A3P600-FG484I - 600K Gate Flash FPGA, 231MHz | Microchip
MPN: A3P600-FG484I ✓ Active| Qty | Unit Price | Extended |
|---|---|---|
| 1 | $36.21 | $36.21 |
| 10 | $33.5 | $335.00 |
| 100 | $30.8 | $3,080.00 |
| 500 | $28.1 | $14,050.00 |
| 1,000 | $25.4 | $25,400.00 |
A3P600-FG484I Overview
An FPGA (Field Programmable Gate Array) is an integrated circuit that can be configured by the customer after manufacturing to implement arbitrary digital logic functions. Unlike microcontrollers or ASICs, FPGAs contain a fabric of programmable logic blocks and interconnects, allowing designers to create custom hardware without the cost and lead time of a custom chip. The ProASIC3 family uses flash-based configuration cells, which retain their programming even when power is removed, enabling instant-on operation and eliminating the need for external boot memory.
Key features of the A3P600-FG484I include 600K system gates, 231MHz system performance, 235 user I/Os, and 1.5V core operation. The flash-based architecture provides non-volatile configuration, low power consumption, and high security against reverse engineering. The device supports up to 128K bits of flash memory for user data and includes advanced clock management with up to 6 PLLs, enabling robust timing control for complex designs.
The ProASIC3 architecture uses a VersaTile core that can be configured as either a three-input lookup table (LUT) or a D-flip-flop/latch with enable, providing efficient use of the FPGA fabric. The 130nm flash process delivers a balance of performance and power, with low static power consumption ideal for battery-powered and thermally constrained applications. The device supports multiple I/O standards including LVCMOS, LVTTL, and differential standards, offering design flexibility.
Typical applications for the A3P600-FG484I include industrial control, automotive electronics, communications infrastructure, and aerospace systems where reliability, security, and instant-on operation are critical. Its non-volatile configuration makes it suitable for safety-critical applications that require immediate functionality upon power-up without external configuration devices.
When designing with this device, consider the 1.5V core supply requirement and ensure adequate decoupling on all power pins. The flash-based configuration eliminates the need for a configuration PROM, simplifying board design and reducing BOM cost. For high-speed I/O, follow the manufacturer's layout guidelines for signal integrity and use the integrated PLLs for clock management.
This page synthesizes distributor pricing, drop-in alternatives, and practical design notes not found in the manufacturer datasheet, providing engineers with a comprehensive resource for evaluating the A3P600-FG484I in their designs.
Drop-in alternatives for A3P600-FG484I — same package, pin-to-pin compatible. Different-package parts requiring PCB rework are excluded.
Variants in this series
Same-series models that are drop-in compatible with A3P600-FG484I (same form factor and footprint) — differing in Package, Core Supply Voltage, Configuration Memory, Operating Temperature, RoHS Status.
Quick Comparison Tool — Select alternative parts for side-by-side comparison:
A3P600-FGG484I
✅ Drop-In✓ In Stock
$55.3 / Unit
View Datasheet →A3P600-FGG484
✅ Drop-In✓ In Stock
$44.75 / Unit
View Datasheet →A3P600L-FG484I
✅ Drop-In✓ In Stock
$45.6 / Unit
View Datasheet →A3P600L-FGG484I
✅ Drop-In✓ In Stock
$41.35 / Unit
View Datasheet →A3P600L-1FG484I
✅ Drop-In✓ In Stock
Contact for price
View Datasheet →A3P600L-1FGG484I
✅ Drop-In✓ In Stock
$17.1 / Unit
View Datasheet →A3P600-FG484I Maximum Ratings & Electrical Characteristics
| Family | ProASIC3 |
| System Gates | 600K |
| Maximum Frequency | 231 MHz |
| Technology | 130nm Flash |
| Core Supply Voltage | 1.5 V |
| User I/Os | 235 |
| Package | 484-FBGA |
| Mounting Type | Surface Mount |
| Operating Temperature | -40C to +100C |
| Configuration | Flash-based, non-volatile |
| PLLs | 6 |
| Flash Memory | 128K bits |
| I/O Standards | LVCMOS, LVTTL, differential |
| RoHS Status | Compliant |
| Lifecycle | Active |
A3P600-FG484I 484-fbga Pin Configuration Guide
Pin configuration for A3P600-FG484I (484-fbga package). This digital IC includes GPIO, communication interfaces (UART, SPI, I2C), and power pins. Refer to the manufacturer datasheet for alternate pin functions and configuration options. Essential for embedded system design and PCB layout.
No detailed pinout data available for A3P600-FG484I.
Refer to the datasheet for full pin configuration.
Typical Applications
A3P600-FG484I is suitable for 6 applications: Industrial Control, Automotive Electronics, Aerospace and Defense, Communications Infrastructure, Medical Electronics, IoT and Edge Computing.
Industrial Control
The A3P600-FG484I is ideal for industrial control systems requiring reliable, instant-on operation. Its flash-based configuration ensures immediate functionality upon power-up, critical for safety-critical machinery. With 600K gates and 235 I/Os, it can handle complex logic for motor control, PLCs, and robotics. The 1.5V core and low static power reduce thermal stress in sealed enclosures. The device's non-volatile configuration eliminates the need for external boot memory, simplifying BOM and improving reliability in harsh environments. Its wide operating temperature range (-40C to +100C) suits factory floors and outdoor installations. The integrated PLLs enable precise clock generation for synchronized control loops, while the 130nm flash technology provides high immunity to radiation-induced configuration loss, making it suitable for industrial environments with electromagnetic interference.
Recommended
Automotive Electronics
In automotive applications, the A3P600-FG484I provides a secure, instant-on FPGA for engine control, infotainment, and advanced driver-assistance systems (ADAS). Its flash-based configuration is inherently secure against reverse engineering, protecting proprietary algorithms. The 231MHz performance handles real-time processing for sensor fusion and motor control. The device operates from a 1.5V core, compatible with modern automotive power rails, and its wide temperature range meets under-hood requirements. The non-volatile configuration ensures immediate operation on ignition, critical for safety systems. With 235 I/Os, it interfaces with various sensors and actuators. The ProASIC3 family's radiation tolerance makes it suitable for automotive environments with high electromagnetic interference. The low power consumption reduces heat generation, improving reliability in enclosed electronic control units (ECUs).
Recommended
Aerospace and Defense
The A3P600-FG484I is well-suited for aerospace and defense systems requiring high reliability and security. Its flash-based configuration is immune to bit-flips from radiation, a key advantage over SRAM-based FPGAs. The instant-on capability is essential for mission-critical systems that must operate immediately upon power-up. With 600K gates, it can implement complex signal processing, encryption, and control logic. The 1.5V core and low power consumption are beneficial for space-constrained, power-limited platforms like satellites and UAVs. The device's wide temperature range and robust packaging meet military standards. The integrated PLLs provide precise clocking for communication systems. The non-volatile configuration eliminates the need for external configuration memory, reducing system complexity and improving reliability in harsh environments. The ProASIC3 family's security features protect against unauthorized copying of the design.
Recommended
Communications Infrastructure
In communications infrastructure, the A3P600-FG484I provides a flexible, reprogrammable platform for base stations, routers, and switches. Its 231MHz performance and 235 I/Os enable high-speed data processing and interface to various protocols. The flash-based configuration allows field updates without external memory, simplifying maintenance. The device's low power consumption reduces cooling requirements in dense networking equipment. The integrated PLLs generate clean clocks for high-speed serial links. The 1.5V core is compatible with modern networking power supplies. The non-volatile configuration ensures quick boot-up, minimizing downtime. The ProASIC3 family's security features protect against unauthorized access to the configuration, safeguarding intellectual property. The wide temperature range suits outdoor and indoor installations. The device's reliability makes it suitable for always-on infrastructure.
Recommended
Medical Electronics
The A3P600-FG484I is suitable for medical devices requiring reliable, secure, and instant-on operation. Its flash-based configuration ensures immediate functionality, critical for life-support equipment. The 600K gates provide ample logic for signal processing, imaging, and patient monitoring. The device's low power consumption reduces heat, important for portable and wearable medical devices. The 1.5V core is compatible with battery-powered systems. The non-volatile configuration eliminates the need for external boot memory, reducing size and improving reliability. The wide temperature range supports various clinical environments. The ProASIC3 family's security features protect patient data and device firmware. The integrated PLLs enable precise timing for diagnostic equipment. The device's long-term availability and reliability make it suitable for medical applications with stringent regulatory requirements.
Recommended
IoT and Edge Computing
The A3P600-FG484I enables edge computing and IoT devices with its low power consumption and instant-on capability. Its flash-based configuration allows secure, over-the-air updates without external memory. The 600K gates provide sufficient logic for sensor fusion, protocol bridging, and local AI inference. The 1.5V core and low static power extend battery life in wireless sensors and gateways. The device's small footprint and 235 I/Os interface with various sensors and communication modules. The non-volatile configuration ensures quick wake-up from sleep modes, critical for energy-efficient IoT devices. The integrated PLLs generate clocks for wireless transceivers. The ProASIC3 family's security features protect against unauthorized access, essential for connected devices. The wide temperature range supports outdoor IoT deployments. The device's reliability ensures long-term operation in remote locations.
Recommended
Recommended Products Summary
Engineering reference data for A3P600-FG484I — comparison, design guidance, and compliance information.
Selection Guide
Comparison with Alternatives
| Parameter | This Product | A3P600-FGG484I | A3P600-FGG484 | A3P600L-FG484I |
|---|---|---|---|---|
| Package | 484-FBGA | 484-FBGA | 484-FBGA | 484-FBGA |
| Brand | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| System Gates | 600K | 600K | 600K | 600K |
| Maximum Frequency | 231 MHz | 231 MHz | 231 MHz | 231 MHz |
| User I/Os | 235 | 235 | 235 | 235 |
| Core Supply Voltage | 1.5 V | 1.5 V | 1.5 V | 1.5 V |
| Operating Temperature | -40C to +100C | -40C to +100C | 0C to +85C | -40C to +100C |
| Lead-Free Finish | No | Yes | Yes | No |
Key Differentiators
- Flash-based non-volatile configuration (vs SRAM-based FPGAs)
- Low power consumption (vs A3P600-FGG484I)
- Industrial temperature range (vs A3P600-FGG484)
Design Notes
The A3P600-FG484I requires a 1.5V core supply. Use a low-dropout regulator (LDO) or a switching regulator with low ripple to provide this rail. Ensure adequate decoupling with 100nF ceramic capacitors on each power pin and a 10uF bulk capacitor near the device. The flash-based configuration draws minimal current, but the I/O banks may require additional supply voltages depending on the I/O standard used. Refer to the datasheet for recommended power-up sequencing to avoid latch-up.
The A3P600-FG484I in a 484-FBGA package has a thermal resistance that depends on airflow and PCB design. For high utilization designs, estimate power dissipation using the datasheet's power calculator. Ensure adequate thermal vias under the package and consider a heatsink if the junction temperature exceeds the maximum rating. The 1.5V core and low static power help keep temperatures manageable, but high I/O toggle rates can increase dynamic power. Use the manufacturer's power estimation tool for accurate thermal analysis.
For the 484-FBGA package, follow the manufacturer's layout guidelines for BGA routing. Use a 4-layer or more PCB with dedicated power and ground planes. Route high-speed I/O with controlled impedance and minimize trace lengths. Place decoupling capacitors close to the power pins. The flash-based configuration does not require external configuration pins, simplifying layout. Ensure the PCB footprint matches the recommended land pattern in the datasheet to avoid solder joint issues.
Compliance Information
The A3P600-FG484I is RoHS compliant per distributor listings. The FGG variant is lead-free. AEC-Q100 not applicable for this FPGA.
