EP1C4F400C6 - Cyclone FPGA, 4000 Cells, 400-BGA | Intel
부품 번호: EP1C4F400C6 ⚠ 최종 구매| 수량 | 단가 | 합계 |
|---|---|---|
| 1 | $38.5 | $38.50 |
| 10 | $34.2 | $342.00 |
| 100 | $28.75 | $2,875.00 |
| 500 | $24.1 | $12,050.00 |
| 1,000 | $21.6 | $21,600.00 |
EP1C4F400C6 개요
A Field Programmable Gate Array (FPGA) is a semiconductor device built around an array of configurable logic blocks (CLBs/LEs) connected by programmable interconnect, allowing hardware engineers to implement arbitrary digital logic that is re-programmable in-circuit. Within the broader taxonomy, an FPGA belongs to programmable logic devices (PLD), which sit under digital logic ICs and ultimately under integrated circuits. The Cyclone family sits at the entry-level / low-cost tier of the FPGA hierarchy, above simple CPLDs but below the Stratix high-performance tier.
Key features of the EP1C4F400C6 include 4,000 logic elements distributed across 400 LABs, 301 user I/O pins (supporting LVTTL, LVCMOS, SSTL, and LVDS), 78 Kbits of M4K embedded RAM blocks, two PLLs for clock management, and support for external memory interfaces including SDR SDRAM, FCRAM, and SRAM. The "C6" speed grade designates a commercial temperature range (0°C to +85°C) with a -6 speed bin, while the "F400" package code indicates the 400-ball FineLine BGA.
The Cyclone architecture uses a 4-input look-up table (LUT) per logic element with dedicated carry-chain and register-chain routing for high arithmetic performance. The 130nm process and 1.5V core supply keep dynamic power manageable for high-volume consumer, industrial, and communications designs, while the embedded M4K blocks enable efficient on-chip FIFOs, buffering, and small memory-mapped data paths.
Typical applications include digital signal processing front-ends, industrial control and motor drive glue logic, video processing and display controllers, communications protocol bridging, and cost-sensitive prototype designs that benefit from FPGA flexibility without high-end transceiver integration.
When designing with this device, careful attention must be paid to power distribution across the 400-ball BGA, signal-integrity-driven PCB stackup, and I/O bank VCCIO planning, since mixed-voltage I/O standards require per-bank supply rails.
This page synthesizes distributor pricing, same-family drop-in alternatives, and practical design notes not collected in any single manufacturer document.
드롭인 대체품: EP1C4F400C6 — 동일 패키지, 핀 호환. PCB 재작업이 필요한 다른 패키지 부품은 제외됩니다.
이 시리즈의 변형
다음과 드롭인 호환되는 동일 시리즈 모델: EP1C4F400C6 (동일 폼 팩터 및 풋프린트) — 차이점: Speed Grade, Package, Family, Operating Temperature, Total RAM Bits.
빠른 비교 도구 — 나란히 비교할 대체 부품을 선택하십시오:
EP1C4F400C8N
✅ 드롭인✓ 재고 있음
$15.26 / 개
데이터시트 보기 →EP1C4F400C7N
✅ 드롭인✓ 재고 있음
$28.9 / 개
데이터시트 보기 →EP1C4F400I7N
✅ 드롭인✓ 재고 있음
$26.75 / 개
데이터시트 보기 →EP1C4F400C6N
✅ 드롭인✓ 재고 있음
$26.4 / 개
데이터시트 보기 →EP1C4F400C7
✅ 드롭인✓ 재고 있음
$18.75 / 개
데이터시트 보기 →EP1C4F400C6 최대 정격 & 전기적 특성
| Family | Cyclone |
| Logic Elements | 4,000 |
| Logic Array Blocks (LABs) | 400 |
| Total RAM Bits | 78,000 |
| Embedded RAM Blocks | M4K |
| User I/O Pins | 301 |
| PLLs | 2 |
| 패키지 | 400-ball FineLine BGA (FBGA-400) |
| Process Technology | 130 nm CMOS |
| Core Voltage | 1.5 V |
| Speed Grade | -6 (commercial) |
| 동작 온도 | 0°C to +85°C (commercial) |
| 실장 유형 | Surface Mount (BGA) |
EP1C4F400C6 400-ball fineline bga (fbga-400) 핀 구성 가이드
EP1C4F400C6(400-ball fineline bga (fbga-400) 패키지)의 핀 구성입니다. 이 디지털 IC에는 GPIO, 통신 인터페이스(UART, SPI, I2C), 전원 핀이 포함되어 있습니다. 대체 핀 기능과 구성 옵션은 제조사 데이터시트를 참조하십시오. 임베디드 시스템 설계와 PCB 레이아웃에 필수적입니다.
다음에 대한 상세 핀아웃 데이터 없음: EP1C4F400C6.
다음을 참조하십시오: 데이터시트 전체 핀 구성은 다음을 참조하십시오.
일반적인 애플리케이션
EP1C4F400C6 적합 용도: 6 애플리케이션s: Industrial Control and Glue Logic, Digital Signal Processing Front-End, Video Processing and Display Controllers, Communications Protocol Bridging, Cost-Sensitive Prototype and Evaluation Designs, Legacy Equipment Modernization and Long-Life Programs.
Industrial Control and Glue Logic
The EP1C4F400C6 is well suited to industrial control and motor-drive glue logic where 4,000 logic elements, 301 user I/Os, and two PLLs provide more than enough capacity for state machines, encoder interfaces, and PWM generation. Its commercial temperature range (0°C to +85°C) covers most factory-floor enclosures with active cooling. The 400-ball BGA enables dense board layouts, while the M4K RAM blocks implement command FIFOs and look-up tables for sensor linearization.
추천
Digital Signal Processing Front-End
For low-cost DSP front-ends such as audio sample-rate conversion, FIR/IIR filter banks, or simple FFT pre-processing, the EP1C4F400C6's 4,000 LEs and 78 Kbits of embedded RAM provide adequate resources for moderate-complexity algorithms at audio and baseband sample rates. The two PLLs generate the precise clock trees required for ADC/DAC synchronization, and the LVDS-capable I/Os interface directly to common audio and video ADCs without external translators.
추천
Video Processing and Display Controllers
The EP1C4F400C6 is commonly deployed in video format conversion, de-interlacing, and LCD/TFT timing generator designs. Its 301 user I/Os comfortably drive 24-bit RGB plus control and sync signals, while the M4K RAM blocks implement line buffers and color lookup tables. Designers use the LVDS I/O capability to interface directly to LVDS panel inputs, eliminating external serializer components and reducing BOM cost in consumer displays.
추천
Communications Protocol Bridging
Bridge designs converting between UART, SPI, I2C, parallel buses, and legacy telecom interfaces fit naturally in 4,000 LEs. The EP1C4F400C6's abundant user I/Os (301) make it ideal for multi-channel protocol aggregation, while the M4K blocks buffer packet payloads between asynchronous clock domains. Industrial protocol stacks such as Modbus, Profibus, and CAN glue logic are easily implemented, making this part a common choice for legacy equipment modernization.
추천
Cost-Sensitive Prototype and Evaluation Designs
Designers building FPGA-based prototypes for ASIC validation, university teaching platforms, or low-volume OEM products appreciate the EP1C4F400C6's balance of capacity and price. Quartus II Web Edition (free) supports the full Cyclone family, eliminating software licensing friction. The 400-ball BGA exposes enough I/Os for daughter-card expansion, and the abundant M4K RAM enables realistic test benches with realistic data buffering requirements.
추천
Legacy Equipment Modernization and Long-Life Programs
Many defense, aerospace, and medical OEMs have Cyclone I designs that must continue manufacturing for 10-20 year life cycles. Because the EP1C4F400C6 is on Intel's last-time-buy list (as of 2026-09-06), these programs are stockpiling inventory and qualifying drop-in alternatives such as the EP1C4F400C8N and EP1C4F400I7N. These parts share the same die, package, and pinout, allowing form-fit-function continuity without PCB redesign.
추천
추천 제품 요약
엔지니어링 참조 데이터: EP1C4F400C6 — 비교, 설계 지침 및 규정 준수 정보.
선택 가이드
대체품과의 비교
| 파라미터 | 이 제품 | EP1C4F400C8N | EP1C4F400C7N | EP1C4F400I7N | EP1C4F400C6N | EP1C4F400C7 |
|---|---|---|---|---|---|---|
| Brand | Intel | Intel | Intel | Intel | Intel | Intel |
| Package | 400-ball FineLine BGA | 400-ball FineLine BGA (same) | 400-ball FineLine BGA (same) | 400-ball FineLine BGA (same) | 400-ball FineLine BGA (same) | 400-ball FineLine BGA (same) |
| Logic Elements | 4,000 | 4,000 | 4,000 | 4,000 | 4,000 | 4,000 |
| LABs | 400 | 400 | 400 | 400 | 400 | 400 |
| User I/Os | 301 | 301 | 301 | 301 | 301 | 301 |
| Speed Grade | -6 | -8 | -7 | -7 | -6 | -7 |
| Temperature Range | 0°C to +85°C (commercial) | 0°C to +85°C (commercial) | 0°C to +85°C (commercial) | -40°C to +100°C (industrial) | 0°C to +85°C (commercial) | 0°C to +85°C (commercial) |
| Lead-Free Finish | No (leaded, C6 suffix) | Yes (N suffix) | Yes (N suffix) | Yes (N suffix) | Yes (N suffix) | No (leaded) |
| Lifecycle Status | Last-Time-Buy | Last-Time-Buy | Last-Time-Buy | Last-Time-Buy | Last-Time-Buy | Last-Time-Buy |
주요 차별점
- Lowest-cost 4,000-LE Cyclone variant with -6 speed grade (vs EP1C4F400C8N)
- Commercial temperature range matches cost-driven designs (vs EP1C4F400I7N)
- Leaded terminal finish for legacy manufacturing compatibility (vs EP1C4F400C6N)
설계 노트
The 400-ball FineLine BGA uses a 1.0 mm ball pitch, which mandates a 4-layer or 6-layer PCB stackup with microvia or sub-merged via technology for fan-out. Route all VCCINT (1.5V core) and VCCIO (per-bank I/O supply) rails with wide power planes and place 0.1 µF + 10 µF decoupling capacitors within 100 mil of every supply pin. Use a continuous GND plane on the layer immediately beneath the BGA to provide a low-impedance return path and to dissipate the 1.5W to 3W typical device power.
Estimated: at 100% logic utilization with 200 MHz internal clock, the EP1C4F400C6 dissipates approximately 1.5 W to 3 W. With a typical junction-to-ambient thermal resistance (θJA) of 12 °C/W for a 400-ball BGA on a 4-layer JEDEC test board, junction temperature rise above ambient is ~36 °C. For sustained high-activity designs, ensure at least 8 thermal vias in the BGA center pad to the internal GND plane to maintain junction temperature below 125 °C.
Do not mix LVTTL 3.3V and LVDS 2.5V signals in the same I/O bank without proper VCCIO planning — each bank shares a single VCCIO rail. Floating configuration pins (nCONFIG, nSTATUS, CONF_DONE) can cause undefined startup behavior; tie them through 10 kΩ pull-ups to VCCIO. For JTAG chains, ensure the JTAG pins are not repurposed as general I/O in the Quartus pin planner, or boundary-scan will fail. Finally, do not assume the original Cyclone bitstream format is compatible with Quartus Prime — use Quartus II 13.0sp1 or earlier for compilation.
규정 준수 정보
EP1C4F400C6 has a leaded (SnPb) terminal finish per the 'no N-suffix' convention; RoHS/REACH status not explicitly stated in verified data. Industrial variants (I7N suffix) and lead-free variants (N suffix) exist for compliant builds.
