W634GU6RB-09 - 4Gb DDR3L SDRAM 1066MHz | Winbond

Name: W634GU6RB-09
Brand: Winbond Electronics
Price: 38.01 USD
Availability: InStock

MPN: W634GU6RB-09 ✓ Active

In Stock (99,999) Ships in 1-3 business days

1.35V Vdss [DATA_NEEDED: supply current] Id 96-VFBGA (7.5x13) Package 1.067 GHz Speed DDR3L SDRAM Memory

$38.01 USD / Unit

MOQ: 1 |

Volume Pricing

Qty	Unit Price	Extended
1	$38.01	$38.01
10	$35.5	$355.00
100	$30.2	$3,020.00
500	$25.8	$12,900.00
1,000	$22.5	$22,500.00

ℹ️ All prices are in USD

View Datasheet (PDF) View Alternatives

Quantity

Drop-in alternatives for W634GU6RB-09 — same package, pin-to-pin compatible. Different-package parts requiring PCB rework are excluded.

Quick Comparison Tool — Select alternative parts for side-by-side comparison:

W634GU6RB09I

✅ Drop-In

Winbond

📦 96-VFBGA (7.5x13)

DDR3L SDRAM · 4Gbit (256M x 16) · 16 bit · 1.067 GHz · 20 ns · 1.35 V · 96-VFBGA (7.5x13 mm) · -40C to +95C

✓ 99,999 In Stock

$6 / Unit

View Datasheet →

W634GU6RB-09-TR

✅ Drop-In

📦 96-VFBGA (7.5x13)

Tape and reel packaging variant

📋 Reference alternative (not in catalog)

W634GU6RB-11

✅ Drop-In

Winbond

📦 96-VFBGA (7.5x13)

SDRAM - DDR3L · 4Gbit (256M x 16) · Parallel · 933 MHz · 20 ns · 1.35V (1.283V to 1.45V) · 96-VFBGA (7.5x13 mm) · -40°C to +95°C

✓ 99,999 In Stock

$32.8 / Unit

View Datasheet →

K4B4G0846E

✅ Drop-In

📦 96-FBGA (7.5x13)

Cross-brand, same density and package, verify pinout

📋 Reference alternative (not in catalog)

MT41K512M8DA-107

✅ Drop-In

📦 96-FBGA (7.5x13)

Cross-brand, same density and package, verify pinout

📋 Reference alternative (not in catalog)

W634GU6RB-09 Maximum Ratings & Electrical Characteristics

Memory Type	DDR3L SDRAM
Memory Size	4Gbit (512M x 8)
Clock Frequency	1.067 GHz
Data Rate	2133 Mbps
Access Time	20 ns
Supply Voltage	1.35V
Interface	Parallel
Package	96-VFBGA (7.5x13)
Mounting Type	Surface Mount
Operating Temperature	[DATA_NEEDED: operating temperature range]
RoHS Status	Compliant
Halogen Free	Yes
Organization	512M x 8
Number of Pins	96
Supply Current	[DATA_NEEDED: supply current]
