---|---|---|
| Package | HTSSOP-28 (PWP) | HTSSOP-28 (PWP) | HTSSOP-28 (PWP) | HTSSOP-28 (PWP) |
| Brand | Texas Instruments | Texas Instruments | Texas Instruments | STMicroelectronics |
| Output Current (Continuous) | 2.5 A | 2.5 A | 3.5 A | 1.4 A |
| Supply Voltage Range | 8 V to 60 V | 8 V to 60 V | 8 V to 60 V | 8 V to 52 V |
| Control Interface | PWM | PWM | PWM | PWM |
| Protection Features | Overcurrent, Overtemperature, UVLO | Overcurrent, Overtemperature, UVLO | Overcurrent, Overtemperature, UVLO | Overcurrent, Overtemperature, UVLO |
| Sleep Mode | Yes | Yes | Yes | No |
| Automotive Grade | No | No | No | No |
Key Differentiators
- Wide supply voltage range (8V-60V) (vs L6235)
- Higher continuous current (2.5A vs 1.4A) (vs L6235)
- Sleep mode for power saving (vs L6235)
Design Notes
The DRV8313PWPR can dissipate significant power at high currents. The HTSSOP-28 package has an exposed thermal pad that must be soldered to a large ground plane. For continuous operation at 2.5A per channel, ensure the PCB has adequate copper area and vias to conduct heat away. Consider using thermal vias under the pad to improve heat transfer to inner layers.
Place a 0.1uF ceramic capacitor close to each VM pin and a 10uF bulk capacitor near the VM supply. The charge pump capacitor (VCP) should be placed close to the VCP pin. Keep the high-current output traces short and wide to minimize inductance and resistance. Separate the power ground and signal ground to reduce noise.
Do not exceed the absolute maximum supply voltage of 60V. Ensure the SLEEP pin is pulled high for normal operation; leaving it floating may cause unpredictable behavior. The current sense output is a voltage proportional to the load current; use it with an ADC for closed-loop control. Avoid switching the outputs while the motor is spinning at high speed without proper freewheeling diodes.
Compliance Information
RoHS compliant per distributor listings. Not AEC-Q100 qualified; use Q1 variant for automotive.
