K4RAH165VB-BCWM Übersicht
DDR5 SDRAM is the fifth generation of double data rate synchronous dynamic random-access memory, a volatile memory technology used as main memory in computing systems. Within the memory hierarchy, DRAM sits between CPU caches and non-volatile storage, and DDR5 succeeds DDR4 with higher bandwidth, lower operating voltage, on-die ECC, and improved power management via the onboard PMIC architecture.
Key features of the K4RAH165VB-BCWM include 16Gb density per component, a x16 data interface, 1.1V operation delivering roughly 30% better power efficiency than DDR4 (per Samsung's DDR5 family documentation), and DDR5-standard functions confirmed for family parts in web data: auto self-refresh, asynchronous reset, on-chip error correction code (ECC), write leveling, CRC, and ZQ calibration. DLL-enabled mode operation is covered by the component datasheet timing specifications.
The DDR5 architecture splits each component into two independent channels, improving effective concurrency for data-intensive workloads, while on-die ECC corrects internal bit errors without host overhead. The x16 organization suits client, mobile, and embedded designs that use fewer components per system compared to x8 server configurations.
Typical applications include data-center memory modules where long-term availability is required, high-performance computing, industrial systems, and data-intensive consumer electronics such as tablets and mobile devices.
A key design consideration: DDR5 components require compliant controller training (write leveling, DFE/Read training) and strict fly-by routing with VDDQ termination; the asynchronous reset pin simplifies initialization sequencing relative to DDR4.
This page synthesizes distributor pricing, drop-in family alternatives, and practical design notes not found in the manufacturer datasheet, as of 2026-09-04.
