K4B4G1646E-BYMA Übersicht
DDR3L SDRAM is a type of double data rate synchronous dynamic random-access memory that operates at a lower voltage (1.35V) compared to standard DDR3 (1.5V), reducing power consumption by up to 20% while maintaining compatibility with DDR3L and DDR3 systems. It is part of the memory hierarchy in computing systems, serving as main memory for processors, and is widely used in laptops, servers, embedded systems, and networking equipment.
Key features include a 4Gb density organized as 256M x 16, a 1.35V power supply (with 1.28V to 1.575V range), a 933 MHz clock frequency, and a typical operating current of 14mA. The device supports auto precharge, asynchronous reset, and dynamic on-chip termination, enhancing performance and ease of use. The FBGA-96 package offers a compact footprint suitable for space-constrained designs.
Technically, the K4B4G1646E-BYMA uses Samsung's advanced E-die process technology, providing high-speed operation with low power. It features programmable CAS latency, burst length, and output drive strength, allowing system designers to optimize performance. The device includes a temperature sensor for thermal management and supports on-die termination (ODT) for improved signal quality.
Typical applications include DDR3L memory modules for laptops and ultrabooks, networking equipment such as routers and switches, industrial computing systems, and embedded applications requiring high-density, low-power memory. Its 1.35V operation makes it ideal for power-sensitive designs.
When designing with this device, ensure proper decoupling capacitors near the power pins and follow the layout guidelines in the datasheet to minimize signal integrity issues. The device requires a stable 1.35V supply and a reference voltage (VREF) for optimal operation.
