W634GU6RB11J - 4Gb DDR3L SDRAM x16 933MHz | Winbond
MPN: W634GU6RB11J ✓ Active| Qty | Unit Price | Extended |
|---|---|---|
| 1 | $13.87 | $13.87 |
| 10 | $12.5 | $125.00 |
| 100 | $11.2 | $1,120.00 |
| 500 | $10.1 | $5,050.00 |
| 1,000 | $9.5 | $9,500.00 |
Drop-in alternatives for W634GU6RB11J — same package, pin-to-pin compatible. Different-package parts requiring PCB rework are excluded.
Quick Comparison Tool — Select alternative parts for side-by-side comparison:
W634GU6RB-11
✅ Drop-In✓ 99,999 In Stock
$32.8 / Unit
View Datasheet →W634GU6RB11K
✅ Drop-In📋 Reference alternative (not in catalog)
MT41K256M16TW-107
✅ Drop-In✓ 99,999 In Stock
$11.66 / Unit
View Datasheet →IS43TR16512BL-107MBL
✅ Drop-In📋 Reference alternative (not in catalog)
K4B4G1646E-BYMA
✅ Drop-In✓ 99,999 In Stock
$11.5 / Unit
View Datasheet →W634GU6RB11J Maximum Ratings & Electrical Characteristics
| Memory Type | SDRAM - DDR3L |
| Memory Size | 4Gbit (256M x 16) |
| Clock Frequency | 933 MHz |
| Data Rate | 1866 MT/s |
| Interface | Parallel |
| Supply Voltage | 1.35V |
| CAS Latency | 20 ns |
| Package | 96-VFBGA (7.5x13 mm) |
| Operating Temperature | -40°C to +95°C |
| Mounting Type | Surface Mount |
| RoHS Status | Compliant |
| Halogen Free | Yes |
| Auto Self-Refresh | Yes |
| Write Leveling | Yes |
| ZQ Calibration | Yes |
W634GU6RB11J Pin Configuration
| Pin A1 | VDD — Power supply |
| Pin A2 | DQ0 — Data input/output 0 |
| Pin A3 | DQ1 — Data input/output 1 |
| Pin B1 | VSS — Ground |
| Pin B2 | DQ2 — Data input/output 2 |
| Pin B3 | DQ3 — Data input/output 3 |
| Pin C1 | VDDQ — I/O power supply |
| Pin C2 | DQ4 — Data input/output 4 |
| Pin C3 | DQ5 — Data input/output 5 |
| Pin D1 | VSSQ — I/O ground |
| Pin D2 | DQ6 — Data input/output 6 |
| Pin D3 | DQ7 — Data input/output 7 |
Safe Operating Area (SOA) & Thermal Characteristics
No official SOA curve available for this digital IC. Always operate within absolute maximum ratings specified in the datasheet. Ensure adequate cooling and derate as needed.
Typical Applications
W634GU6RB11J is suitable for 6 applications: Networking Equipment, Industrial Automation, Medical Devices, Embedded Computing, Automotive Infotainment, Test & Measurement.
Networking Equipment
The W634GU6RB11J provides high-density, low-power memory for routers and switches. Its 4Gb capacity and 1866 MT/s data rate support high-bandwidth packet processing. The 1.35V operation reduces power consumption in 24/7 operation, and the industrial temperature range ensures reliability in telecom cabinets. The x16 interface simplifies PCB routing, and features like write leveling improve signal integrity at high speeds.
Recommended
Industrial Automation
In industrial controllers, the W634GU6RB11J offers reliable memory for real-time data logging and control algorithms. Its -40°C to +95°C range suits factory floors, and auto self-refresh maintains data integrity during power-saving modes. The 1.35V supply reduces heat generation, and the 96-ball VFBGA package withstands vibration. The 4Gb density supports complex HMI applications without external storage.
Recommended
Medical Devices
The W634GU6RB11J is ideal for medical imaging and patient monitoring systems that require high-speed, low-power memory. Its 1866 MT/s data rate enables fast image processing, while 1.35V operation extends battery life in portable devices. The industrial temperature range ensures reliable operation in clinical environments. The x16 interface simplifies connection to medical-grade processors, and features like DTC improve signal quality for error-free data transfer.
Recommended
Embedded Computing
For embedded systems like single-board computers and IoT gateways, the W634GU6RB11J provides a balance of capacity and power efficiency. Its 4Gb size supports Linux-based applications, and the 1.35V supply is compatible with low-power SoCs. The 96-ball VFBGA package is compact for space-constrained designs. Features like ZQ calibration ensure reliable operation across temperature variations, making it suitable for outdoor IoT deployments.
Recommended
Automotive Infotainment
The W634GU6RB11J supports automotive infotainment systems requiring high-bandwidth memory for navigation and multimedia. Its 1866 MT/s data rate handles HD video playback, and the 1.35V supply reduces heat in the cabin. The industrial temperature range covers automotive environments, and features like write leveling ensure stable operation. The x16 interface connects easily to automotive SoCs, and the compact package fits head units.
Recommended
Test & Measurement
In oscilloscopes and data acquisition systems, the W634GU6RB11J provides fast, reliable memory for waveform storage. Its 1866 MT/s data rate enables high-speed sampling, and the 4Gb capacity stores long records. The 1.35V operation reduces noise, and the industrial temperature range ensures accuracy in lab and field use. The x16 interface simplifies connection to FPGAs, and features like auto precharge improve efficiency.
Recommended
Recommended Products Summary
Engineering reference data for W634GU6RB11J — comparison, design guidance, and compliance information.
Selection Guide
Comparison with Alternatives
| Parameter | This Product | W634GU6RB-11 | W634GU6RB11K | MT41K256M16TW-107 |
|---|---|---|---|---|
| Package | 96-VFBGA (7.5x13) | 96-VFBGA (7.5x13) | 96-VFBGA (7.5x13) | 96-FBGA (7.5x13) |
| Brand | Winbond Electronics | Winbond Electronics | Winbond Electronics | Micron Technology |
| Memory Size | 4Gbit | 4Gbit | 4Gbit | 4Gbit |
| Organization | 256M x 16 | 256M x 16 | 256M x 16 | 256M x 16 |
| Clock Frequency | 933 MHz | 933 MHz | 933 MHz | 933 MHz |
| Supply Voltage | 1.35V | 1.35V | 1.35V | 1.35V |
| Operating Temperature | -40°C to +95°C | -40°C to +95°C | -40°C to +95°C | 0°C to +95°C |
| RoHS | Compliant | Compliant | Compliant | Compliant |
Key Differentiators
- Industrial temperature range (vs MT41K256M16TW-107)
- Renewable energy option (vs W634GU6RB-11)
- Low power consumption (vs K4B4G1646E-BYMA)
Design Notes
Ensure proper decoupling capacitors (0.1uF and 1uF) are placed close to each VDD and VDDQ pin to minimize power supply noise. Follow JEDEC DDR3L layout guidelines for controlled impedance traces (typically 50 ohms single-ended, 100 ohms differential) and maintain equal trace lengths for DQ and DQS signals to ensure signal integrity at 1866 MT/s.
The W634GU6RB11J operates over -40°C to +95°C. In high-ambient-temperature environments, ensure adequate airflow or heatsinking to keep the junction temperature within limits. The 1.35V supply reduces power dissipation, but at 1866 MT/s, the device can still generate significant heat. Use thermal vias under the package to improve heat transfer to the PCB.
Do not exceed the absolute maximum ratings for VDD (1.575V) and VDDQ (1.575V). Ensure the memory controller is configured for DDR3L (1.35V) operation, not DDR3 (1.5V), to avoid damage. Also, verify that the CAS latency and timing parameters match the controller's settings to prevent data corruption.
Compliance Information
RoHS and halogen-free per Winbond. AEC-Q100 not specified for this part; automotive variants may be available.
