STF25NM60ND - 600V 21A N-Ch MOSFET TO-220FP | STMicroelectronics
Teilenummer: STF25NM60ND ✓ Aktiv
Auf Lager
Versand in 1–3 Werktagen
600 V Vdss
21 A Id
0.13 ohm Rds(on)
TO-220FP (isolated) Package
Ab $1
USD / Stück
MOQ: 1 |
Preis aktualisiert: 2026-09-03
Mengenpreise
| Menge | Stückpreis | Gesamt |
|---|---|---|
| 1 | $1 | $1,00 |
ℹ️ Alle Preise sind in USD
STF25NM60ND Übersicht
The STMicroelectronics STF25NM60ND is an N-channel 600 V power MOSFET built on the FDmesh II trench technology, rated for 21 A drain current (at Tc) and 40 W power dissipation in an isolated TO-220FP package. Its typical on-resistance of 0.13 ohm and integrated fast-recovery body diode make it well suited for off-line switched-mode power conversion.
A power MOSFET is a voltage-controlled semiconductor switch used to regulate or convert electrical power. Within the component hierarchy, the STF25NM60ND belongs to the transistor family, specifically the MOSFET (metal-oxide-semiconductor field-effect transistor) class, which sits within the broader category of discrete semiconductors and power management components. Power MOSFETs are the switching elements in SMPS topologies such as flyback, forward, half-bridge and resonant converters.
Key features include the 600 V drain-source breakdown voltage rating for universal-mains rectified-bus applications, FDmesh II process technology that lowers RDS(on) and gate charge for improved efficiency, and the fast-recovery intrinsic body diode (indicated by the D suffix) that reduces reverse-recovery losses in hard-switched topologies such as two-switch forward and LLC converters. The F suffix in the part number denotes the TO-220FP fully molded isolated package, providing 2500 Vrms electrical isolation without an external insulator, simplifying heatsink mounting.
The FDmesh II stripe-trench architecture balances conduction and switching losses, allowing designers to optimize for either low-frequency conduction efficiency or high-frequency switching performance. Low gate charge reduces gate-drive losses, while the rugged body diode withstands avalanche events typical of transformer-leakage-inductance environments.
Typical applications include off-line flyback and forward AC-DC converters for industrial power supplies, PFC pre-regulator stages, motor drive inverter legs for light industrial loads, and high-voltage DC-DC modules for solar and telecom rectifiers.
Design tip: the TO-220FP isolated package has higher thermal resistance than standard TO-220, so verify junction temperature with proper heatsink sizing; drive the gate with a low-impedance driver (e.g., 10 ohm series resistor) to manage EMI from fast switching edges.
A power MOSFET is a voltage-controlled semiconductor switch used to regulate or convert electrical power. Within the component hierarchy, the STF25NM60ND belongs to the transistor family, specifically the MOSFET (metal-oxide-semiconductor field-effect transistor) class, which sits within the broader category of discrete semiconductors and power management components. Power MOSFETs are the switching elements in SMPS topologies such as flyback, forward, half-bridge and resonant converters.
Key features include the 600 V drain-source breakdown voltage rating for universal-mains rectified-bus applications, FDmesh II process technology that lowers RDS(on) and gate charge for improved efficiency, and the fast-recovery intrinsic body diode (indicated by the D suffix) that reduces reverse-recovery losses in hard-switched topologies such as two-switch forward and LLC converters. The F suffix in the part number denotes the TO-220FP fully molded isolated package, providing 2500 Vrms electrical isolation without an external insulator, simplifying heatsink mounting.
The FDmesh II stripe-trench architecture balances conduction and switching losses, allowing designers to optimize for either low-frequency conduction efficiency or high-frequency switching performance. Low gate charge reduces gate-drive losses, while the rugged body diode withstands avalanche events typical of transformer-leakage-inductance environments.
Typical applications include off-line flyback and forward AC-DC converters for industrial power supplies, PFC pre-regulator stages, motor drive inverter legs for light industrial loads, and high-voltage DC-DC modules for solar and telecom rectifiers.
Design tip: the TO-220FP isolated package has higher thermal resistance than standard TO-220, so verify junction temperature with proper heatsink sizing; drive the gate with a low-impedance driver (e.g., 10 ohm series resistor) to manage EMI from fast switching edges.
Drop-in-Alternativen für STF25NM60ND – gleiches Gehäuse, Pin-kompatibel. Bauteile mit anderem Gehäuse, die eine PCB-Überarbeitung erfordern, sind ausgeschlossen.
Schnellvergleichstool – Wählen Sie Alternativbauteile für den Direktvergleich:
Für dieses Produkt sind keine Drop-in-Alternativen verfügbar.
Alternativen anfordernSTF25NM60ND Grenzwerte & elektrische Eigenschaften
| Polarity | N-Channel |
| Drain-Source Voltage (VDSS) | 600 V |
| Continuous Drain Current (ID at Tc) | 21 A |
| On-Resistance (RDS(on) typ) | 0.13 ohm |
| Power Dissipation (PD at Tc) | 40 W |
| Technology | FDmesh II trench |
| Body Diode | Fast recovery intrinsic |
| Gehäuse | TO-220FP (isolated) |
| Montageart | Through Hole |
| Isolation | Fully molded isolated package (F suffix) |
| RoHS-Status | Compliant |
| Configuration | Single MOSFET |
STF25NM60ND Pin-Konfiguration
| Pin 1 | Gate (G) — Gate control terminal |
| Pin 2 | Drain (D) — Connected to heatsink tab, drain terminal |
| Pin 3 | Source (S) — Source terminal |
Sicherer Arbeitsbereich
DC-Dauerbetrieb
Typische Anwendungen
STF25NM60ND ist geeignet für 3 Anwendungs: Leistungsmanagement, Motorsteuerung, LED-Beleuchtung.
Leistungsmanagement
Schalten und Regeln in Stromversorgungsschaltungen mit STF25NM60ND.
Motorsteuerung
Ansteuerung und Regelung von DC-/BLDC-Motoren mit STF25NM60ND.
LED-Beleuchtung
Ansteuerung von LED-Strings und -Arrays mit STF25NM60ND.
Für dieses Produkt sind keine FAQs verfügbar.
Technische Referenzdaten für STF25NM60ND – Vergleich, Designhinweise und Compliance-Informationen.
Auswahlhilfe
Choose the STF25NM60ND when you need a 600 V, 21 A N-channel MOSFET with an isolated TO-220FP package for off-line power converters requiring a fast-recovery body diode and no external isolation pad. Choose STP25NM60ND for non-isolated TO-220 mounting with better thermal performance. Choose STB25NM60ND (D2PAK) for surface-mount-friendly boards. Choose STF23NM60ND when slightly lower current (23 A class) suffices at lower cost. For 650 V designs with more margin, consider STF24NM65N. The isolated FP package trades thermal resistance for mounting convenience and isolation.
