STF25NM60ND - 600V 21A N-Ch MOSFET TO-220FP | STMicroelectronics
MPN: STF25NM60ND ✓ Active
In Stock
Ships in 1-3 business days
600 V Vdss
21 A Id
0.13 ohm Rds(on)
TO-220FP (isolated) Package
From $1
USD / Unit
MOQ: 1 |
Price updated: 2026-09-03
Volume Pricing
| Qty | Unit Price | Extended |
|---|---|---|
| 1 | $1 | $1.00 |
ℹ️ All prices are in USD
STF25NM60ND Overview
The STMicroelectronics STF25NM60ND is an N-channel 600 V power MOSFET built on the FDmesh II trench technology, rated for 21 A drain current (at Tc) and 40 W power dissipation in an isolated TO-220FP package. Its typical on-resistance of 0.13 ohm and integrated fast-recovery body diode make it well suited for off-line switched-mode power conversion.
A power MOSFET is a voltage-controlled semiconductor switch used to regulate or convert electrical power. Within the component hierarchy, the STF25NM60ND belongs to the transistor family, specifically the MOSFET (metal-oxide-semiconductor field-effect transistor) class, which sits within the broader category of discrete semiconductors and power management components. Power MOSFETs are the switching elements in SMPS topologies such as flyback, forward, half-bridge and resonant converters.
Key features include the 600 V drain-source breakdown voltage rating for universal-mains rectified-bus applications, FDmesh II process technology that lowers RDS(on) and gate charge for improved efficiency, and the fast-recovery intrinsic body diode (indicated by the D suffix) that reduces reverse-recovery losses in hard-switched topologies such as two-switch forward and LLC converters. The F suffix in the part number denotes the TO-220FP fully molded isolated package, providing 2500 Vrms electrical isolation without an external insulator, simplifying heatsink mounting.
The FDmesh II stripe-trench architecture balances conduction and switching losses, allowing designers to optimize for either low-frequency conduction efficiency or high-frequency switching performance. Low gate charge reduces gate-drive losses, while the rugged body diode withstands avalanche events typical of transformer-leakage-inductance environments.
Typical applications include off-line flyback and forward AC-DC converters for industrial power supplies, PFC pre-regulator stages, motor drive inverter legs for light industrial loads, and high-voltage DC-DC modules for solar and telecom rectifiers.
Design tip: the TO-220FP isolated package has higher thermal resistance than standard TO-220, so verify junction temperature with proper heatsink sizing; drive the gate with a low-impedance driver (e.g., 10 ohm series resistor) to manage EMI from fast switching edges.
A power MOSFET is a voltage-controlled semiconductor switch used to regulate or convert electrical power. Within the component hierarchy, the STF25NM60ND belongs to the transistor family, specifically the MOSFET (metal-oxide-semiconductor field-effect transistor) class, which sits within the broader category of discrete semiconductors and power management components. Power MOSFETs are the switching elements in SMPS topologies such as flyback, forward, half-bridge and resonant converters.
Key features include the 600 V drain-source breakdown voltage rating for universal-mains rectified-bus applications, FDmesh II process technology that lowers RDS(on) and gate charge for improved efficiency, and the fast-recovery intrinsic body diode (indicated by the D suffix) that reduces reverse-recovery losses in hard-switched topologies such as two-switch forward and LLC converters. The F suffix in the part number denotes the TO-220FP fully molded isolated package, providing 2500 Vrms electrical isolation without an external insulator, simplifying heatsink mounting.
The FDmesh II stripe-trench architecture balances conduction and switching losses, allowing designers to optimize for either low-frequency conduction efficiency or high-frequency switching performance. Low gate charge reduces gate-drive losses, while the rugged body diode withstands avalanche events typical of transformer-leakage-inductance environments.
Typical applications include off-line flyback and forward AC-DC converters for industrial power supplies, PFC pre-regulator stages, motor drive inverter legs for light industrial loads, and high-voltage DC-DC modules for solar and telecom rectifiers.
Design tip: the TO-220FP isolated package has higher thermal resistance than standard TO-220, so verify junction temperature with proper heatsink sizing; drive the gate with a low-impedance driver (e.g., 10 ohm series resistor) to manage EMI from fast switching edges.
Drop-in alternatives for STF25NM60ND — same package, pin-to-pin compatible. Different-package parts requiring PCB rework are excluded.
Quick Comparison Tool — Select alternative parts for side-by-side comparison:
No drop-in alternatives available for this product.
Request AlternativesSTF25NM60ND Maximum Ratings & Electrical Characteristics
| Polarity | N-Channel |
| Drain-Source Voltage (VDSS) | 600 V |
| Continuous Drain Current (ID at Tc) | 21 A |
| On-Resistance (RDS(on) typ) | 0.13 ohm |
| Power Dissipation (PD at Tc) | 40 W |
| Technology | FDmesh II trench |
| Body Diode | Fast recovery intrinsic |
| Package | TO-220FP (isolated) |
| Mounting Type | Through Hole |
| Isolation | Fully molded isolated package (F suffix) |
| RoHS Status | Compliant |
| Configuration | Single MOSFET |
STF25NM60ND Pin Configuration
| Pin 1 | Gate (G) — Gate control terminal |
| Pin 2 | Drain (D) — Connected to heatsink tab, drain terminal |
| Pin 3 | Source (S) — Source terminal |
Safe Operating Area
DC Continuous Operation
Typical Applications
STF25NM60ND is suitable for 3 applications: Power Management, Motor Control, LED Lighting.
Power Management
Switching and regulation in power supply circuits using STF25NM60ND.
Motor Control
Driving and controlling DC/BLDC motors with STF25NM60ND.
LED Lighting
Driving LED strings and arrays with STF25NM60ND.
No FAQ available for this product.
Engineering reference data for STF25NM60ND — comparison, design guidance, and compliance information.
Selection Guide
Choose the STF25NM60ND when you need a 600 V, 21 A N-channel MOSFET with an isolated TO-220FP package for off-line power converters requiring a fast-recovery body diode and no external isolation pad. Choose STP25NM60ND for non-isolated TO-220 mounting with better thermal performance. Choose STB25NM60ND (D2PAK) for surface-mount-friendly boards. Choose STF23NM60ND when slightly lower current (23 A class) suffices at lower cost. For 650 V designs with more margin, consider STF24NM65N. The isolated FP package trades thermal resistance for mounting convenience and isolation.
Compliance Information
RoHS
Compliant
REACH
Unknown
AEC-Q100
Lead Free
Halogen Free
Unknown
Conflict Minerals
Unknown
RoHS compliance per STMicroelectronics product listing; other statuses not stated in provided data.
Data verified on: 2026-08-29
— data verified and curated by XAIPART's component engineering team
